The DAC7715 is a quad, serial input, 12-bit, voltage
output Digital-to-Analog Converter (DAC) with
guaranteed 12-bit monotonic performance over the
–40°C to +85°C temperature range. An asynchronous
reset clears all registers to either mid-scale (800
H
) or
zero-scale (000
H
), selectable via the RESETSEL pin.
The individual DAC inputs are double buffered to
allow for simultaneous update of all DAC outputs.
The device can be powered from a single +15V supply
or from dual +15V and –15V supplies.
Low power and small size makes the DAC7715 ideal
for automatic test equipment, DAC-per-pin program-
mers, data acquisition systems, and closed-loop servo-
control. The device is available in a SO-16 package
and is guaranteed over the –40°C to +85°C tempera-
ture range.
APPLICATIONS
q
PROCESS CONTROL
q
ATE PIN ELECTRONICS
q
CLOSED-LOOP SERVO-CONTROL
q
MOTOR CONTROL
q
DATA ACQUISITION SYSTEMS
q
DAC-PER-PIN PROGRAMMERS
GND
V
CC
V
REFH
Input
Register A
SDI
DAC
Register A
DAC A
V
OUTA
Serial-to-
Parallel
Shift
Register
Input
Register B
12
DAC
Register B
DAC B
V
OUTB
Input
Register C
DAC
Register C
DAC C
V
OUTC
CLK
CS
DAC
Select
Input
Register D
DAC
Register D
DAC D
V
OUTD
LOADREG
RESETSEL RESET
LOADDACS
V
REFL
V
SS
International Airport Industrial Park • Mailing Address: PO Box 11400, Tucson, AZ 85734 • Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 • Tel: (520) 746-1111
equals –10V, then one LSB equals 4.88mV. (2) All DAC outputs will match within
the specified error band. (3) Ideal output voltage does not take into account zero or full-scale error.
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
DAC7715
2
SPECIFICATIONS (Single Supply)
At T
A
= –40°C to +85°C, V
CC
= +15V, V
SS
= GND, V
REFH
= +10V, V
REFL
= 0V, unless otherwise noted.
DAC7715U
PARAMETER
ACCURACY
Linearity Error
(1)
Linearity Matching
(3)
Differential Linearity Error
Monotonicity
Zero-Scale Error
Zero-Scale Drift
Zero-Scale Matching
(3)
Full-Scale Error
Full-Scale Matching
(3)
Power Supply Sensitivity
ANALOG OUTPUT
Voltage Output
(4)
Output Current
Load Capacitance
Short-Circuit Current
Short-Circuit Duration
REFERENCE INPUT
V
REFH
Input Range
V
REFL
Input Range
Ref High Input Current
Ref Low Input Current
DYNAMIC PERFORMANCE
Settling Time
(5)
Channel-to-Channel Crosstalk
Digital Feedthrough
Output Noise Voltage
DIGITAL INPUT
Logic Levels
V
IH
V
IL
Data Format
POWER SUPPLY REQUIREMENTS
V
CC
I
CC
Power Dissipation
TEMPERATURE RANGE
Specified Performance
To
±0.012%,
10V Output Step
CONDITIONS
MIN
TYP
MAX
±2
±2
±1
T
MIN
to T
MAX
Code = 004
H
12
±4
2
Code = FFF
H
At Full Scale
V
REFL
–5
No Oscillation
To V
CC
or GND
V
REFL
+1.25
0
–0.3
–2.0
8
0.25
2
65
500
±20
Indefinite
+10
V
REFH
– 1.25
1.5
0
10
T
T
T
T
T
T
T
20
V
REFH
+5
T
T
T
T
T
T
T
T
T
T
T
±4
±4
±4
T
T
T
±2
T
±2
T
T
MIN
DAC7715UB
TYP
MAX
±1
±1
±1
UNITS
LSB
(2)
LSB
LSB
Bits
LSB
ppm/°C
LSB
LSB
LSB
ppm /V
V
mA
pF
mA
V
V
mA
mA
µs
LSB
nV-s
nV/√Hz
f = 10kHz
I
IH
≤ ±10µA
I
IL
≤ ±10µA
3.325
1.575
Straight Binary
14.25
3.0
45
–40
+85
15.75
T
T
T
T
T
T
T
T
T
V
V
V
mA
mW
°C
T
NOTES: (1) If V
SS
= 0V, specification applies at code 004
H
and above. (2) LSB means Least Significant Bit; if V
REFH
equals +10V and V
REFL
equals 0V, then one
LSB equals 2.44mV. (3) All DAC outputs will match within the specified error band. (4) Ideal output voltage does not take into account zero or full-scale error.
(5) Full-scale positive 10V step and negative step from code FFF
H
to 020
H
.
®
3
DAC7715
ABSOLUTE MAXIMUM RATINGS
(1)
V
CC
to V
SS
........................................................................... –0.3V to +32V
V
CC
to GND ......................................................................... –0.3V to +16V
V
SS
to GND ......................................................................... +0.3V to –16V
V
REF
H to GND ....................................................................... –9V to +11V
V
REF
L to GND (V
SS
= –15V) ................................................. –11V to +9V
V
REF
L to GND (V
SS
= 0V) .................................................... –0.3V to +9V
V
REFH
to V
REFL
....................................................................... –1V to +22V
Digital Input Voltage to GND .............................................. –0.3V to 5.8V
Digital Output Voltage to GND ............................................ –0.3V to 5.8V
Maximum Junction Temperature ................................................... +150°C
Operating Temperature Range ........................................ –40°C to +85°C
Storage Temperature Range ......................................... –65°C to +150°C
Lead Temperature (soldering, 10s) ............................................... +300°C
NOTE: (1) Stresses above those listed under “Absolute Maximum Ratings”
may cause permanent damage to the device. Exposure to absolute maximum
conditions for extended periods may affect device reliability.
ELECTROSTATIC
DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may
be more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.
PACKAGE/ORDERING INFORMATION
MAXIMUM
LINEARITY
ERROR
(LSB)
±2
MAXIMUM
DIFFERENTIAL
LINEARITY
(LSB)
±1
PACKAGE
DRAWING
NUMBER
211
SPECIFICATION
TEMPERATURE
RANGE
–40°C to +85°C
PRODUCT
DAC7715U
PACKAGE
SOIC-16
ORDERING
NUMBER
(1)
DAC7715U
DAC7715U/1K
DAC7715UB
DAC7715UB/1K
TRANSPORT
MEDIA
Rails
Tape and Reel
Rails
Tape and Reel
"
DAC7715UB
"
±1
"
±1
"
SOIC-16
"
211
"
–40°C to +85°C
"
"
"
"
"
"
NOTE: (1) Models with a slash (/) are available only in Tape and Reel in the quantities indicated (e.g., /1K indicates 1000 devices per reel). Ordering 1000 pieces
of “DAC7715UB/1K” will get a single 1000-piece Tape and Reel.
