Coupling nut
Thread A
19 0,25
Housing : Zinc alloy nickel plated
Coupling Nut : Aluminium alloy, nickel plated
Insert : PA 66 UL94 V0
Coupling spring : Stainless steel
O'ring : Nitril
Operating temperature : -40 C up to 105 C
Insulation resistance : 5000 M min
Withstanding voltage: 2000Vrms
(1500 Vrms for 102w2 and 103w3 layouts)
Corrosion salt spray : 48 hours or 96 hours ( spéc. 02 )
Durability : 500 matings and unmatings
Sealing in mated conditions : IP67 / IP68 3 bars/30min as per IEC60529
( depending on counterpart used )
Sealing in mated conditions : IP69K as per DIN40050
ROHS compliant
-1- Contact identification and orientation of connector, refer to :
UT0-CONTACT-L-C01 (Male)
UT0-CONTACT-L-C02 (Female)
-2- Contact to be ordered separately refer to : UT0 catalog
-3- This drawing covers p/n termination : -H / -H6
-4- Packaging: connector is individually packed in a plastic bag
MATERIAL :
8
8
7
6
Insert
PERFORMANCE CHARACTERISTICS :
7
Housing
O-seal
Part Number
(Note 3)
UT06102W2--H-
UT06103W3--H-
UT06103--H-
UT06104--H-
UT061044--H-
UT06124--H-
UT06128--H-
UT06142G1--H-
UT06147--H-
UT06148--H-
UT061412--H-
UT061492--H-
UT061619--H-
UT061823--H-
UT062028--H-
UT062030--H-
UT062235--H-
UT062238--H-
UT062448--H-
Thread A
for information
COUPE
E-E
NOTES :
Coupling spring
D Max
Male
Female
35
33
35
27
6
B
0.15
C
0.20
E 0.20
10.15
9/16-24 UNEF Class 2A
20.00
21.80
33
25.5
13.10
34
33
34
25.5
33
16.40
Receptacle UT0 :
Type 6
Shell size :
Insert arrangement :
See Note 1
UT06 10 2W2 P
W
H
02
5
5
4
3
2
1
11/16-24 UNEF Class 2A
23.60
26.10
13/16-20 UNEF Class 2A
26.80
29.30
35
Contact :
P : Male
S : Female
Insert polarisation :
No letter : Standard version
W, X, Y, Z : Differents orientation
Sealing version :
4
15/16-20 UNEF Class 2A
1" 1/16-18 UNEF Class 2A
1" 3/16-18 UNEF Class 2A
1" 5/16-18 UNEF Class 2A
1" 7/16-18 UNEF Class 2A
30.00
33.30
36.55
39.50
42.60
32.45
35.25
38.80
42.00
45.05
33
25.5
H : IP67 version
No letter : Standard version
02 : Coupling nut is black anodized
3
19.50
21.65
24.80
Sealing version :
27.5
27.99
31.16
MALE CONNECTOR
PIN (P)
FEMALE CONNECTOR
SOCKET (S)
A
ISS
20/04/2015
DATE
_CREATION OF THE DRAWING
_Cancel & replace UT06-C01
Latest modification - by:
COUTY L.
Date: 21/10/2013
COUTY L.
24021
Designed by:
CUSTOMER DRAWING
MOD N
2
TITLE
Scale
2/1
PLUG
UT0 PLUG CONNECTOR
General linear
Tolerances:
0.1
NPRDS / PROJECT
UT0
This document is the property of
SOURIAU
It must not be reproduced or
communicated without permission
SHEET
1 / 1
WWW.SOURIAU.COM
FORMAT
1
A2
H
G
F
E
D
C
SOURIAU DRG N°
C001-UT06-A
B
A
CLASSIFICATION:
NOT EXPORT CONTROLLED
