DIMD10A
DUAL PRE-BIASED TRANSISTORS
FOR POWER MANAGEMENT
Features
NEW PRODUCT
•
•
•
•
•
Epitaxial Planar Die Construction
Built-In Biasing Resistors
One 500mA PNP and One 100mA NPN
Lead Free By Design/RoHS Compliant (Note 1)
Qualified to AEC-Q101 Standards for High Reliability
A
SC-74R
Dim
A
B C
Min
0.35
1.50
2.70
2.90
1.00
0.35
0.10
0°
Max
0.50
1.70
3.00
3.10
1.30
0.55
0.20
8°
Typ
0.38
1.60
2.80
0.95
0.55
3.00
0.05
1.10
0.40
0.15
B
C
D
H
Mechanical Data
•
•
•
•
•
•
•
•
Case: SC-74R
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminal Connections: See Diagram
Terminals: Finish
Matte Tin Finish annealed over
Copper leadframe. Solderable per MIL-STD-202, Method
208
Marking & Type Code Information: See Last Page
Ordering Information: See Last Page
Weight: 0.015 grams (approximate)
T
r2
R
1
R
2
R
1
T
r1
K
M
F
H
J
K
L
M
α
0.013 0.10
J
D
F
L
All Dimensions in mm
P/N
DIMD10A
Tr1
Tr2
R1
0.1K
10K
R2
10K
-
Type
Code
C73
SCHEMATIC DIAGRAM
Maximum Ratings PNP Section Tr1
Characteristic
Supply Voltage
Input Voltage
Output Current
@ T
A
= 25°C unless otherwise specified
Symbol
V
CC
V
IN
I
O
Value
-50
-5 to +5
-500
Unit
V
V
mA
Maximum Ratings NPN Section Tr2
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
@ T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
Value
50
50
5
100
Unit
V
V
V
mA
Maximum Ratings - Total
Characteristic
Power Dissipation
@ T
A
= 25°C unless otherwise specified
Symbol
P
d
T
j
, T
STG
Value
300*
-55 to +150
Unit
mW
°C
Operating and Storage Temperature Range
* Not to exceed 200mW for either Tr1 or Tr2.
Note:
1. No purposefully added lead.
DS30391 Rev. 4 - 2
1 of 4
www.diodes.com
©
Diodes Incorporated
DIMD10A
Electrical Characteristics PNP Section Tr1
@ T
A
= 25°C unless otherwise specified
Min
-0.3
68
Typ
-0.1
200
Max
-1.5
-0.3
-25
-0.5
Unit
V
V
mA
µA
MHz
Test Condition
V
CC
= -5V, I
O
= -100µA
V
O
= 0.3, I
O
= -100mA
I
O
= -100mA/-5mA
V
I
= -2V
V
CC
= -50V, V
I
= 0V
V
CE
= -10V, I
E
= -50mA,
f = 100MHz
NEW PRODUCT
Characteristic
Input Voltage
Output Voltage
Input Current
Output Current
DC Current Gain
Gain-Bandwidth Product*
* Transistor - For Reference Only
Symbol
V
l(off)
V
l(on)
V
O(on)
I
l
I
O(off)
G
l
f
T
Electrical Characteristics NPN Section Tr2
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
Collector-Emitter Saturation Voltage
DC Current Transfer Ratio
Gain-Bandwidth Product*
* Transistor - For Reference Only
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
V
CE(sat)
h
FE
f
T
Min
50
50
5
100
@ T
A
= 25°C unless otherwise specified
Typ
250
250
Max
0.5
0.5
0.3
600
Unit
V
V
V
µA
µA
V
MHz
Test Condition
I
C
= 50µA
I
C
= 1mA
I
E
= 50µA
V
CB
= 50V
V
EB
= 4V
I
C
/I
B
= 10mA / 1.0mA
I
C
= 1mA, V
CE
= 5V
V
CE
= 10V, I
E
= -5mA, f = 100MHz
DS30391 Rev. 4 - 2
2 of 4
www.diodes.com
DIMD10A
TYPICAL CURVES - Tr2
NEW PRODUCT
V
CE(SAT)
, MAXIMUM COLLECTOR VOLTAGE (V)
250
P
D
, POWER DISSIPATION (MILLIWATTS)
(TOTAL PACKAGE)
1
I
C
/I
B
= 10
200
0.1
75°C
-25°C
25°C
150
100
0.01
50
0
-50
0
50
100
150
0.001
0
10
20
30
40
50
I
C
, COLLECTOR CURRENT (mA)
Fig. 2 V
CE(SAT)
vs. I
C
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Derating Curve
1000
hFE, DC CURRENT GAIN (NORMALIZED)
75°C
V
CE
= 10
4
I
E
= 0mA
C
OB
, CAPACITANCE (pF)
-25°C
25°C
3
100
2
10
1
0
1
1
10
I
C
, COLLECTOR CURRENT (mA)
Fig. 3 DC Current Gain
100
0
5
10
15
20
25
30
V
R
, REVERSE BIAS VOLTAGE (V)
Fig. 4 Output Capacitance
10
100
75°C
I
C
, COLLECTOR CURRENT (mA)
25°C
V
O
= 0.2
10
-25°C
V
in
, INPUT VOLTAGE (V)
1
-25°C
75°C
1
25°C
0.1
0.01
0.001
0
1
2
3
4
5
6
7
8
9
10
V
in
, INPUT VOLTAGE (V)
Fig. 5 Collector Current Vs. Input Voltage
1
0
10
20
30
40
50
I
C
, COLLECTOR CURRENT (mA)
Fig. 6 Input Voltage vs. Collector Current
DS30391 Rev. 4 - 2
3 of 4
www.diodes.com
DIMD10A
Ordering Information
(Note 2)
Packaging
SC-74R
Shipping
3000/Tape & Reel
NEW PRODUCT
Device
DIMD10A-7
Notes:
2. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
C73 = Product Type Marking Code
YM = Date Code Marking
Y = Year ex: S = 2005
M = Month ex: 9 = September
C73
Date Code Key
Year
Code
Month
Code
Jan
1
Feb
2
March
3
2005
S
Apr
4
May
5
2006
T
Jun
6
2007
U
Jul
7
2008
V
Aug
8
2009
W
Sep
9
Oct
O
2010
X
Nov
N
2011
Y
Dec
D
DS30391 Rev. 4 - 2
4 of 4
www.diodes.com
YM
DIMD10A
