1/4" x 1-1/4" Fuseblocks
S-8000 Series
Description
• For 1/4" x 1-1/4" (6.3mm x 32mm) fuses
• Bolt-in and snap-in mounting available
• Tight cluster mounting
• All types of terminal configurations
• Clips made of spring-bronze
• Anti-rotational pin provided
• Flame retardant thermoplastic meets UL 94 VO
Environmental Data
• Temperature Rating (RTI): The mounting body for all
devices (except those with Suffix –1-SNP or –W-SNP),
has a temperature rating of 130°C. The mounting body
for all devices with Suffix –1-SNP has a temperature
rating of 110°C.
Multiple Pole
SPECIFICATIONS
Voltage
Rating
AC
300V
300V
300V
300V
Voltage
Rating
DC
300V
300V
300V
300V
Dimensions
No. of
Poles
1
2
3
4
5
6
7
8
9
10
11
12
Inches
A
*
1 1/8"
1 3/4"
2 3/8"
3"
3 5/8"
4 1/4"
4 7/8"
5 1/2"
6 1/8"
6 3/4"
7 3/8"
B
*
5/8"
1 1/4"
1 7/8"
2 1/2"
3 1/8"
3 3/4"
4 3/8"
5"
5 5/8"
6 1/4"
6 7/8"
Millimeters
A
B
*
*
28.6
15.9
44.4
31.8
60.3
47.6
76.2
63.5
92.1
79.4
108
95.2
123.8
111.1
139.7
127.0
155.6
142.9
171.4
158.8
187.3
174.6
S-8000
S-8100
S-8200
S-8300
Dimensions
S-8000 Single Pole Bolt-In Mounting Series
S-8000 Single Pole Snap-In Mounting Series
Component
Clip
Body
Material
Spring-Bronze, Bright Tin-Lead Plate
Thermoplastic
1/4" x 1-1/4" Fuseblocks
S-8000 Series
PACKAGING CODE
Packaging Code
Blank
BK/
Description
Varies with number of poles. Contact customer service.
Varies with number of poles. Contact customer service.
Example:
BK/S-8001-01-SNP
BK/ S-8 0
"
" "
1
2
3
01 – 01 – SNP
"
"
"
4
5
6
1. Packaging Code:
2. Series Number:
3. Type Terminal:
4. Terminal Angle:
5. Number of Poles:
6. Mounting Style:
BK/
S-8
0 = Solder
1 = 3/16" Quick Connect
2 = 1/4" Quick Connect
3 = Screw
01 = Straight (0°)
02 = 40° Angle
03 = Side*
(01 – 12)
1X = One pole, No Mounting Stud
SNP = Snap-in Mounting
*Available only in single pole
OC-2608 5/03
© Cooper Electronic
Technologies 2003
Visit us on the Web at www.cooperET.com
3601 Quantum Boulevard Boynton Beach, Florida 33426-8638
Tel: +1-561-752-5000 Toll Free: +1-888-414-2645 Fax: +1-561-742-1178
This bulletin is intended to present product design solutions and technical information that will help the end user with design applications. Cooper
Electronic Technologies reserves the right, without notice, to change design or construction of any products and to discontinue or limit distribution of
any products. Cooper Electronic Technologies also reserves the right to change or update, without notice, any technical information contained in this
bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
