T-1 3/4 Clear Lens LED Lamps
DESCRIPTION AND FEATURES
All dimensions in inches.
.190±.010
.340±.010
.040
These non-diffused LED lamps offer high brightness in multiple colors
and are designed for backlighting.
The High Efficiency Red and Yellow lamps are produced with GaAsP/GaP
and the High Efficiency Green lamp is produced with GaP/GaP.
This compact, rugged and lightweight LED lamp requires low power
and allows for versatile PC board or panel mounting.
All devices are available with either cathode long or anode long
configurations.
1.00
MIN.
.020±.003
S Q.T Y P .
.050
C AT HODE
Ø.230
.100
ELECTRO-OPTICAL CHARACTERISTICS AND RATINGS
C MD5152* C MD5352*
P AR T NUMB E R
Y ellow
H.E . R ed
Output C olor
Non-Diffused Diffused
Diffusion
Y ellow
Amber
P ackage C olor
20
20
T est C urrent (mA)
2.1
2.0
F orward Voltage Typ. (V)
3.0
3.0
F orward V oltage Max. (V )
10.0
17.0
Luminous Intensity Min. (mcd)
100.0
90.0
Luminous Intensity T yp. (mcd)
45
45
C apacitance pF V r=0, F =1MHz
P eak Wavelength (nm)
585
635
28
28
Viewing Angle 20 1/2 (degrees)
120
120
P ower Dissipation (mW)
Operating Temperature (°C )
-55 to +100 -55 to +100
-55 to +100 -55 to +100
S torage T emperature (°C )
P eak Forward C urrent Max. (1µs @ 0.3% duty cycle) (mA)
1000
1000
R everse V oltage (IR =100µA) (V )
5
5
Lead S older T ime @ 260°C
5
5
C MD5452* C MD5752* C MD6152 C MD6352
H.E .G reen H.E . R ed
H.E . R ed
Y ellow
Diffused
Diffused
Diffused
Diffused
Y ellow
G reen
R ed
Amber
20
20
20
20
2.1
2.2
2.0
2.0
3.0
3.0
3.0
3.0
10.0
12.0
17.0
17.0
90.0
25.0
100.0
100.0
45
20
45
45
585
562
635
635
28
35
28
28
120
120
120
120
-55 to +100 -55 to +100 -55 to +100 -55 to +100
-55 to +100 -55 to +100 -55 to +100 -55 to +100
1000
90
1000
1000
5
5
5
5
5
5
5
5
C MD64520
H.E .G reen
Diffused
G reen
20
2.2
3.0
12.0
25.0
20
562
35
120
-55 to +100
-55 to +100
90
5
5
C MD64521 C MD6752
H.E .G reen H.E . R ed
Diffused
Diffused
R ed
G reen
20
20
2.0
2.2
3.0
3.0
17.0
30.0
100.0
100.0
45
20
635
562
28
35
120
120
-55 to +100 -55 to +100
-55 to +100 -55 to +100
1000
90
5
5
5
5
* c a t hode long
