05177
DALC112S1
Only One Name Means ProT
ek’Tion™
STEERING DIODE ARRA
Y
APPLICA
TIONS
✔
Ethernet - 10/100/1000 Base T
✔
Cellular Phones
✔
Handheld Electronics
✔
FireWire
✔
USB Interface
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 12A, 8/20µs - Level 1(Line-Gnd) & Level 2(Line-Line)
FEA
TURES
✔
ESD Protection > 40 kilovolts
✔
Low Clamping Voltage
✔
Provides Six (6) Lines of Protection
✔
LOW LEAKAGE CURRENT < 200nA
✔
ULTRA LOW CAPACITANCE: 5pF Typical
✔
RoHS Compliant on Lead-Free Versions
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SO-8
✔
Weight 70 milligrams (Approximate)
✔
Available in Tin-Lead or Lead-Free Pure-Tin Plating(Annealed)
✔
Solder Reflow Temperature:
Tin-Lead - Sn/Pb, 85/15: 240-245°C
Pure-Tin - Sn, 100: 260-270°C
✔
Flammability Rating UL 94V-0
✔
12mm Tape and Reel Per EIA Standard 481
✔
Marking: Marking Code, Logo, Date Code & Pin One Defined By Dot on Top of Package
SO-8
PIN CONFIGURA
TION
REF 1
I/O 6
REF 2
I/O 5
8
7
6
5
1
I/O 1
2
I/O 2
3
I/O 3
4
I/O 4
05177.R2 3/05
1
www.protekdevices.com
DALC112S1
DEVICE CHARACTERISTICS
MAXIMUM RATINGS @ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
Continuous Power Dissipation
SYMBOL
T
J
T
STG
P
PC
VALUE
-55°C to 150°C
-55°C to 150°C
145
UNITS
°C
°C
mW
ELECTRICAL CHARACTERISTICS PER LINE @ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
REPETITIVE
PEAK
REVERSE
VOLTAGE
TYPICAL
FORWARD
VOLTAGE
MAXIMUM
PEAK PULSE
FORWARD
CURRENT
8/20µs
I
FM
AMPS
12
MAXIMUM
REVERSE
LEAKAGE
CURRENT
V
RRM
@18V
I
R
nA
20
MAXIMUM
QUIESCENT
SUPPLY
CURRENT
@20V
I
RQ
nA
200
TYPICAL
CAPACITANCE
V
RRM
VOLTS
DALC112S1
PSC
20
@50mA
V
F
VOLTS
1.3
@0V, 1 MHz
Cj
pF
5
FIGURE 1
NON-REPETITIVE PEAK PULSE CURRENT CAPABILITY
8
I
PP
- Peak Pulse Current - % of I
PP
Peak Pulse Current - Amps
120
100
80
60
40
20
0
t
f
FIGURE 2
PULSE WAVE FORM
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
6
e
-t
4
2
t
d
= t I /2
PP
0
0.001
0.01
0.1
1
Square Wave Pulse - ms
10
100
0
5
10
15
t - Time - µs
20
25
30
05177.R2 3/05
2
www.protekdevices.com
DALC112S1
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
-A-
SO-8
8
5
-B - P
0.010 (0.25 MM) M B M
4 PL
+
PACKAGE DIMENSIONS
DIM
A
B
C
D
F
G
J
K
P
R
NOTES
1.
2.
3.
4.
5.
6.
- T - = Seating Plane and Datum Surface.
Dimensions “A” and “B” are Datum.
Dimensions “A” and “B” do not include mold protrusion.
Maximum mold protrusion is 0.015” (0.380 mm) per side.
Dimensioning and tolerances per ANSI Y14.5M, 1982.
Dimensions are exclusive of mold flash and metal burrs.
1
4
MILLIMETERS
MIN
MAX
4.80
3.80
1.35
0.35
0.40
1.27 BSC
0.18
0.10
5.80
0.25
INCHES
MIN
MAX
G
D
C
R x 45°
0° - 10°
K
0.010 (0.25 MM) M T B S A S
+
8 PL
0.050 ± 0.005
-T-
J
F
5.00
0.189
0.196
4.00
0.150
0.157
0.054
0.068
1.75
0.49
0.014
0.019
1.250
0.016
0.049
1.27 BSC 0.05 BSC 0.05 BSC
0.25
0.007
0.009
0.004
0.008
0.25
6.20
0.229
0.244
0.019
0.50
0.010
MOUNTING PAD
0.030 ± 0.005
TAPE & REEL/BULK ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 1,000 pieces per 12mm tape,
i.e.,
DALC112S1-T7.
3. Suffix-T13 = 13 Inch Reel - 2,500 pieces per 12mm tape,
i.e.,
DALC112S1-T13.
4. Suffix - LF = Lead-Free, Pure-Tin Plating,
i.e.,
DALC112S1-LF-T7.
5. No Suffix = Product Shipped in Tubes of 98 pcs per Tube.
0.160 ± 0.005
0.245 MIN
0.045 ± 0.005
Outline & Dimensions: Rev 1 - 11/01, 06009
COPYRIGHT © ProTek Devices 2005
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and
specifications is the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or
specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
