BC817-16
THRU
BC817-40
NPN Small
Signal Transistor
310mW
SOT-23
A
D
Features
•
•
•
•
•
•
•
•
Halogen
free available upon request by adding suffix "-HF"
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
Ideally Suited for Automatic Insertion
150 C Junction Temperature
For Switching and AF Amplifier Applications
Epitaxial Planar Die Construction
Mechanical Data
•
•
•
•
•
Case: SOT-23, Molded Plastic
Terminals: Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 0.008 grams ( approx.)
Marking:
BC817-16
BC817-25
BC817-40
6A
6B
6C
G
K
F
C
B
C
B
E
E
Maximum Ratings @ 25
o
C Unless Otherwise Specified
Charateristic
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Peak Collector Current
Peak Emitter Current
Power Dissipation@T
s
=50
o
C(Note1)
Operating & Storage Temperature
Symbol Value
V
45
CEO
V
EBO
I
C
H
J
Unit
V
V
mA
mA
mA
mW
o
DIM
A
B
C
D
E
F
G
H
J
K
DIMENSIONS
INCHES
MIN
MAX
.110
.120
.083
.104
.047
.055
.035
.041
.070
.081
.018
.024
.0005
.0039
.035
.044
.003
.007
.015
.020
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
NOTE
5
500
1000
1000
300
I
CM
I
EM
P
d
T
j
, T
STG
-55~150
2
C
Suggested Solder
Pad Layout
.031
.800
.035
.900
.079
2.000
inches
mm
Note:
1.
Device mounted on Ceramic Substrate 0.7mm X 2.5cm area
.037
.950
.037
.950
www.mccsemi.com
Revision:
C
1 of 4
2013/06/04
BC817-16 thru BC817-40
Electrical Characteristics
Parameter
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Base-emitter saturation voltage
Base-emitter voltage
Collecter capactiance
Transition frequency
@25°C unless otherwise specified
MCC
TM
Micro Commercial Components
Symbol
V
CBO
V
CEO
V
EBO
I
CBO
I
EBO
h
FE(1)
h
FE(2)
V
CE(sat)
V
BE(sat)
V
BE
C
ob
f
T
Test conditions
I
C
= 10μA, I
E
=0
I
C
= 10mA, I
B
=0
I
E
= 1μA, I
C
=0
V
CB
= 45 V , I
E
=0
V
EB
= 4V, I
C
=0
V
CE
= 1V, I
C
= 100mA
V
CE
= 1V, I
C
= 500mA
I
C
= 500mA, I
B
= 50mA
I
C
= 500mA, I
B
= 50mA
V
CE
= 1 V, I
C
= 500mA
V
CB
=10V ,f=1MHz
V
CE
= 5 V, I
C
= 10mA
f=100MHz
Min
50
45
5
Typ
Max
Unit
V
V
V
μA
μA
0.1
0.1
100
40
0.7
1.2
1.2
10
100
600
V
V
V
pF
MHz
CLASSIFICATION OF
h
FE
(1)
Rank
Range
BC817-16
100-250
BC817-25
160-400
BC817-40
250-600
400
See Note 1
P
d
, POWER DISSIPATION (mW)
300
200
100
0
0
100
50
150
T
JA
, Junction to Ambient Air
(°C)
200
°
www.mccsemi.com
Revision:
C
2 of 4
2013/06/04
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel;3Kpcs/Reel
