MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
ZLG
ZLG
SERIES
Load Life: 105℃ 1000∼5000hours, Ultra Low Impedance.
◆FEATURES
・
Extremely reduced impedance at high frequency range than ZL series.
・
Load Life : 105℃ 1000∼5000 hours.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−40∼＋105℃
6.3∼35V.DC
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝0.03CV
or 3μA whichever is greater.(After 2 minutes)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(V)
Dissipation Factor(MAX)
(tanδ)
Rated Voltage
120Hz）
6.3 10 16 25 35
（20℃，
(V)
tanδ
0.22 0.19 0.16 0.14 0.12
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After life test with rated ripple current at conditions stated in the table below at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Rated Voltage
6.3
(V)
Z
（−25℃） （20℃） 2
/Z
Z
（−40℃） （20℃） 12
/Z
Within ±25％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
Case Size
Ｌ
＝7
φD≦6.3
φD＝ 8
L≧11
φD＝ 10
φD≧12.5
Life Time
(hrs)
1000
2000
3000
4000
5000
Low Temperature Stability
Impedance Ratio(MAX)
10
2
12
16
2
10
25
2
8
35
2
6
（120Hz）
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆DIMENSIONS
100k≦
1.00
1.00
1.00
1.00
1.00
1.00
〈L＝7〉
φD
φd
F
α
1.5
4
5
0.45
2.0
1.0
2.5
6.3
SLEEVE(PET)
（mm）
F ±0.5
φD＋0.5MAX
φd
120
0.24
0.42
0.50
0.55
0.60
0.70
1k
0.53
0.70
0.73
0.77
0.80
0.85
10k
0.80
0.90
0.92
0.94
0.96
0.98
Coefficient
4.7∼10μF
22∼33μF
47∼270μF
330∼680μF
820∼1500μF
2200∼3900μF
L＋ MAX
α
15MIN
4MIN
〈L≧11〉
φD
φd
F
α
2.0
5
0.5
2.5
3.5
6.3
8
10
0.6
5.0
12.5
L≦16 : α
＝1.5 L≧20 : α
＝2.0
◆OPTION
Code
PET Sleeve
◆PART NUMBER
□□□
Rated Voltage
ZLG
Series
□□□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
Ｅ
ＦC
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
ZLG
◆STANDARD SIZE
Rated
capacitance
Size
Rated ripple current
Voltage
φD×L(mm) (mA r.m.s./105℃, 100kHz)
(μF)
(V½DC)
Impedance
(Ω MAX)
20℃, 100kHz −10℃, 100kHz
0.48
0.26
0.15
0.15
0.065
0.036
0.028
0.027
0.020
0.020
0.014
0.018
0.013
0.013
0.012
0.49
0.26
0.26
0.15
0.15
0.065
0.036
0.028
0.027
0.020
0.020
0.014
0.018
0.013
0.013
0.012
0.27
0.26
0.15
0.15
0.065
0.036
0.028
0.027
0.020
0.020
0.014
0.018
0.013
0.013
0.012
1.6
0.86
0.50
0.50
0.19
0.11
0.083
0.070
0.056
0.056
0.033
0.033
0.030
0.030
0.024
1.6
0.86
0.86
0.50
0.50
0.19
0.11
0.083
0.070
0.056
0.056
0.033
0.033
0.030
0.030
0.024
0.89
0.86
0.50
0.50
0.19
0.11
0.083
0.070
0.056
0.056
0.033
0.033
0.030
0.030
0.024
Rated
capacitance
Size
Rated ripple current
Voltage
φD×L(mm) (mA r.m.s./105℃, 100kHz)
(μF)
(V½DC)
Impedance
(Ω MAX)
20℃, 100kHz −10℃, 100kHz
0.52
0.27
0.16
0.15
0.15
0.065
0.036
0.028
0.027
0.020
0.020
0.014
0.018
0.013
0.013
0.012
0.64
0.33
0.17
0.16
0.15
0.065
0.036
0.028
0.027
0.020
0.020
0.014
0.018
0.013
0.013
0.012
1.7
0.89
0.53
0.50
0.50
0.19
0.11
0.083
0.070
0.056
0.056
0.033
0.033
0.030
0.030
0.024
2.1
1.1
0.56
0.53
0.50
0.19
0.11
0.083
0.070
0.056
0.056
0.033
0.033
0.030
0.030
0.024
6.3
(0J)
10
(1A)
16
(1C)
33
47
100
150
330
560
820
1000
1200
1200
1500
1500
2200
3300
3900
22
33
47
100
100
220
470
680
680
1000
1000
1200
1200
1500
2200
3300
22
33
47
56
120
330
470
470
680
680
1000
1000
1200
1500
2200
4×7
5×7
6.3×7
5×11
6.3×11
8×11.5
8×16
10×12.5
8×20
10×16
10×20
12.5×16
10×23
12.5×20
12.5×25
4×7
5×7
5×7
6.3×7
5×11
6.3×11
8×11.5
8×16
10×12.5
8×20
10×16
10×20
12.5×16
10×23
12.5×20
12.5×25
5×7
5×7
6.3×7
5×11
6.3×11
8×11.5
8×16
10×12.5
8×20
10×16
10×20
12.5×16
10×23
12.5×20
12.5×25
230
350
480
405
760
1000
1250
1430
1600
1820
2180
2200
2360
2480
2900
230
350
350
480
405
760
1000
1250
1430
1600
1820
2180
2200
2360
2480
2900
350
350
480
405
760
1000
1250
1430
1600
1820
2180
2200
2360
2480
2900
25
(1E)
35
(1V)
10
22
33
47
47
100
220
330
330
470
470
680
680
820
1000
1500
4.7
10
22
33
33
56
150
220
220
270
330
470
470
560
680
1000
4×7
5×7
6.3×7
6.3×7
5×11
6.3×11
8×11.5
8×16
10×12.5
8×20
10×16
10×20
12.5×16
10×23
12.5×20
12.5×25
4×7
5×7
6.3×7
6.3×7
5×11
6.3×11
8×11.5
8×16
10×12.5
8×20
10×16
10×20
12.5×16
10×23
12.5×20
12.5×25
230
350
480
480
405
760
1000
1250
1430
1600
1820
2180
2200
2360
2480
2900
230
350
480
480
405
760
1000
1250
1430
1600
1820
2180
2200
2360
2480
2900
