DF005 THRU DF10
GLASS PASSIVATED CHIP SINGLE-PHASE BRIDGE RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Forward Current -
1.0 Ampere
Features
Ideal for printed circuit board
Glass passivated chip junction
High temperature soldering guaranteed:
260 /10 seconds at 5 lbs tension
Mechanical Data
Terminals:
Plated leads, solderable per
MIL-STD-202, method 208
Case:
Molded with UL-94Class V-0 recognized
flame retartant epoxy
Polarity:
Polarity symbol marked on body
Mounting Position:
Any
Maximum Ratings and Electrical Characteristics
Single-phase, half-wave, 60Hz, resistive or inductive load.
Ratings at 25
unless otherwise stated.
For capacitive load, Derate current by 20%.
Characteristic
Symbols
DF005
DF01
DF02
DF04
DF06
DF08
DF10
Units
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
at T
A
=40
Peak forward surge current
8.3mS single half sine-wave superimposed
on rated load
Maximum forward voltage at
forward current perelement 1.0A
I
2
t-rating for fusion (t<8.3mS)
Maximum DC reverse current
at rated DC blocking voltage
Typical junction capacitance (Note 1)
Typical thermal resistance (Note 2)
Operating temperature range
Storage temperature range
T
A
=25
T
A
=125
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
2
t
I
R
C
J
R
JA
50
35
50
100
70
100
200
140
200
400
280
400
1.0
50.0
1.1
10.0
10.0
500.0
25.0
40.0
-55 to +125
-55 to +150
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amp
Amps
Volts
A
2
S
A
F
/W
T
J
T
STG
Notes:
(1) Measured at 1.0MHz and applied reverse voltage of 4.0 VDC
(2) Thermal resistance from junction to ambient on P.C. Board Mounted
1
