CL32A106MOJNNNE datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> CL32A106MOJNNNE

CL32A106MOJNNNE: Descriptioncap cer 10uf 16v 20% x5r 1210; CategoryPassive components capacitor; File Size134KB，2 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/; Environmental Compliance

Download Datasheet Parametric View All

CL32A106MOJNNNE Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CL32A106MOJNNNE	-	-	View	Buy Now

CL32A106MOJNNNE Overview

cap cer 10uf 16v 20% x5r 1210

CL32A106MOJNNNE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SAMSUNG
Parts packaging code	1210
package instruction	, 1210
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	10 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	2.5 mm
JESD-609 code	e3
length	3.2 mm
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, EMBOSSED, 7 INCH
positive tolerance	20%
Rated (DC) voltage (URdc)	16 V
size code	1210
surface mount	YES
Temperature characteristic code	X5R
Temperature Coefficient	15% ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
width	2.5 mm

Preview

Download Datasheet

View All

SPECIFICATION



Supplier : Samsung electro-mechanics



Product : Multi-layer Ceramic Capacitor

A. Samsung Part Number

①

Series

②

Size

③

Dielectric

④

Capacitance

⑤

Capacitance

tolerance

⑥

Rated Voltage

⑦

Thickness

16 V

2.5 ± 0.2

②

③

106

④

⑤

⑥

⑦

⑧

⑨

⑩

⑪



Samsung P/N :

CL32A106MOJNNNE



Description :

CAP, 10㎌, 16V, ±20%, X5R, 1210

Samsung Multi-layer Ceramic Capacitor

1210 (inch code)

X5R

㎌

±20 %

L: 3.2 ± 0.3

Sn 100%

Normal

Reserved for future use

Embossed Type, 7" reel

(Pb Free)

2.5 ± 0.2

⑧

Inner electrode

Termination

Plating

⑨

Product

⑩

Special

⑪

Packaging

B. Samsung Reliability Test and Judgement condition

Performance

Capacitance

Tan

(DF)

Insulation

Resistance

Appearance

Withstanding

Voltage

Temperature

characteristics

Adhesive Strength

of Termination

Bending Strength

Solderability

Within specified tolerance

0.075 max.

10,000Mohm or 100Mohm㎌

Whichever is Smaller

No abnormal exterior appearance

No dielectric breakdown or

mechanical breakdown

X5R

(From -55℃ to 85℃, Capacitance change should be within ±15%)

No peeling shall be occur on the

500gF, for 10±1 sec.

terminal electrode

Capacitance change :

within ±12.5% Bending to the limit (1mm)

with 1.0mm/sec.

More than 75% of terminal surface

is to be soldered newly

SnAg3.0Cu0.5 solder

245±5℃, 3±0.3sec.

(preheating : 80~120℃ for 10~30sec.)

Resistance to

Soldering heat

Capacitance change :

Tan

δ,

IR : initial spec.

within ±7.5%

Solder pot : 270±5℃, 10±1sec.

Rated Voltage

60~120 sec.

1㎑±10%

Test condition

1.0±0.2 Vrms

Microscope (×10)

250% of the rated voltage
