XFMRS
COMMON MODE CHOKES
• SUPERIOR MATERIALS / HIGH IMPEDANCE TO MINIMIZE COMMON MODE NOISE
• APPLICATIONS INCLUDE FDDI-TP, TOKEN RING, ETHERNET/10BASE T, ISDN,
T1/CEPT, FAST ETHERNET AND MOST TELECOMMUNICATIONS APPLICATIONS
• 2000 VRMS ISOLATION AVAILABLE
• OTHER PACKAGE STYLES AVAILABLE; E-E, U-U, IEC/TUV DESIGNS
• CUSTOM DESIGNS AVAILABLE AT NO EXTRA COST
1
PART
NUMBER
OCL
(uH ±20%)
PRI/SEC
L
L
(uH MAX)
PRI/SEC
Cw/w
(pF MAX)
PRI/SEC
DCR
(OHMS MAX)
ISOLATION
(VRMS)
PACKAGE/
SCHEMATIC
XF0306AA
XF0306AB
XF0506AA
XF0506AB
XF0756AA
XF0756AB
XF0856AA
XF0856AB
XF1006AA
XF1006AB
XF1506AA
XF1506AB
XF2006AA
XF2006AB
XF0306AE
XF0506AE
XF0756AE
XF0856AE
XF1006AE
30
30
50
50
75
75
85
85
100
100
150
150
200
200
30
50
75
85
100
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.12
0.12
0.12
0.12
0.10
0.10
0.10
0.10
0.10
8
8
8
8
8
8
10
10
10
10
15
15
15
15
8
8
8
10
10
0.10
0.10
0.15
0.15
0.15
0.15
0.17
0.17
0.20
0.20
0.23
0.23
0.30
0.30
0.10
0.10
0.15
0.15
0.15
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
A/A
B/A
A/A
B/A
A/A
B/A
A/A
B/A
A/A
B/A
A/A
B/A
A/A
B/A
A/E
A/E
A/E
A/E
A/E
XFMRS
XFMRS, INC.
