DB101 - DB107
MECHANICAL DATA
*
*
*
*
*
*
Case: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: MIL-STD-202E, Method 208 guaranteed
Polarity: Symbols molded or marked on body
Mounting position: Any
Weight: 0.4 gram
SINGLE-PHASE SILICON BRIDGE RECTIFIER
FEATURES
*
*
*
*
*
Good for automation insertion
Surge overload rating - 50 Amperes peak
Ideal for printed circuit board
Reliable low cost construction
Glass passivated junction
VOLTAGE RANGE - 50 to 1000 Volts CURRENT - 1.0 Ampere
DB-1
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
PARAMETER
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Output Current at T
A
= 40℃
Peak Forward Surge Current 8.3 ms single half sine-wave
Superimposed on rated load (JEDEC Method)
Maximum Forward Voltage Drop per element at 1.0A DC
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
I t Rating For Fusing ( t<8.3ms )
Typical Junction Capacitance ( Note 1)
Typical Thermal Resistance ( Note 2 )
Operating and Storage Temperature Range
2
SYMBOL DB101 DB102 DB103 DB104 DB105 DB106 DB107 UNITS
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
@T
A
= 25℃
@T
A
= 125℃
I
R
R
50
35
50
100
70
100
200
140
200
400
280
400
1.0
50
1.1
10
500
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
A Sec
pF
℃/W
℃
2
I
It
C
J
RΘJA
T
J,TSTG
2
10
25
40
-65 to +150
NOTES : 1. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
2. Thermal Resistance from Junction to Ambient and from junction to lead mounted on P.C.B. with 0.5 x 0.5" (13x13mm) copper pads.
