LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
LED SMD
Pb
Lead-Free Parts
LG-192HRF/9UG-S-CT
DATA SHEET
DOC. NO :
REV.
DATE
:
:
QW0905-LG-192HRF/9UG-S-CT
A
16 - Oct - 2006
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LG-192HRF/9UG-S-CT
Page 1/11
Features:
1. Package in 8.0mm carrier tape on 7" diameter reel.
2. Compatible with automatic placement equipment.
3. Compatible with infrared and vapor phase reflow solder process.
Descriptions:
1. The LG-192HRF/9UG-S SMD Taping is much smaller than
lead frame type components, thus enable smaller
board size, higher packing density, reduced storage
space and finally smaller equipment to be obtained.
2. Besides, lightweight makes them ideal for miniature
applications. etc.
Applications:
1. Automotive : backlighting in dashboard and switch.
2. Telecommunication : indicator and backlighting in telephone and fax.
3. Flat backlight for LCD, switch and symbol
4. General use.
Device Selection Guide:
COLOR
PART NO
MATERIAL
AlGaInP
AlGaInP
Emitted
Red
Green
Water Clear
Lens
LG-192HRF/9UG-S-CT
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LG-192HRF/9UG-S-CT
Page 2/11
Package Dimensions
0.4
0.8
2
DIE2
1.6
DIE1
0.45
4
3
1.0
1
0.2
0.25
Cathode
Mark
0.25
Resin
0.45
Soldering
Terminal
PCB
2
1
9UG
HRF
4
3
Note : 1.All dimension are in millimeter tolerance is
±
0.1mm unless otherwise noted.
2.Specifications are subject to change without notice.
Recommended Soldering Pad Dimensions
0.5
0.3
0.5
0.8
0.7
0.8
Note : The tolerances unless mentioned is
±
0.1mm,Angle
±
0.5. Unit=mm.
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LG-192HRF/9UG-S-CT
Page 3/11
Absolute Maximum Ratings at Ta=25
℃
Ratings
Parameter
Power Dissipation
Peak Forward Current
Duty 1/10@10KHz
Forward Current
Reverse Current @5V
Electrostatic Discharge
Operating Temperature
Storage Temperature
Soldering Temperature
Symbol
HRF
PD
I
FP
I
F
Ir
ESD
T
opr
Tstg
Tsol
72
90
30
10
2000
-40 ~ +85
-40 ~ +90
Max 260
℃
for 5 sec Max
9UG
78
60
30
10
UNIT
mW
mA
mA
μ
A
V
℃
℃
Typical Electrical & Optical Characteristics (Ta=25
℃
)
Items
Luminous Intensity
Symbol
HRF
Min.
20
20
Typ.
50
40
642
575
630
574
20
20
----
----
130
130
Max. UNIT
----
mcd
----
----
----
----
----
----
----
2.4
V
nm
nm
nm
CONDITION
IF=20mA
Iv
9UG
HRF
----
9UG
----
Peak Wavelength
λ
P
IF=20mA
Dominant Wavelength
λD
HRF
----
9UG
----
IF=20mA
Spectral Line Half-Width
△λ
HRF
----
9UG
----
IF=20mA
Forward Voltage
HRF
1.5
V
F
9UG
1.7
IF=20mA
2.6
----
----
deg
IF=20mA
Viewing Angle
2
θ
1/2
HRF
----
9UG
----
LIGITEK ELECTRONICS CO.,LTD.
Property of Ligitek Only
PART NO. LG-192HRF/9UG-S-CT
Page 4/11
Typical Electro-Optical Characteristics Curve
HRF CHIP
Fig.1 Forward current vs. Forward Voltage
Fig.2 Relative Intensity vs. Forward Current
1000
3.5
Forward Current(mA)
100
Relative Intensity
Normalize @20mA
1.0
1.5
2.0
2.5
3.0
3.0
2.5
2.0
1.5
1.0
0.5
0
1.0
10
100
1000
10
1.0
0.1
Forward Voltage(V)
Fig.3 Forward Voltage vs. Temperature
1.2
Forward Current(mA)
Fig.4 Relative Intensity vs. Temperature
3.0
Forward Voltage@20mA
Normalize @25
℃
Relative Intensity@20mA
Normalize@25
℃
-40
-20
-0
20
40
60
80
100
2.5
2.0
1.5
1.0
0.5
0
-40
1.1
1.0
0.9
0.8
-20
0
20
40
60
80
100
Ambient Temperature(
℃
)
Ambient Temperature(
℃
)
Fig.5 Relative Intensity vs. Wavelength
Fig.6 Directive Radiation
Relative Intensity@20mA
1.0
0.5
0
550
600
650
700
Wavelength (nm)
