The EX-421 provides exceptionally low aging rates and tight temperature stabilities in an extremely small package over a wide
range of environmental conditions. This EMXO series bridges the gap between current large, high precision OCXO’s and smaller
TCXO’s. The EX-421 Series becomes the most economical choice where there is a need for spectral purity, short and long term
stability, along with small size and dramatically reduced power consumption.
Features
Low Power Consumption Precision Oscillator
Fast Warm-up
Low Phase Noise
Good Aging
Small Form Factor
SMD and Thru-Hole Mounting Option
RoHS Compliant
*
Standard Frequencies: 10MHz, 20MHz and 100MHz
Design/Material Sourcing/Manufacture/Test in MHS,PA COO:USA
No ITAR Restriction for importing EAR99
Previous Model Number: EX-620, EX-420 series
•
•
•
•
•
•
•
Applications
Mobile Data Communications
Military Portable Radio
Satellite Communications
Airborne Equipment
Avionics
Instrumentation
Marine/Land Seismic
•
•
•
•
•
•
•
•
•
*
Performance Specifications
Frequency Stabilities
1
Min
vs. operating temperature range
Typ
Max
ppb
ppb
ppb
ppb
ppm
ppb
ppb
ppb
ppb
ppm
seconds
seconds
Condition
at time of shipment
vs. supply voltage change
vs. load change
-1
Warm-up Time
+1
Supply Voltage (Vs)
Watts
Watts
during warm-up
1 of 5
Performance Specifications
Frequency Stabilities
1
Min
Signal [Standard]
pF
Typ
Max
RF Output
Condition
ns
Signal [Standard]
Sinewave
ohm
+4
dBm
dBm
dBc
Frequency Tuning (EFC)
Tuning Voltage
Tuning Slope
+Vref
ppm
Additional Parameters
0
45
ppb
Tau = 1 sec
Weight
g
Absolute Maximum Ratings
Supply Voltage
pF
Operable temperature range
Storage temperature range
2 of 5
Outline Drawing / Enclosure
Surface Mounture
LABEL
ure
Thru-hole
LABEL
[11.43] MAX
.450 MAX
45°
[13.46] MAX
.530 MAX
[13.46] MAX
.530 MAX
[11.43. MAX
.450 MAX
METAL TAB AND
DOT INDICATE PIN 1
[0.64] MAX
0.025 MAX
(ALL 4 SIDES)
METAL TAB AND DOT
INDICATE PIN 1
[.64] MAX
.025 MAX
(ALL 4 SIDES)
[9.80] MAX
.385 MAX
6.60
.260
[9.40] MAX
.370 MAX
[6.60]
.260 REF
3.72±0.254
.146±.010
0.51
R.020
1
2
4
0.51
.020
0.46
.018
1.73
.068
2.54
.100
1.14
.045
(5X)
1.73
.068
12.70±0.254
.500±.010
2.54
.100
Pin Connections
Function
1
EFC Input
Vref Output
1
2
4
7.62
.300
8
5
12.70±0.254
.500±.010
8
5
7.62
.300
12.70±0.508
.500±.020
2
4
7.62
.300
12.70±0.508
.500±.020
Supply Voltage Input
Standard Shipping Method
Hi Janice,
We can offer MOQ of 10+pcs with
our 25+pcs pricing, under Stan-
dard USD price list. Please quote
and Jake will approve the MOQ
and price.
Thanks,John
3 of 5
Recommended Reflow Profiles for Pb-Free & Sn-Pb
tp
T
p
Ramp up
Ts
Critical Zone
T
L
to T
p
T
L
Temperature
t
L
Ramp dow n
Ts
ts
preheat
25
t 25°C to peak
Time
230°C Reflow Profile
W
&
^ W
3°C/seconds max.
135°C
155°C
60-90 seconds
3°C/seconds max.
183°C
40-60 seconds
max 230°C
Time within 5°C of actual
Peak Temperature (tp)
Ramp-down Rate
6°C/seconds max.
10-20 seconds max.
W
&
^ W
4 minutes max.
Average ramp-up rate (TL to TP)
Preheat - Temperature min Tsmin
- Temperature Min Tsmax
- Time (min to max) (ts)
Tsmax to TL -Ramp-up Rate
Time maintained above - Temperature (TL)
- Time (TL)
Peak Temperature (Tp)
E
Time 25°C to Peak Temperature
Time maintained above
- Temperature (TL)
- Time (tL)
183°C
45-60 seconds
All temperatures refer to topside of the package, measured on the package body surface.
260°C Reflow Profile
W
&
W &
3°C/seconds max.
150°C
200°C
60-180 seconds
3°C/seconds max.
217°C
60-150 seconds
max 260°C
Time within 5°C of actual
Peak Temperature (tp)
Ramp-down Rate
6°C/seconds max.
20-40 seconds max.
W
&
W &
8 minutes max.
Average ramp-up rate (TL to TP)
Preheat - Temperature min Tsmin
- Temperature min Tsmax
- Time (min to max) (ts)
Tsmax to TL -Ramp-up Rate
Time maintained above - Temperature (TL)
- Time (TL)
Peak Temperature (Tp)
E
Time 25°C to Peak Temperature
Time maintained above
- Temperature (TL)
- Time (tL)
217°C
60-150 seconds
All temperatures refer to topside of the package, measured on the package body surface.
4 of 5
Ordering Information
EX - 421 0 - D A P - 108 0 - 10M0000000
Frequency
Frequency Control
Configuration
Thru-hole
Thru-hole with Solder Coated Leads
Supply Voltage
508: ±50ppb
758: ±75ppb
107: ±100ppb
Stability Code
d
^
d
108 (+/-10ppb)
208 (+/-20ppb)
308 (+/-30ppb)
508 (+/-50ppb)
758 (+/-75ppb)
107 (+/-100ppb)
10-30MHz
10-50MHz
10-80MHz
10-100MHz
Z
^
d
10-30MHz
A: -55°C to +85°C E: -40°C to +85°C J: -20°C to +70°C P: 0°C to +50°C
10-30MHz
10-30MHz
10-50MHz
10-100MHz
10-30MHz
10-30MHz
10-50MHz
10-100MHz
10-30MHz
10-50MHz
10-100MHz
Temperature Range and Stability Table
Notes:
Stability/Temperature A: -55°C to +85°C
E: -40°C to +85°C
J: -20°C to +70°C
1.
108 (+/-10ppb)
frequencies.
10-30MHz
2.
208 (+/-20ppb)
10-30MHz
10-30MHz
308 (+/-30ppb) 10-30MHz
10-30MHz
10-30MHz
10-30MHz
4.
Subject to technical modification.
Contact factory for availability.
P: 0°C to +50°C
For Additional Information, Please Contact
USA:
Vectron International
Europe:
Vectron International
Asia:
Vectron International
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
