H
2.54
Number of
Contacts
Dimensions
A
B
4
6
2.54
5.08
7.62
5.08
7.62
10.16
5.00
2.54
8
10
12
14
16
18
20
Specifications
Material
Insulator:
Standard: Polyamide, Nylon 6T, UL94V-0
Options: Polymer, LCP, UL94V-0
Polyester, PBT, UL94V-0
Contact: Copper Alloy
Plating
Contact: See ordering grid
Electrical
Current Rating: 3 Amp Per Pin
Contact Resistance: 20 mΩ max.
Insulation Resistance : 1000 MΩ min.
Dielectric Withstand Voltage: 600 V AC
Mechanical & Environmental
Operating Temperature: -40°C to +105°C
10.16 12.70
12.70 15.24
15.24 17.78
17.78 20.32
20.32 22.86
22.86 25.40
25.40 27.94
27.94 30.48
30.48 33.02
33.02 35.56
35.56 38.10
38.10 40.64
40.64 43.18
43.18 45.72
45.72 48.26
48.26 50.80
50.80 53.34
53.34 55.88
55.88 58.42
58.42 60.96
60.96 63.50
63.50 66.04
66.04 68.58
68.58 71.12
71.12 73.66
73.66 76.20
76.20 78.74
78.74 81.28
81.28 83.82
83.82 86.36
86.36 88.90
88.90 91.44
91.44 93.98
93.98 96.52
96.52 99.06
99.06 101.60
G
2.54
.0
Ø1
2
Recommended PCB Layout
B±0.38
A±0.25
F
2° Max. Sway & Toe
(Either Direction At The top)
5.00
2.54
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
BG151
BG180
BG225
BG152
BG185
BG160
BG190
2.54
0.64 sq. Pin
D
D±0.2 2.54
E
30mm Maximum
C±0.2
Ordering Grid
BG040
No. of Contacts
04 to 80
C
XX
X
XXXX
XXXX
X
X
Request Samples
and Quotation
Contact Plating
A = Gold Flash All Over
(Standard)
B = Selective Gold Flash Contact Area
/Tin On Tail
C = Tin All Over
G = 10µ" Gold Contact Area/Tin On Tail
I = 30µ" Gold Contact Area/Tin On Tail
Dimension C
(1/100mm) (Post Height)
0300 = 3.00mm
(Standard)
0450 = 4.50mm
(Standard)
0650 = 6.50mm
(Standard)
Or specify custom Post Height
eg 0250 = 2.50mm
(Maximum 2000=20.00mm)
(Minimum 0050=0.50mm)
Packing Options
G = Plastic Box
(Standard)
D = Tube
E = Tube with Cap
Insulator Material
N = Nylon 6T
(Standard)
P = PBT
L = LCP
Dimension D
(1/100mm) (Tail Length)
0300 = 3.00mm
(Standard)
Or specify custom Tail Length
eg 0250 = 2.50mm
(Maximum 2000=20.00mm)
(Minimum 0050=0.50mm)
Part Number
Soldering Process
Nylon 6T (Standard)
IR Reflow: 260°C for 10 sec.
Wave: 230°C for 5-10 sec
Manual Solder : 350°C for 3-5 sec
LCP (Option)
IR Reflow: 260°C for 10 sec.
Wave: 250°C for 5-10 sec.
Manual Solder: 350°C for 3-5sec
PBT (Option )
Manual Solder: 330°C for 3-5sec
(not suitable for hi-temp process)
Mates with
BG120
BG165
BG195
(Subject to Pin Length)
BG121 BG140 BG150
BG166 BG170 BG175
BG200 BG210 BG220
72
74
76
78
80
B
BG121 Recommended mating length 3.00mm
BG166 Recommended mating length 3.00mm
Product Description
BG040
Drawing Date
A
30th October 2006
By
Detail
Revision
Date
CC
BG040
F PCN
F3
06/09/17
Length
2.54mm Pitch Pin Header
Dual Row, Through Hole, Vertical
Tolerances
(Except as Noted)
Angle
1
2
3
4
5
X.° ± 5°
X. ± 0.30
X.X° ± 2°
X.X ± 0.20
X.XX ± 0.15 X.XX° ± 1°
X.XXX ± 0.10 X.XXX° ± 0.5°
Units:
Metric (mm)
C
7
3rd Angle Projection
This drawing is confidential and
copyright of Global Connector
Technology, Ltd (GCT).
This drawing must not be copied
or disclosed without written
consent. E & OE
www.gct.co
Not to
Scale
Drawn By
LYH
Sheet No.
1/1
