DK190V
LCD Digital Panel Meters
Specifications Installation and Operating Instructions
Epic Series - Adjustable Voltage Powered 3½ Digit LCD
FEATURES
}
}
}
}
}
}
}
}
}
}
}
}
}
}
Low-cost,}high-performance}replacement}for}many}} EM}DPMs
O
Optional}RED,}GREEN}or}AMBER}backlighting
Snap-in}bezel}mount}eliminates}mounting}hardware
Resistant}to}RF}and}EMI
3½}digits}with}high-contrast}LCD}
12V}or}24V}DC}voltage-powered}
User-selectable,}displayed}engineering}units}
SPECIFICATIONS
DISPLAY
Digits:
Type:
Backlighting:
Polarity:
Annunciators:
Decimal Points:
Overrange:
3 ½ digits (±1999 counts)
0.45" (11.4 mm) 7 segment LCD
Optional Red Negative
(red numbers/black background)
Optional Green Negative
(green numbers/black background)
Optional Amber Negative
(amber numbers/black background)
automatic, “-” displayed
°F, °C, PSI, %, user-selectable
or V, A, KW, PF
3 position, user-selectable
three lower order digits blank for inputs
>1999 & < -1999
0-10 VDC, 0-5 VDC or 0-200 mV DC
single ended
390 KΩ min.
±(0.1% fs + 2 count)
3 per second
>30 dB @ 60 Hz
span (gain) (2) (10V and 5V) and
zero (offset)
10 minutes typical
± 100 ppm per °C typical
-1999 to +1999
1-2000 counts above adjusted zero
0 to 50 °C
-10 to 60 °C
12 VDC or 24 VDC regulated (selectable)
24 VDC at 35 mA typical
snap-in bezel mount
4 screw terminal (6 with backlight)
ORDERING INFO
PART NUMBER
BACKLIGHT COLOR
BACKLIGHT POWER
SNAP-IN:
DK196* .................................. NEG AMBER ...................................... 24 VDC
DK197* ...................................NEG GREEN ...................................... 24 VDC
.
DK198* .....................................NEG RED ......................................... 24 VDC
DK199* ................................ NO BACKLIGHT .......................................NONE
*Add (P) for Power Engineering Units V, A, KW, PF
ACCESSORIES
PW2-12 ................................... Regulated 120V AC to 12V DC Power Supply
PW2-24 ................................... Regulated 120V AC to 24V DC Power Supply
CVC ..............................................................................................Calibrator
INPUTS
Ranges:
Configuration:
Impedence:
PERFORMANCE
Accuracy:
Conversion Rate:
Normal Mode Rejection:
Adjustments:
Warmup:
Temperature Coeff.:
Offset Range:
Gain Range:
ENVIRONMENT
Operating Range:
Storage Range:
POWER SUPPLY
MOUNTING
CONNECTION
Optional Backlight:
