SCW Series: Instrument Laser Modules
Wavelengths: 1310nm, 1550nm,
1625nm and 1650nm
High Peak Optical Power:
100 to 180mW @ 1000mA
Pw = 10 us
Duty Cycle = 1%
RoHS Compliant
Typical Applications*:
OTDR Instruments
Spectroscopy
Photon Counting
Optical Sensors
Talk Sets
*Options: Temperature controlled or
uncooled versions available.
Custom packaging available
Laser Diode Incorporated’s High Power SMF coupled laser modules are designed to meet the performance
demands of the optical test equipment marketplace. The high peak optical power SCW Series lasers serve
1310nm through 1650nm wavelengths and are available in fully hermetic laser welded 14 pin DIP or 14 Pin
Butterfly packages or a 3 pin coaxial package. The 14 pin packaged lasers can include both TEC and
temperature sensing thermistors for superior wavelength stability over a wide temperature range.
Characteristics w/TEC:
w/o TEC:
Parameters
Optical Power (Fiber)
Forward Current
Threshold Current
Forward Voltage
Center Wavelength
Spectral Width (RMS)
Cooling Capacity*
TEC Voltage*
TEC Current*
Operating Temperature
Range
Storage Temperature
Range
*Cooled Modules Only
Reliability data available upon request
T
a
= -30 to 70 C; T
Id
= +25 C
T
a
= +25 C
Symbol
1330 Series
Min
Typ
Max
120
1000
30
2
1290
45
1.2
600
-30
-40
1.6
800
70
85
-30
-40
1310
1330
8
45
1530
o
o
o
o
Conditions: Pw = 10
μs;
D/C = 1%
1530 Series
Min
Typ
Max
100
1000
35
2
1550
1570
10
1630 Series
Min
Typ
Max
100
1000
45
2
1615
45
1625
1635
12
1650 Series
Min
Typ Max
100
1000
45
2
1640
45
1650 1665
12
1.2
600
-30
-40
1.6
800
70
85
Units
mW
mA
mA
V
nm
nm
o
P
I
f
I
th
V
f
λ
Δλ
ΔΤ
V
tec
I
tec
T
op
T
stg
C
V
1.2
600
1.6
800
70
85
-30
-40
1.2
600
1.6
800
70
85
mA
o
C
C
o
LDI Document #10-4400-0034 Rev. B 1/13/09
14-pin Butterfly Package and 14-pin DIP Package F Series and G Series
F Series (Floating Thermistor)
Pin
Function
1
cooler anode (+)
2,3,4,6,7,8,13
no connection
5
laser anode (+), ground
9
laser cathode (-)
10
ground
11,12
thermistor
14
cooler cathode (-)
G Series (Ground Thermistor)
Pin
Function
1
cooler anode (+)
2,3,4,6,7,8,12,13
no connection
5
laser anode (+), ground
9
laser cathode (-)
10
ground, thermistor
11
thermistor
14
cooler cathode (-)
*
*
*
*
*
*
*Cooled Package Only. No connection for uncooled pkg.
14-pin Butterfly Package
14-Pin DIP Package
TOP VIEW
BOTTOM VIEW
Coaxial Package
PIN
1
2
3
Function
Laser cathode (-)
Laser anode (+)/ Ground
No Connection
Detailed package drawings are available upon request.
