Push-In |
Spacing 3.81 mm
AKZ4701/..KD-3.81-V-BASALTGREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PBT
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
10.12
13.93
17.74
21.55
25.36
29.17
32.98
36.79
40.60
44.41
48.22
Article Designation
AKZ4701/2KD-3.81-V-BASALTGREY
AKZ4701/3KD-3.81-V-BASALTGREY
AKZ4701/4KD-3.81-V-BASALTGREY
AKZ4701/5KD-3.81-V-BASALTGREY
AKZ4701/6KD-3.81-V-BASALTGREY
AKZ4701/7KD-3.81-V-BASALTGREY
AKZ4701/8KD-3.81-V-BASALTGREY
AKZ4701/9KD-3.81-V-BASALTGREY
AKZ4701/10KD-3.81-V-BASALTGREY
AKZ4701/11KD-3.81-V-BASALTGREY
AKZ4701/12KD-3.81-V-BASALTGREY
Article Number
54701020421F
54701030421F
54701040421F
54701050421E
54701060421E
54701070421E
54701080421D
54701090421D
54701100421D
54701110421D
54701120421D
PU
200
200
200
100
100
100
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 0.34 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Clamp Spring
Brass
Stainless Steel
7.0 mm
1.4 mm
Colours
BASALT GREY
GREEN
LIGHT GREEN
RAL7012
RAL6018
similar RAL 6018
RAL7012
RAL6018
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Ratings
*
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
6A
AWG 26-16
AWG 26-16
1.6 kV
C
-
-
-
-
-
D
300 V
6A
AWG 26-16
AWG 26-16
1.6 kV
min
0.2 mm²
0.2 mm²
2.0 kV
250 V
12 A
*
max
1.5 mm²
1.5 mm²
* Approval Pending
