Rocker Switches
R-Series
The R-Series Curvette single pole
miniature snap-in rocker switches are
available with momentary, rocker,
paddle & Visi-Rocker type actuators.
These aesthetically pleasing switches are
compatible with a range of standard
panel cutouts. Electrical ratings, with
international approvals, are available
up to 16 amps.
Specifications
•Certifications*: UL, CSA, VDE, TUV,
SEMKO, DEMKO, NEMKO, FIMKO,
SEVand BEAB
•Dielectric Strength: 1,000 V (minimum)
•Insulation Resistance: 100 Megohms
(minimum)
•Base Material: Nylon
•Actuator Material: Polyester or Nylon
* Due to ongoing technological advances, consult factory for
certification specifics.
Dimensional Specifications: in. [mm]
.125[3.18] DIA
6.000[152.40]
.250[6.35]
.250 TAB (Q.C.)
.250[6.35]
.187[4.75]
.500[12.70]
WIRE LEAD
.080[2.03]
.375[9.52]
SOLDER LUG
TERMINAL TYPE
.187[4.75]
1.125[28.58]
.725[18.41]
MOMENTARY
.350[8.89]
.550[13.97]
TEST CUT HOLE
IN ACTUAL
MATERIAL
.480[12.19]
1.070[27.17]
.375[9.53]
.620[15.75]
.710[18.03]
1.072[27.23]
MOUNTING HOLE
Panel Thickness: .025 min - .187 max.
Specific cutout dimension range
dependent on panel thickness and material.
Consult factory.
PADDLE
R
SERIES
R
A
91 1
RATING
1
-
V
0
1
5
B
-
B
-
0
-
V
TERMINATION
SOLDER LUG
.250TAB (QC)
WIRE LEAD
BASE COLOR
2
B
BLACK
W
WHITE
SINGLE POLE
CIRCUIT
OFF-NONE-ON
ON-NONE-ON
ON-OFF-ON
Available w/ratings
21, 23, 58, & 91 only
D
OFF-NONE-(ON)
Available w/rating
22 only
AD
OFF-NONE-ON
Double Insulation
BD
ON-NONE-ON
Double Insulation
CD
ON-OFF-ON
Double Insulation
Available w/ratings
21 and 58 only
A
B
C
H
NOTES:
Shading indicates standard configurations.
Panel Cut-Out Recommendations: For sheet metal panels, switch must enter panel in same direction as the punch. (Burr on bottom.) Test cut hole in actual material.
1
Additional ratings are available. Consult factory.
Rating 22 must use circuit D only and momentary rocker.
2
Matte finish is standard. Custom colors are available. Consult factory.
3
Molded-in Legend available only with Visi-Rocker option.
4
White is standard with dark actuators; black is standard with light actuators.
20
10A 250VAC
16A 125VAC
3/4HP 125-250VAC
21
10A 250 VAC
16A 125VAC
22
8A 250VAC
12A 125VAC
1/2HP 125-250VAC
23
10A 250VAC
16A 125VAC
1/2HP 125-250VAC
58
5A 277VAC
10A 125VAC
10A 30V
8A 14VT
90
10A 250VAC
16A 125VAC
3/4HP 125-250VAC
10(4)A 250VACµ T85
91
10A 250VAC
16A 125VAC
10(4)A 250VACµ T85
COLOR OF MOLDED-IN
LEGEND AND/OR
VISI-ROCKER END
2
N
B
V
W
NOT APPLICABLE
BLACK
VISI-RED
WHITE
ACTUATOR STYLE
M
MOMENTARY
ROCKER
P
PADDLE
R
ROCKER
V
TWO COLOR
VISI-ROCKER
ACTUATOR COLOR
B
BLACK
W
WHITE
2
ROCKER FACE LEGEND
INK TRANSFER
STAMP
4
MOLDED-IN
3
0
1
2
8
9
NO LEGEND
OFF-ON (VERTICAL)
OFF-ON (HORIZONTAL)
O-I
(HORIZONTAL)
O-I
(VERTICAL)
ON-OFF (VERTICAL)
ON-OFF (HORIZONTAL)
DUAL LEGEND:
OFF
O-I
ON (VERTICAL)
0
A
B
D
E
F
G
26
Carlingswitch,Inc. (860) 793-9281• Carlingswitch, LTD. Int + 44 1392-364422 • Carlingswitch Asia-Pacific, LTD. Int + 852-2737-2277
