Conformal Coated Inductors - Axial
SPECIFICATIONS
Please specify tolerance code when ordering.
CTC2-R022_
J = ±5%, K = ±10%, M = ±20%
Part
Number
CTC2-R022_
CTC2-R033_
CTC2-R039_
CTC2-R047_
CTC2-R056_
CTC2-R068_
CTC2-R082_
CTC2-R10_
CTC2-R12_
CTC2-R15_
CTC2-R18_
CTC2-R22_
CTC2-R27_
CTC2-R33_
CTC2-R39_
CTC2-R47_
CTC2-R56_
CTC2-R68_
CTC2-R82_
CTC2-1R0_
CTC2-1R2_
CTC2-1R5_
CTC2-1R8_
CTC2-2R2_
CTC2-2R7_
CTC2-3R3_
CTC2-3R9_
CTC2-4R7_
CTC2-5R6_
CTC2-6R8_
CTC2-8R2_
CTC2-100_
CTC2-120_
CTC2-150_
CTC2-180_
CTC2-220_
CTC2-270_
CTC2-330_
CTC2-390_
CTC2-470_
CTC2-560_
CTC2-680_
CTC2-820_
CTC2-101_
CTC2-121_
CTC2-151_
CTC2-181_
CTC2-221_
CTC2-271_
CTC2-331_
CTC2-391_
CTC2-471_
CTC2-561_
CTC2-681_
CTC2-821_
CTC2-102_
Inductance
(µH)
.022
.033
.039
.047
.056
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(MHz)
50
50
50
50
50
50
50
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
Q
Factor
Min.
40
40
40
40
40
40
40
30
30
30
30
40
40
40
40
40
40
40
40
40
40
45
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
50
50
50
50
50
60
60
60
60
60
60
60
60
60
60
60
50
Q Test
Freq.
(MHz)
50
50
50
50
50
50
50
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
.796
SRF
Min.
(MHz)
500
490
480
480
470
470
470
280
280
280
280
280
260
250
220
200
180
160
140
135
135
130
125
80
80
70
65
45
49
30
28
22
20
16
15
13
11
10
9.5
8.5
7.5
6.5
6.0
5.5
5.4
4.8
4.4
4.0
3.7
3.4
2.8
2.7
2.4
2.0
1.6
1.2
Ver. 8.3
CTC2 Series
From .022 µH to 1,000 µH
ENGINEERING KIT #1
Not shown at actual size.
DCR
Max.
Ω
(Ω)
.01
.02
.02
.03
.04
.05
.05
.08
.08
.09
.12
.15
.15
.15
.17
.17
.17
.18
.18
.18
.18
.20
.23
.25
.28
.30
.32
.35
.40
.45
.56
.72
.80
.88
1.0
1.2
1.3
1.5
1.7
2.3
2.6
2.9
3.2
3.5
3.8
4.4
5.0
5.7
7.5
9.5
10
11
13
18
24
30
Rated
DC
(mA)
520
500
500
500
460
460
460
1400
1350
1270
1200
1150
1110
1110
1000
1000
950
900
900
815
740
700
655
630
596
575
555
530
500
470
425
370
350
335
315
285
270
255
240
205
195
185
175
165
160
150
140
130
120
100
95
90
85
75
65
60
CHARACTERISTICS
Description:
Axial leaded conformal coated inductor
Applications:
Used in less harsh environments. Ideal for less
critical RFL/EMI applications
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4285A or
HP4286A at specified frequency
Packaging:
Bulk pack or Tape & Reel, 5,000 parts per reel
Marking:
Parts are EIA color banded with inductance code and
tolerance
Material:
Magnetic core with epoxy resin for protection and
longer reliability
Miscellaneous:
Other values available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
Max.
6.6
0.26
A
Max.
2.8
0.11
B
Typ.
29.2
1.15
C
24 AWG
Nom.
0.511
0.02
06.11.03
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
