DCR01 family is a series of high-efficiency, input-
isolated, output-regulated DC/DC converters. In addi-
tion to 1W nominal, galvanically-isolated output power
capability, this range of DC/DCs offer very low out-
put noise, thermal protection and high accuracy.
The DCR01 family is implemented in standard molded
IC packaging, giving standard JEDEC outlines suit-
able for high-volume assembly.
The DCR01 is manufactured using the same technol-
ogy as standard IC packages, thereby achieving very
high reliability.
NOTE: (1) SO version available Q3 2000.
SYNC
V
REC
ENABLE
V
S
Input
Controller
LDO
Regulator
ERROR
V
OUT
0V
0V
International Airport Industrial Park • Mailing Address: PO Box 11400, Tucson, AZ 85734 • Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 • Tel: (520) 746-1111
Storage Temperature ...................................................... –60°C to +125°C
Lead Temperature (soldering, 10s) ................................................. 270°C
ELECTROSTATIC
DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
ESD damage can range from subtle performance degrada-
tion to complete device failure. Precision integrated circuits
may be more susceptible to damage because very small
parametric changes could cause the device not to meet its
published specifications.
ORDERING INFORMATION
DCR01
Basic Model Number: 1W Product
Voltage Input:
5V In
Voltage Output:
5V Out
Package Code:
P = 18-Pin Plastic DIP, U = 28-Pin SO
(1)
NOTE: (1) SO version available Q3 2000.
05
05
(P)
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN assumes
no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject to change
without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not authorize or warrant
any BURR-BROWN product for use in life support devices and/or systems.
®
3
DCR01
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING
NUMBER
218-1
218-1
217-2
217-2
218-1
217-2
218-1
217-2
218-1
217-2
218-1
217-2
SPECIFIED
TEMPERATURE
RANGE
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
–40°C to +85°C
PACKAGE
MARKING
DCR010503P
DCR010505P
DCR010503U
DCR010505U
DCR011203P
DCR011203U
DCR011205P
DCR011205U
DCR012403P
DCR012403U
DCR012405P
DCR012405U
ORDERING
NUMBER
(1)
DCR010503P
DCR010505P
DCR010503U/1K
DCR010505U/1K
DCR011203P
DCR011203U/1K
DCR011205P
DCR011205U/1K
DCR012403P
DCR012403U/1K
DCR012405P
DCR012405U/1K
TRANSPORT
MEDIA
Rails
Rails
Tape and Reel
Tape and Reel
Rails
Tape and Reel
Rails
Tape and Reel
Rails
Tape and Reel
Rails
Tape and Reel
PRODUCT
DCR010503P
DCR010505P
DCR010503U
(3)
DCR010505U
(3)
DCR011203P
(2)
DCR011203U
(1, 3)
DCR011205P
(2)
DCR011205U
(1, 3)
DCR012403P
(3)
DCR012403U
(1, 3)
DCR012405P
(3)
DCR012405U
(1, 3)
PACKAGE
PDIP-18
PDIP-18
SO-28
SO-28
PDIP-18
SO-28
PDIP-18
SO-28
PDIP-18
SO-28
PDIP-18
SO-28
NOTE: (1) Models with a slash (/) are available only in Tape and Reel in the quantities indicated (e.g., /1K indicates 1000 devices per reel). Ordering 1000 pieces
of “DCR010503U/1K” will get a single 1000-piece Tape and Reel. (2) Available Q2 2000. (3) Available Q3 2000.
