1808X821G302SW-B datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> 1808X821G302SW-B

1808X821G302SW-B: DescriptionCeramic Capacitor, Multilayer, Ceramic, 3000V, 2% +Tol, 2% -Tol, X7R, -/+15ppm/Cel TC, 0.00082uF, 1808,; CategoryPassive components capacitor; File Size82KB，1 Pages; ManufacturerCapax Technologies Inc; Websitehttp://www.capaxtechnologies.com/

Download Datasheet Parametric View All

1808X821G302SW-B Overview

Ceramic Capacitor, Multilayer, Ceramic, 3000V, 2% +Tol, 2% -Tol, X7R, -/+15ppm/Cel TC, 0.00082uF, 1808,

1808X821G302SW-B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	890623434
package instruction	, 1808
Reach Compliance Code	compliant
Country Of Origin	USA
ECCN code	EAR99
YTEOL	5.91
capacitance	0.00082 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	2.032 mm
JESD-609 code	e0
length	4.572 mm
multi-layer	Yes
negative tolerance	2%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package form	SMT
method of packing	Waffle Pack
positive tolerance	2%
Rated (DC) voltage (URdc)	3000 V
size code	1808
Temperature characteristic code	X7R
Temperature Coefficient	15% ppm/°C
Terminal surface	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
width	2.032 mm

1808X821G302SW-B Preview

Technologies, Inc

Surface Mount Capacitors:

1808 - X7R, High Voltage

Mechanical Dimensions

Length (L): .180” ± .010”

Width (W): .080” ± .010”

Thickness (T): .080” max

Bandwidth (bw): .030”

1808 SMT Capacitors feature:

•

1808 Case Size

•

High Voltage

•

High Capacitance

•

X7R Dielectric Material

Capacitance Value

Value (pF)

100

150

220

330

470

680

820

1000

1500

1800

2200

2700

3300

3900

4700

5600

6800

8200

10,000 (.01µF)

15,000 (.015µF)

18,000 (.018µF)

Cap. Code

101

151

221

331

471

681

821

102

152

182

222

272

332

392

472

562

682

822

103

153

183

Max Voltage

3000 VDC

Dielectric

X7R

Value (pF)

22,000 (.022µF)

27,000 (.027µF)

33,000 (.033µF)

39,000 (.039µF)

47,000 (.047µF)

56,000 (.056µF)

68,000 (.068µF)

82,000 (.082µF)

100,000 (.10µF)

Cap. Code

223

273

333

393

473

563

683

823

104

Max Voltage

1000 VDC

Dielectric

X7R

500 VDC

X7R

300 VDC

X7R

200 VDC

X7R

2000 VDC

X7R

1000 VDC

X7R

** For Additional Capacitance Values and Working Voltages, Please Contact the Factory **

RDERING

NFORMATION

Case Size

Dielectric

Capacitance

Tolerance

Voltage

Termination

Packaging

Hi-Reli Testing

1808

Mechanical

Dimensions

Shown

Above

X = X7R

822

First 2 digits are

Significant; Third

digit indicates #

of Zeros. Use “R”

for decimal point

Examples:

201 = 200pF

226 = 22µF

D ± 0.5pF

F ±1%

G ±2%

J ±5%

K ±10%

M ±20%

202

T = Tape and

Reel

W = Waffle

Pack

- A

(Optional)

A = Group A

B = Group B

C = Group C

Tested and

Screened

First 2 digits are

S Solder Plated

Over Nickel

Significant; Third

digit indicates

SN Tin over

number of Zeros

Nickel Plated

Examples:

(RoHS Compliant)

201 = 200V

G Gold over

151 = 150V

Nickel Plated

202 = 2000V

(RoHS Compliant)

APAX

ECHNOLOGIES

, I

24842 A

IBBITTS

ALENCIA

, C

91355

661.257.7666

: 661.257.4819

WWW

APAX

ECHNOLOGIES
