RADIATION TOLERANT 3-PHASE DC
MOTOR TORQUE CONTROLLER
FEATURES
•
Self-Contained 3-Phase Motor
Controller
•
Operates as Current or Voltage
Controller
•
1, 3 and 10 Amp Output Current
•
Radiation Tolerant
Total Dose: 100 Krads
SEU: > 100 MeV/mg/cm
2
•
1.5% Linearity
•
3% Current Regulating Accuracy
•
User-Programmable Compensation
•
10 KHz - 100 KHz PWM Frequency
DESCRIPTION
The PW-82520R (100Vdc) is a high performance, radiation tolerant,
current regulating torque loop controller designed to accurately regu-
late the current in the motor windings of 3-phase brushless DC and
brush DC motors.
The PW-82520R is a completely self-contained motor controller that
converts an analog input command signal into motor current and
uses the signals from Hall-effect sensors in the motor to commutate
the current in the motor windings. The motor current is internally
sensed and processed into an analog signal. The current signal is
summed together with the command signal to produce an error sig-
nal that controls the pulse width modulation (PWM) duty cycle of the
output, thus controlling the motor current. The PW-82520R perform-
ance can be tuned by utilizing the internal error amplifier and the
external Proportional/Integral (PI) regulator network components to
match motor characteristics.
•
Complementary Four-Quadrant
Operation
•
Holding Torque through Zero Current
•
Cycle-by-Cycle Current Limit
•
Non-Radiation Tolerant versions of
this product are also available
(see PW-82520/21N data sheet)
APPLICATIONS
The PW-82520R is ideal for space and radiation tolerant applications
requiring current regulation and/or holding torque at zero input com-
mand. System applications that can use the PW-82520R are: pumps,
actuators, antenna position, environmental control and
reaction/momentum wheel systems using brushless and brush
motors. Available in a 1 and 3 amp small DIP-style and a 10 amp flat-
pack hybrid package, the PW-82520R is suitable for applications with
limited printed circuit board area.
FOR MORE INFORMATION CONTACT:
Data Device Corporation
105 Wilbur Place
Bohemia, New York 11716
631-567-5600 Fax: 631-567-7358
www.ddc-web.com
Technical Support:
1-800-DDC-5757 ext. 7771
©
2001 Data Device Corporation
5.0V
10K 10K 10K
HA
HB
HC
HALL A
TACH OUT
Data Device Corporation
www.ddc-web.com
HALL B
HALL C
COMMUTATION
LOGIC
TACH
CIRCUIT
DIR OUT
COMMAND OUT
50K
+
50K
100
DRIVE
A
PHASE A
VBUS+ A
-
COMMAND IN
-
50K
50K
COMMAND
BUFFER
COMMAND IN +
PHASE A
COMMAND GND
SYNC IN
+15V
+5V
+5V RTN
+
+
VBUS+ C
CASE
10.0K
5.0V
DRIVE
C
PHASE C
DRIVE
B
VBUS+ B
V
DR
V
CC
V
CC
RTN
PHASE B
PHASE B
V
DD
PWM
LOGIC
CIRCUITRY
2
470pF
-
SUPPLY GND
V
EE
CASE GND
PHASE C
ENABLE
PWM IN
PWM OUT
ERROR AMP OUT
R
S
+
100
ERROR
AMPLIFIER
-
+
ERROR AMP IN
+
Rsense
CURRENT
MONITOR OUT
CURRENT
AMP
VBUS–
PW-82520R
F-03/06-0
FIGURE 1. PW-82520R BLOCK DIAGRAM
TABLE 1. PW-82520R ABSOLUTE MAXIMUM RATINGS (Tc = +25°C UNLESS OTHERWISE SPECIFIED)
PARAMETER
BUS VOLTAGE
+15V SUPPLY
+5V TO +15V
+5V SUPPLY
-5V TO -15V
VBUS- TO GND
Voltage Differential
CONTINUOUS OUTPUT CURRENT
PW-82520R1
PW-82520R3
PW-82520R0
PEAK OUTPUT CURRENT (PULSED, t = 50 µS)
PW-82520R1
PW-82520R3
PW-82520R0
COMMAND INPUT +
COMMAND INPUT -
LOGIC INPUTS
ENABLE, SYNC IN, HA, HB, HC,
ERROR AMP IN, PWM IN
TACH OUT / DIR OUT
TACH OUT / DIR OUT
SYMBOL
VBUS+ A,B,C
V
DR
V
DD
V
CC
V
EE
V
GNDDIF
VALUE
100.0
+17.5
+17.5
+5.5
-17.5
0V to V
DD
+1.0
UNITS
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
I
OC
1
3
10
3.0
8.0
20.0
±15.0
±15.0
7.0
40
10
A
A
A
A
A
A
Vdc
Vdc
Vdc
Vdc
mA
I
PEAK
V
CMD
+
V
CMD
-
V
IH
V
OH
I
OL
TABLE 2. PW-82520R SPECIFICATIONS
(UNLESS OTHERWISE SPECIFIED,VBUS=28VDC,V
DR
=+15V,V
CC
= +5V,V
DD
=+5V,V
EE
=-5V,TC = 25°C, LL = 500 µH, 100KRAD,
PWM IN = PWM OUT AT ½ FREE RUNNING FREQUENCY)
PARAMETER
OUTPUT (PW-82520R1)
Output Current Continuous
Output Current Pulsed
Current Limit
Current Offset
Output On-Resistance
Output Conductor Resistance
Diode Forward Voltage Drop
OUTPUT (PW-82520R3)
Output Current Continuous
Output Current Pulsed
Current Limit
Current Offset
Output On-Resistance
Output Conductor Resistance
Diode Forward Voltage Drop
OUTPUT (PW-82520R0)
Output Current Continuous
Output Current Pulsed
Current Limit
Current Offset
Output On-Resistance
Output Conductor Resistance
Diode Forward Voltage Drop
SYMBOL
I
OC
I
OP
I
CL
I
OFFSET
R
ON
R
C
V
F
I
OC
I
OP
I
CL
I
OFFSET
R
ON
R
C
V
F
I
OC
I
OP
I
CL
I
OFFSET
R
ON
R
C
V
F
TEST CONDITIONS
MIN
TYP
MAX
1
3
2.25
+20
0.60
0.90
0.06
0.08
.65
3
8
4.75
+20
0.18
0.27
0.06
0.08
.85
10
20
14
+100
0.055
0.075
0.06
0.08
.6
UNITS
A
A
A
mA
Ω
Ω
Ω
Ω
V
A
A
A
mA
Ω
Ω
Ω
Ω
V
A
A
A
mA
Ω
Ω
Ω
Ω
V
Pulse Width
≤
50µsec
FIGURE 7, V
CMD
= 0V
+25°C
+85°C
+25°C
+85°C
I
D
= 1A
1.3
-20
Pulse Width
≤
50µsec
FIGURE 7, V
CMD
= 0V
+25°C
+85°C
+25°C
+85°C
I
D
= 3A
3.25
-20
Pulse Width
≤
50µsec
FIGURE 7, V
CMD
= 0V
+25°C
+85°C
+25°C
+85°C
I
D
= 10A
11
-100
Data Device Corporation
www.ddc-web.com
3
PW-82520R
F-03/06-0
TABLE 2. PW-82520R SPECIFICATIONS (CONTINUED)
(UNLESS OTHERWISE SPECIFIED,VBUS=28VDC,V
DR
=+15V,V
CC
= +5V,V
DD
=+5V,V
EE
=-5V,TC = 25°C, LL = 500 µH, 100KRAD,
PWM IN = PWM OUT AT ½ FREE RUNNING FREQUENCY)
PARAMETER
PROPAGATION DELAY
SYMBOL
Td (on)
Td (off)
SWITCHING CHARACTERISTICS
(PW-82520R1)
Upper Drive
Turn-on Rise Time
Turn-off Fall Time
Lower Drive
Turn-on Rise Time
Turn-off Fall Time
SWITCHING CHARACTERISTICS
(PW-82520R3)
Upper Drive
Turn-on Rise Time
Turn-off Fall Time
Lower Drive
Turn-on Rise Time
Turn-off Fall Time
SWITCHING CHARACTERISTICS
(PW-82520R0)
Upper Drive
Turn-on Rise Time
Turn-off Fall Time
Lower Drive
Turn-on Rise Time
Turn-off Fall Time
CURRENT MONITOR AMP
(PW-82520R1/R3/R0)
Current Monitor Offset
Output Current
Output Resistance
CURRENT MONITOR AMP (PW-82520R1)
Current Monitor Gain
CURRENT MONITOR AMP (PW-82520R3)
Current Monitor Gain
CURRENT MONITOR AMP (PW-82520R0)
Current Monitor Gain
CURRENT COMMAND
Transconductance Ratio
PW-82520R1
PW-82520R3
PW-82520R0
Non-Linearity
Temperature Coefficient of G
VBUS+ SUPPLY
Nominal Operating Voltage
+15V SUPPLY
Voltage
Current
Disabled (PW-82520R1/R3/R0)
Enabled
PW-82520R1
PW-82520R3
PW-82520R0
+5V SUPPLY
Voltage
Current
+5V TO +15V SUPPLY
Voltage
Current
-5V TO -15V SUPPLY
Voltage
Current
G
Tested using circuit
shown in FIGURE 7
Io = 1A
Io = 3A
Io = 10A
TEST CONDITIONS
From 0.8V on ENABLE
to 90% of VBUS
From 2.4V on ENABLE
to 10% of VBUS
MIN
TYP
MAX
40
20
UNITS
µs
µs
t
r
t
f
t
r
t
f
Rise Time =
90% to 10% of VBUS
Fall Time =
10% to 90% of VBUS
I
O
= 1A
75
30
50
60
ns
ns
ns
ns
t
r
t
f
t
r
t
f
Rise Time =
90% to 10% of VBUS
Fall Time =
10% to 90% of VBUS
I
O
= 3A
150
150
160
130
ns
ns
ns
ns
t
r
t
f
t
r
t
f
Rise Time =
90% to 10% of VBUS
Fall Time =
10% to 90% of VBUS
I
O
= 10A
200
200
200
200
ns
ns
ns
ns
Ioc = 0A
Rout
-10
-10
+10
+10
1
4
1.33
0.40
mVdc
mA
Ω
V/A
V/A
V/A
0.24
0.73
2.40
-1.5
0.25
0.75
2.50
0.038
0.26
0.77
2.60
+1.5
A/V
A/V
A/V
% FSR
% FSR/°C
Vdc
Vdc
µA
mA
mA
mA
Vdc
mA
Vdc
mA
Vdc
mA
Vnom
V
DR
I
DR
I
DR
I
DR
I
DR
V
CC
I
CC
V
DD
I
DD
V
EE
I
EE
ENABLE = high
ENABLE = low
ENABLE = low
ENABLE = low
18
+13.5
28
+15.0
70
+16.5
100
8
18
40
+4.5
+5.0
40
15
25
60
+5.5
60
+16.5
50
-4.5
50
+4.5
35
-16.5
40
Data Device Corporation
www.ddc-web.com
4
PW-82520R
F-03/06-0
TABLE 2. PW-82520R SPECIFICATIONS (CONTINUED)
(UNLESS OTHERWISE SPECIFIED,VBUS=28VDC,V
DR
=+15V,V
CC
= +5V,V
DD
=+5V,V
EE
=-5V,TC = 25°C, LL = 500 µH, 100KRAD,
PWM IN = PWM OUT AT ½ FREE RUNNING FREQUENCY)
PARAMETER
SYNC IN
Low
High
Duty Cycle
SYNC range as % of free-run frequency
Input Impedance
PWM IN
+ Peak Voltage
- Peak Voltage
Frequency
PW-82520R1/R3
PW-82520R0
Linearity Error
Duty Cycle
PWM OUT
Free Run Frequency
PW-82520R1/R3
PW-82520R0
Stability, Temperature
HALL SIGNALS (HA,
HB, HC)
Logic 0
Logic 1
ENABLE
Enabled
Disabled
TACH OUT/ DIR OUT
Output Voltage
Iomax
ISOLATION
Case to Ground
COMMAND IN+/-
Differential Input
Input Offset
Input Offset Drift
COMMAND OUT
Internal Voltage Clamp
Slew Rate
Settling Time
THERMAL (PW-82520R1/R3/R0)
Junction Temperature
Case Operating Temperature
Case Storage Temperature
THERMAL (PW-82520R1)
Thermal Resistance
Junction-Case
Case-Air
THERMAL (PW-82520R3)
Thermal Resistance
Junction-Case
Case-Air
THERMAL (PW-82520R0)
Thermal Resistance
Junction-Case
Case-Air
LEAD SOLDER
WEIGHT
PW-82520R1/R3
PW-82520R0
RADIATION
Total dose
Dose Rate
SEU at LET (
Linear Energy Transfer
) level
Latch-up Immune
SYMBOL
V
IL
V
IH
D.C.
R
IN
V
P
+
V
P
-
f
PWM
f
PWM
LIN
D.C.
Vcc = 4.5 - 5.5V
2.3
-2.8
10
10
-2
49
TEST CONDITIONS
MIN
TYP
MAX
0.8
2.4
49
100
50
10
2.5
-2.5
2.8
-2.3
110
55
+2
51
51
120
UNITS
Vdc
Vdc
%
%
KΩ
V
V
KHz
KHz
%
%
50
f
PWM
f
PWM
95
47.5
Full Temp Range
100
50
0.5
105
52.5
2.0
0.8
KHz
KHz
%
Vdc
Vdc
Vdc
Vdc
Vdc
mA
MΩ
V
IL
V
IH
V
IL
V
IH
1.4
0.8
2.0
@ 1 mA
0.4
10
10
-4
2
+4
800
V
OL
I
O
500 Vdc HIPOT
V
CMD
Vdc
µV
µV/°C
Vdc
V/µs
µs to 0.1%
°C
°C
°C
V
CLAMP
V
O
= 0.2 - 4.5V
Tj
T
C
T
CS
θj-c
θc-a
θj-c
θc-a
θj-c
θc-a
-5.8
3
1.4
+5.8
-55
-65
+150
+125
+150
25
10
°C/W
°C/W
9
10
°C/W
°C/W
4
5.5
10sec
@300°C
1.7 (48)
2.9 (82)
100
0.5
100
100
°C/W
°C/W
oz (g)
oz (g)
Krad
Rad/Sec
MeV/mg/cm2
MeV/mg/cm2
Data Device Corporation
www.ddc-web.com
5
PW-82520R
F-03/06-0
京公网安备 11010802033920号
EEWORLD
