REVISIONS
REV.
A
B
ECO. NO
2168
2688
DESCRIPTION
INITIAL RELEASE
REMOVE DIMPLE BUMP ON TAILS, ADD GUIDE
POSTS & PCB LAYOUT TOLERANCE, UPDTE REF
CONTACT GAP DIM (WAS .35mm REF)
DATE
08/30/2010
10/12/2012
BY
LH
LH
F
F
A
.050 1.27
E
.050 1.27
E
B
D
.041 1.04
.012 0.30
.091 2.30
.199 5.05
.122 3.10
.091 2.30
.004 [0.10]
D
C
2X .039 1.00
OPTIONAL
SEE PART NUMBER CODING
C
A
C
C
.050 1.27
.028 0.70
.020 0.52 X .005[0.12]
2X
.025±.004 0.64±0.10
.063 1.60
.220 5.60
B
B
+.004
+0.10
2X .031
0.80
- .000
0.00
(FOR GUIDE POSTS, OPTIONAL)
NOTES:
1. INSULATOR MATERIAL: NYLON 6T, UL 94V-0, COLOR: BLACK.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: GOLD FLASH OVERALL.
4. CURRENT RATING: 1 AMP.
5. INSULATOR RESISTANCE: 5000 MEGAOHMS MIN.
6. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
7. DIELECTRIC WITHSTANDING: 500V AC.
8. OPERATING TEMPERATURE: -40° C TO +105° C.
9. *PROCESSING TEMPERATURE: 230° C FOR 60 SECONDS MAX.
(260° C FOR 10 SECONDS MAX.)
10. FOR TOP AND BOTTOM ENTRY.
(*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT
INSULATOR. HIGHER PROCESSING TEMPERATURES MAY BE USED,
PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB, AND INSULATOR
DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.)
8
7
6
5
.030 0.76
.050 1.27
RECOMMENDED PCB LAYOUT
DRAWN
DATE
8/16/2010
NAME
LH
TITLE
A
Pb
R
oHS COMPLIANT
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
ANGULAR: 5
.XX= .01 [0.3]
.XXX= .008 [0.20]
.XXXX= .0040 [0.100]
TOLERANCES:
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
PART NUMBER
SIZE
HEADER .050 CC, DUAL ROW
CAGE CODE
A
SFM230-NPPB-D_ _-S_-BK
DWG. NO.
INTERPRET DIMENSIONS AND
TOLERANCING
PER: ASME Y14.5M-2009
3
SCALE: 8:1
2
C
54453
11564
REV
SHEET 1 OF 1
1
B
FILE NAME: 11564, SFM230-NPPB-D_ _-S_-BK
