flat cable clamp
WITH FULL OUTER ENCLOSURE AND ADHESIVE MOUNT.
Ferrite
B
assembly in fully enclosed nylon case for flat cables up to 64-conductor width.
Internal grip-lock tabs apply pressure on cable to maintain mounting position.
Very effective from 1 MHz to 60 MHz with a peak attenuation at 30 MHz. For
C
typical impedance curve comparisons to other material formulations, see page
37; and for specific impedance curves see page 36, bottom.
Installs easily on any mounting surface by removing liner from foam adhesive
base pad. Also available without the adhesive mounting pad for assembly with
two flat head screws through the .120” (3,0
mm)
diameter holes on 1.25” (31,8
Adhesive pad
mm)
centers in the bottom by temporarily removing the lower ferrite half.
D
PART No.
RA33B2480
RA33B4340
w/o Adhesive
RC33B2480
RC33B4340
A
.700
17,8
.785
19,9
B
2.76
70,1
4.61
117,1
C
1.312
33,3
1.312
33,3
D
.060
1,5
.104
2,6
E
A
Adhesive pad
B
C
E
A
D
E
2.047
52,0
3.240
82,3
IMPEDANCE IN OHMS
31 @ 30 MHz
79 @ 30 MHz
For specific performance by part number, find the alpha-numeric designation on the charts below according to the last
seven digits of each catalog part number; i.e., for part number “CS28B1937” see “28B1937” on the chart.
TYPICAL PERFORMANCE
1000
IMPEDANCE (Ω)
100
10
1
1M
10M
100M
FREQUENCY (Hz)
1G
33B4340
33B2480
33B2032/2036/2040
33B2035
33B0984/1984
