PK Series
CHASSIS MOUNT, HIGH PERFORMANCE, MULTIPURPOSE,
SINGLE STAGE EMI/RFI LINE FILTER.
MECHANICAL DIMENSIONS
(Unit: mm)
A1, A2, A3
C
A
2x 4.8
D
B
E
10.0
G
DIMENSIONS
CASE
CODE A
B
C
F
D
E
G
24.4 45.0 17.5 64.5 54.1 8.5 49.6
A1
33.8 45.0 30.0 64.5 54.5 14.9 59.0
A2
46.5 51.8 30.0 70.9 60.9 14.9 71.7
A3
F
FEATURES
51.5
The PK series offers a wide variety of EMI filters in numerous
styles of packages and current ratings. The filters are effective
in reducing both Line-to-Line and Line-to-Ground noise up to
30 Amp at 250VAC. This series offers very low leakage
current suitable for medical and non-medical applications.
These filters are also available for Medical applications.
The absence of C(y) capacitors offers extremely low leakage
current to comply with various industry standards especially
the medical equipment with Switching power supplies.
A Bleeder resistor can also be added to prevent excessive
voltages from developing across the filter capacitors when
there is no load.
B1
85.3
74.7
64.0
39.1
2x
4.8
(14.9)
(4.6)
APPLICATIONS
Computer & networking equipment, Measuring & control
equipment, Data processing equipment, laboratory instruments,
Switching power supplies, other electronic equipment.
G1
100.0
82.5
TECHNICAL DATA
•
Rated Voltage: 115/250VAC
•
Rated Current: 1A, 2A, 3A, 5A, 6A, 10A, 15A, 20A, 30A
•
Power Line Frequency: 50/60Hz
•
Max. Leakage Current each
Line to Ground:
@ 115VAC 60Hz: 0.25mA
@ 250VAC 50Hz: 0.45mA
@ 115VAC 60Hz: 2
µ
A*
@ 250VAC 50Hz: 5
µ
A*
•
Hipot Rating (one minute)
Line to Ground: 2250VDC
Line to Line: 1450VDC
•
Temperature Range: -25C to +85C
* Medical application
105.0
95.3
86.4
38.6
4X 6.5X4.0
50.8
(17.3)
(6.1)
Specifications subject to change without notice. Dimensions (mm).
