MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
ZLJ
ZLJ
SERIES
105℃ Miniaturized, Long Life, Low Impedance, High Ripple Current.
◆FEATURES
・
Load Life : 105℃ 6000∼10000 hours.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−40∼＋105℃
6.3∼100V.DC
±20％
（20℃，
120Hz）
Rated Voltage Range
Capacitance Tolerance
I＝0.01CV
or 3μA whichever is greater.(After 2 minutes)
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Capacitance
(μF) V＝
Rated Voltage
(V)
Dissipation Factor(MAX)
(tanδ)
Rated Voltage
6.3 10 16 25 35 50 63 80 100
(V)
tanδ
0.22 0.19 0.16 0.14 0.12 0.10 0.09 0.08 0.08
（20℃，
120Hz）
When capacitance is over 1000μF, tanδ shall be added 0.02 to the listed value with increase of every 1000μF.
After life test with rated ripple current at conditions stated in the table below at 105℃,
the capacitors shall meet the following requirements.
Capacitance Change
Endurance
Dissipation Factor
Leakage Current
Not more than 200％ of the specified value.
Not more than the specified value.
Within ±25％ of the initial value.(6.3V,10V:±30％)
Life Time(hrs)
6.3V.DC 10∼50V.DC 63∼100V.DC
φD≦6.3
6000
7000
6000
8000
9000
8000
8×11.5
9000
9000
9000
10×12.5
9000
9000 10000
8×16,8×20
10×16,10×20,10×25
10000
φD≧12.5
Case Size
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
6.3
(V)
Z
（−25℃） （20℃） 2
/Z
Z
（−40℃） （20℃） 3
/Z
10
2
3
16
2
3
25
2
3
35
2
3
50
2
3
63
2
3
80 100
（120Hz）
2
3
2
3
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
◆DIMENSIONS
100k≦
1.00
1.00
1.00
1.00
1.00
SLEEVE(PET)
（mm）
F ±0.5
φD＋0.5MAX
φd
120
0.42
0.50
0.55
0.60
0.70
1k
0.70
0.73
0.77
0.80
0.85
10k
0.90
0.92
0.94
0.96
0.98
8.2∼33μF
47∼270μF
Coefficient
330∼680μF
820∼1800μF
2200∼8200μF
L＋ MAX
α
15MIN
4MIN
φD
φd
5
6.3
0.5
8
10 12.5
0.6
16
18
0.8
7.5
◆OPTION
PET Sleeve
Code
Blank
F
α
2.0
2.5
3.5
5.0
L≦16 : α
＝1.5 L≧20 : α
＝2.0
◆PART NUMBER
□□□
Rated Voltage
ZLJ
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
