FMZ
CONNECTOR
1.0mm
(.039") pitch
Connectors for FFC
Features ––––––––––––––––––––––––
• Zero insertion force mechanism
A ZIF mechanism increases wear resistance and extends the
connector's mating life. By moving the slide into its locking
position after an FFC is inserted into the connector with a low
insertion force, the FFC leads are securely locked in place.
• Temporary retention feature
After the FFC is inserted, but before the locking slide is
actuated, a retention feature prevents the FFC leads from
moving or coming out. This allows one handed operation and
higher work efficiency.
• Compact
This connector is very small with a mounting height of only
6.5mm (.256") and a thickness of 4.2mm (.165") when locked.
• Double-leaf contact
The FMZ series, a Zero Insertion Force
(ZIF) connector series, was developed to
increase wear resistance and extend the
connector's mating life. It is a very
compact connector with a thickness of
only 4.2mm (.165") and a pitch of only
1.0mm (.039") and is thus useful for high
density packaging. The contact has a
reliable double-leaf construction which
provides stable connection.
The slide mechanism and FFC are held and locked between
the contact beams. This eliminates stress to the housing,
provides high contact pressure and reliable connection.
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance:
800M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable FFC : Lead pitch /1.0mm(.039")
Lead width /0.7mm(.028")
Mating part thickness /
8 to 10, 12 to 16, 20 circuits:
0.30 ± 0.05mm(.012"± .002")
22, 26, 28, 30 circuits:
0
0"
0.30
+0.05
mm(.012"
+.002"
)
• Applicable PC board thickness: 0.8 to 1.6mm(.031" to .063")
<Note
>
FFC to be actually used should be checked for applicability.
* Contact JST for details.
Standards ––––––––––––––––––––––
404
0
1
Recognized E60389
Certified LR20812
FMZ
CONNECTOR
Connector –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
B
3.95(.159)
Cir-
cuits
6
8
6.5(.256)
When locked
8.0(.315)
Model No.
Top entry
type
06FMZ-BT
08FMZ-BT
09FMZ-BT
10FMZ-BT
12FMZ-BT
13FMZ-BT
14FMZ-BT
15FMZ-BT
16FMZ-BT
20FMZ-BT
22FMZ-BT
26FMZ-BT
28FMZ-BT
30FMZ-BT
Side entry
type
–
Dimensions mm(in.)
A
5.0( .197)
7.0( .276)
8.0( .315)
9.0( .354)
Q'ty / box
Top entry Side entry
type
type
1,440
1,440
960
960
960
960
960
780
800
720
720
480
480
480
–
800
600
600
600
600
600
600
400
400
400
300
300
400
B
12.0( .472)
14.0( .551)
15.0( .591)
16.0( .630)
18.0( .709)
19.0( .748)
20.0( .787)
21.0( .827)
22.0( .866)
26.0(1.024)
28.0(1.102)
32.0(1.260)
34.0(1.339)
36.0(1.417)
08FMZ-ST
09FMZ-ST
10FMZ-ST
9
10
12
13
14
15
16
20
22
26
12FMZ-ST
11.0( .433)
13FMZ-ST
12.0( .472)
14FMZ-ST
13.0( .512)
15FMZ-ST
14.0( .551)
16FMZ-ST
15.0( .591)
20FMZ-ST
19.0( .748)
22FMZ-ST
21.0( .827)
26FMZ-ST
25.0( .984)
28FMZ-ST
27.0(1.063)
30FMZ-ST
29.0(1.142)
Circuit No.1
1.0(.039)
3.05
(.120)
A
2.35
(.093)
2.0
(.079)
4.2(.165)
1.0(.039)
2.7
[
(.107)
[
Side entry type
B
A
1.0(.039)
JST
28
30
Material and Finish
8.0(.315)
6.5(.256)
When locked
3.95(.156)
4.2(.165)
3.5(.138)
Contact: Phosphor bronze, tin-plated
Housing: Glass-filled PBT, UL94V-0
Circuit No.1
[6.2(.244)]
when locked
2.0
(.079)
Lead section dimensions of FFC ––––––––––––––––––––––––––––––––––––––––––––
[1.0(.039)x (Number of circuits + 1)]± 0.12(.005)
1.0
±
0.15
1.0
±
0.15 [1.0(.039)x (Number of
(.039
±
.006) circuits - 1)]± 0.1(.004) (.039
±
.006)
0.7
±
0.1
1.0
±
0.1
(.039
±
.004)
(.028
±
.004)
8 to 20 circuits: 0.30
±
0.05
(.012
±
.002)
22 to 30 circuits: 0.30 to 0.35
(.012 to .014)
2.7
[
(.106)
[
5.0
(.197)
min.
Conductor
Cover layer
7.5(.295)
Reinforcing layer
Base layer
