DIP Sockets
Table of Models
Decoupling Capacitor DIPs
with Murphy Circuits
Description:
Decoupling Capacitor Socket (MDC)
Material: High Temperature Glass Filled
Thermoplastic* U.L. Rated 94V-0
Index: -60°C to 260°C (-76°F to 500°F)
®
.080
(2.03)
*Note: This product is not RoHS Compliant.
Standard Terminals
Low Profile
.072 Dia.
(1.83)
Additional standard and custom terminals available.
See Terminals section or consult factory.
Type -01
Features:
• Quietest decoupling capacitor
socket available.
• Insert molded circuit with
committed voltage and ground
terminals.
• .014/(.36mm) thick copper circuit
offers excellent electrical and
thermal conductivity.
• Standard decoupling capacitor
values of .01µf, .1µf and .33µf.
Other capacitor values available to
suit your electrical requirements.
• Mounted height above PCB of
.165/(4.19mm).
• Test report available upon request.
.145
(3.68)
.165
(4.19)
.125
(3.18)
.020 Dia.
(.51)
Dimensional Information
.100 Typ.
(2.54)
# of Pins
14
ADVANCED
A
B
16
20
D
C
.080
(2.03)
22
24
.290
(7.37)
Specifications:
Terminals and Contacts:
Terminal: Brass - Copper Alloy
(C36000) ASTM-B-16
Contact: Beryllium Copper -
Copper Alloy
(C17200) ASTM-B-194
Circuit: Copper
Plating:
Terminal: G - Gold over Nickel
T - Tin/Lead over Nickel
Contact: G - Gold over Nickel
T - Tin/Lead over Nickel
Circuit: Tin/Lead*
Gold per ASTM-B-488
Tin/Lead per MIL-P-81728
Nickel per QQ-N-290
.125
(3.18)
.020 Dia.
(.51)
Terminal
Type -01
Shown
24
28
40
A
.300
(7.62)
.300
(7.62)
.300
(7.62)
.300
(7.62)
.300
(7.62)
.600
(15.24)
.600
(15.24)
.600
(15.24)
B
.400
(10.16)
.400
(10.16)
.400
(10.16)
.400
(10.16)
.400
(10.16)
.700
(17.78)
.700
(17.78)
.700
(17.78)
C
.700
(17.78)
.800
(20.32)
1.000
(25.40)
1.100
(27.94)
1.200
(30.48)
1.200
(30.48)
1.400
(35.56)
2.000
(50.80)
D
.600
(15.24)
.700
(17.78)
.900
(22.86)
1.000
(25.40)
1.100
(27.94)
1.100
(27.94)
1.300
(33.02)
1.900
(48.26)
Available Online
• Design your own Decoupling Capacitor DIP Socket
Electrical Schematic
Sectional View
of Capacitor
• Decoupling Capacitor Socket Effectiveness Study
How To Order
MDC
Body Type
Decoupling Capacitor Socket
with Murphy Circuits
DIP Spacing
3 - .300/(7.62mm)
6 - .600/(15.24mm)
3
14
-01
T
G
.01
Capacitance Value
Contact Plating
G - Gold
T - Tin/Lead
Terminal Plating
G - Gold
T - Tin/Lead
Terminal Type
5 Energy Way, West Warwick, RI 02893 USA
Tel: 800.424.9850 | 401.823.5200
Fax: 401.823.8723
info@advanced.com | www.advanced.com
Catalog 16A
Number of Pins
(14 to 40)
Products shown covered by patents issued and/or pending. Specifications subject to change without notice.
inch/(mm)
