03029BR221BJZL7292 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> 03029BR221BJZL7292

03029BR221BJZL7292: DescriptionCeramic Capacitor, Multilayer, Ceramic, 100V, 5% +Tol, 5% -Tol, BR, -/+15ppm/Cel TC, 0.00022uF, 0402,; CategoryPassive components capacitor; File Size476KB，4 Pages; ManufacturerKEMET; Websitehttp://www.kemet.com

Download Datasheet Parametric View All

03029BR221BJZL7292 Overview

Ceramic Capacitor, Multilayer, Ceramic, 100V, 5% +Tol, 5% -Tol, BR, -/+15ppm/Cel TC, 0.00022uF, 0402,

03029BR221BJZL7292 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	275410382
package instruction	, 0402
Reach Compliance Code	not_compliant
ECCN code	EAR99
YTEOL	8.83
capacitance	0.00022 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.61 mm
JESD-609 code	e0
length	1.02 mm
multi-layer	Yes
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package form	SMT
method of packing	Waffle Pack
positive tolerance	5%
Rated (DC) voltage (URdc)	100 V
Guideline	MIL-PRF-55681
size code	0402
Temperature characteristic code	BR
Temperature Coefficient	15% ppm/°C
Terminal surface	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
width	0.51 mm

Preview

Download Datasheet

View All

Surface Mount Multilayer Ceramic Chip Capacitors

DSCC Approved 03029 (BR/BX Dielectrics)

Overview

KEMET is approved to DSCC (Defense Supply Center, Columbus)

drawing no. 03029 for surface mount EIA 0402 case size multi-

layer ceramic capacitors (MLCCs) in BR and BX dielectrics.

DSCC MLCC control drawings are managed by the Defense

Logistics Agency (DLA) and represent devices with case sizes,

voltage ratings, and capacitance offerings not currently refer-

enced in a valid military specification. Approved devices must

meet the stringent requirements, specifications and standards

outlined by DSCC.

DSCC drawing no. 03029 was developed in response to the

growing need and demand within the defense and aerospace

industries for EIA 0402 case size MLCCs not currently offered

in MIL-PRF-55681. KEMET’s DSCC approved capacitors meet

the requirements, specifications and standards outlined in

drawing no. 03029 as well as all referenced provisions per MIL-

PRF-55681.

Benefits

• EIA 0402 case size

• Defense Supply Center, Columbus approved

• Federal Stock Control Number, Cage Code 31433

• Meets US Department of Defense (USDoD) specifications

per MIL-PRF-55681

• Meets USDoD standards per MIL-STD 202 & MIL-STD-1285

• High reliability

• Surface mount device

• Non-polar

Applications

Typical

applications include decoupling, bypass, filtering, blocking

and energy storage for use in military and aerospace applications.

Outline Drawing

70Sn/30Pb

Nickel Plate

Conductive Metallization

Electrodes

Dimensions - Millimeters (Inches)

EIA SIZE

CODE

0402

METRIC

SIZE CODE

1005

LENGTH^

WIDTH^

BANDWIDTH

THICKNESS

Maximum

0.61 (.024)

1.02 (.040) ± 0.10 (.004) 0.51 (.020) ± 0.10 (.004) 0.25 (.010) ± 0.15 (.006)

^For symbol “U” termination add .20 inches (0.51mm) to the positive length tolerance and .015 inches (0.38mm) to the positive width and thickness tolerances.

Ordering Information

DSCC Drawing

Number

03029 (0402 case size)

03029

Dielectric

Capacitance

Code (pF)

2 Sig. Digits +

Number of

Zeros

222

Voltage

W = 6.3V

X = 10V

Y = 16V

Z = 25V

A = 50V

B = 100V

C = 200V

Capacitance

Tolerance

J = ±5%

K = ±10%

M = ±20%

End

Metallization^

U = SnPb (4%min)

Z = SnPb (4%min)

Blank = No group C testing

C = Full group C

L = 2,000 hour life test only

M = 1,000 hour life test only

H = Low voltage humidity only

Group C

Testing Option

Blank = Bulk Bag

Packaging/Grade

(C-Spec)*

7189

7246 = Anti-Static Bulk Bag

7292 = Waffle Pack

7189 = 7” Reel Marked

^ “U” = Base metallization-barrier metal-solder coated (tin/lead alloy, with a min of 4% lead). Melting point is +200ºC or less. Metallization thickness is ≥ 60µ-inches.

^ “Z” = Base metallization-barrier metal-tinned (tin/lead alloy, with a min of 4% lead).

* Additional reeling or packaging options may be available. Contact KEMET for details.

Additional termination options may be available. Contact KEMET for details.

F4003_L 10/13
