308 Series SC
Fiber Optic Connectors
FEATURES
SC Duplex Multimode
Connecter C3-208-3
M
ethode
®
308 Series SC
connector products are
designed and manufactured
to meet JIS, IEC EIA/TIA and ANSI
specifications for intermateability and
optical performance. This Methode
SC connector features a unique grip
housing and a pre-assembled plug
body for easy termination.
The duplex clip positions two SC
connector ferrules on 0.5” (12.7mm)
centers. The duplex configuration is
compliant with ANSI X3T11 Fibre
Channel specifications.
This Methode SC connector has
unsurpassed float and duplex
plugging characteristics. Our 308
Series SC connectors are installed
using Methode 900 Series universal
termination tooling and consumables.
The Universal Polishing Disk can
handle up to four (4) simplex SC plugs
at one time. When combined with the
Methode Quick-Cure™ adhesive
system, connector termination takes
less than two (2) minutes.
s
Pull proof
s
Meets ISO/IEC
11801 and TIA 568A
performance standards.
s
Pre-assembled option
PERFORMANCE CHARACTERISTICS*
s
Insertion Loss* (dB):
Multimode
≤
0.2
Single mode
≤
0.2
≤
0.1 dB
0.35 (8.9)
2.43
(61.72)
simplifies field
termination
s
Polymer ferrules available
s
Durability (500 cycles):
3mm Boot
1.70
(43.18)
s
Temperature Range:
for a variety of fiber sizes
s
Pre-radiused ceramic
Operating:
-40° to 85°C
900 Micron Boot
*Typical at 850 nm wavelength using
62.5/125 micron fiber
ferrules configured for
“Ultra” and “Super” PC
Polishing
s
Bend relief boots meet
Dimensions: inches (mm)
MATERIALS
s
Grip and Plug Body:
Thermoplastic
s
Boot:
Thermoplastic Rubber
Bellcore TR-NWT-000326
side load specification
s
Terminates with same
(reinforced, flame retardant)
s
Rear Body:
Zinc alloy, nickel plated
s
Crimp Sleeve:
Brass, tin plated
(flame retardant)
s
Ferrule:
Zirconia Ceramic or
Polymer
s
Dust Cover:
Vinyl
tools as ST
®
and FC
s
Duplex clip available
ORDERING INFORMATION
SC Duplex Clip
Dust Cover w/lanyard
COLOR
Black
Black
PART NO.
308-107-3092
900-111-2006
separately
s
Dust Cover with lanyard
(optional) stays with the
connector
SIMPLEX
PART NUMBER
D3-004-3
D3-204-3
C3-A04-1
COLOR
GRIP
Black
Beige
Green
Blue
Black
Beige
FIBER SIZE
BOOT (MICRON)
Black
Black
Green
Yellow
Black
Black
62.5/125
62.5/125
9/125
9/125
62.5/125
62.5/125
FERRULE
MATERIAL
MODE
Polymer
Polymer
Ceramic
Ceramic
Ceramic
Ceramic
Multimode
Multimode
APC
Single mode
Multimode
Multimode
FO2005-8190
The Americas
7444 W. Wilson Avenue
Chicago, IL 60656 U.S.A.
708.867.9600 Fax: 708.867.9621
C3-004-1
C3-004-3
C3-204-3
Individually packaged, add ”-B“ suffix to part number for bulk packaging
800.323.6858
www.methode.com
308 Series SC Couplings and
Hybrid Adapters
.368 (9.3) Max
FEATURES
SC/ST
®
Multimode
Hybrid Adapters
.869 (22.0)
Max
1.092 (27.7)
Max
.120
(3.1)
Max
.503
(12.8)
Max
Latch
Housing
0.370
(9.4)
0.510
(2.9)
.708
(18.1)
308-294-03 Duplex
308-292-03 Simplex
SC Simplex
Coupling
0.368
(9.3)
Max
0.07 (1.78)
Maximum
Panel Thickness
1.092
(27.7)
Max
Ø.095
(2.4) Ref Dia
Recommended
Panel Cut Out
(Minimum)
s
SC to SC, FC and ST
®
s
Simplex and duplex
0.90 Dia
(2.3)
0.370
(9.4)
.120
(3.1) Max
1.208
(30.7)
1.022
(25.9)
panel cutouts
installation
s
Panel clip for easy
s
Available in several
1.377
(34.9)
Max
0.5
(12.7)
1.020
(25.9) Max
standard colors
s
Available without
SC Duplex
Coupling
Identical panel cutout for all duplex SC hybrid
adapters and couplings
flanges, call factory for
part number
0.070 (1.78)
Maximum
Panel Thickness
Ø.095
(2.4) Ref Dia
Recommended
Panel Cut Out
(Minimum)
Dimensions: inches (mm)
COUPLING AND ADAPTER PART NUMBERS
Alignment Sleeve
Application Material
COLOR
1 =NTT BLUE
2 =BLACK
3 =BEIGE
7 =GREEN (APC)
1 = SM
2 = SM/MM
3 = SM/MM
ZIRCONIA CERAMIC
PHOSPHOR BRONZE
POLYMER
MATERIALS
s
s
Body, Latch and
Dust Caps:
Thermoplastic
(flame retardant)
Clip:
Spring Steel
Style
2 = SIMPLEX
4 = DUPLEX
SC to
Individually packaged, add ”-B“ suffix to part number
for bulk packaging.
0 - SC
4 - FC
7 - FC/APC
9 - ST
®
SC/FC Multimode
Hybrid Adapters
CONNECTOR TERMINATION TOOLS & ACCESSORIES
Universal Termination Kit with oven, 110V*
308-144-03 Duplex
308-142-03 Simplex
900-118-3010
900-118-3014
900-118-1404
900-118-9024
900-118-9030
900-118-9017
Universal Termination Kit with oven, 220V*
Universal Polishing Disk
Quick-Cure™ Anaerobic Consumables Kit ( completes 200 terminations)
Quick-Cure™ Anaerobic Adhesive
Consumables Replacement Kit (100 terminations)
The Americas
7444 W. Wilson Avenue
Chicago, IL 60656 U.S.A.
708.867.9600 Fax: 708.867.9621
*110V - USA and Canada, 220V - Europe,
