XT57C
Vishay Dale
Quartz Crystals
FEATURES
• Miniature size: 7.0 x 5.0 x 1.1 (mm)
• Wide frequency range
• Seam sealing
• Emboss taping
• Compliant to RoHS directive 2002/95/EC
The XT57C is a miniature SMD crystal with 7.0 x 5.0 ceramic
package and a height of 1.1 mm maximum. 9.8304 MHz to
100 MHz frequency makes it widely applied in notebook
computer, PCMCIA, and communication equipment.
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency range
Frequency tolerance
Temperature stability
Operating temperature range
Storage temperature range
Shunt capacitance
Load capacitance
Insulation resistance
Drive level
Aging (first year)
SYMBOL
F
O
ΔF/F
O
T
C
T
OPR
T
STG
C
0
C
L
I
R
D
L
Fa
at 25 °C, per year
customer specified
100 V
DC
at 25 °C
ref. to 25 °C
CONDITION
UNIT
MHz
ppm
ppm
°C
°C
pF
pF
MΩ
μW
ppm
MIN.
9.8304
± 10
± 10
- 10
- 40
-
10
500
-
-5
TYP.
-
± 30
± 30
-
-
-
-
-
100
-
MAX.
100.000
± 50
± 50
+ 60
+ 85
7
series
-
300
+5
EQUIVALENT SERIES RESISTANCE (ESR) AND MODE OF VIBRATION (MODE)
FREQUENCY RANGE (MHz)
9.8304 to 15.999
16.000 to 39.999
40.000 to 83.999
84.000 to 100.000
MAX. ESR (Ω)
60
40
60
80
MODE
fundamental
fundamental
3
rd
overtone
3
rd
overtone
DIMENSIONS
in inches [millimeters]
0.276 ± 0.006
[7.00 ± 0.15]
0.039 ± 0.005
[1.0 ± 0.13]
0.047 [1.20]
1
4
2
3
Recommended
Solder
Pattern
0.061 ± 0.005
[1.54 ± 0.13]
0.055
[1.4]
0.087 0.157 0.087
[2.2] [4.0] [2.2]
0.055 [1.4]
0.043 [1.1]
MARKING
AREA
0.197 ± 0.006
[5.0 ± 0.15]
0.181 ± 0.005
[4.60 ± 0.13]
0.043 [1.1 max.]
Note
Pin #2 and pin #4 are connected through cover, in case
connected to
GND.
Frequency might be drifted.
Document Number: 35013
Revision: 18-Oct-07
For technical questions, contact:
frequency@vishay.com
www.vishay.com
1
