Prepared
Checked
Approved
Product Specifications
Ref No.
Total Page
Page No.
A-1
7
1
AN17880A
Structure
Appearance
Application
Function
Silicon Monolithic Bipolar IC
SSONF-16D
DIL-16Pin Plastic Package (SO type)
Low Frequency Amplifier
Headphone amplifier IC with Center Amplifier
A
No.
1
2
3
4
5
6
7
8
Item
Storage Temperature
Absolute Maximum Ratings
Symbol
Tstg
Topr
Popr
Gopr
Sopr
Vcc
Icc
P
D
Ratings
-55 ~ +150
-25 ~ +75
1.013x10 ±0.61x10
(1.0 ± 0.6)
9,810
(1,000)
4,900
(500)
5
5
Unit
°C
°C
Pa
(atm)
Note
1
1
2
2
Operating Ambient Temperature
Operating Ambient Pressure
Operating Constant Gravity
Operating Shock
Power Supply V
oltage
Power Supply Current
Power Dissipation
m/s
(G)
m/s
(G)
4.6
200
437
V
mA
mW
2
3
Operating Supply V
oltage Range
Vcc
1.8 V ~ 4.5 V
Note : 1) Ta = 25°C except storage temperature and operating ambient temperature.
Note : 2) At no - signal
Note : 3) At Ta = 70°C on PCB of the standard, 50mmX 50mmX 0.8tmm glass - epoxy.
Eff. Date
9 Nov 2000
FMSC-PSDA-002-01
Eff. Date
Eff. Date
Eff. Date
Matsushita Electronics Corporation
Prepared
Checked
Approved
Product Specifications
Ref No.
Total Page
Page No.
B-1
7
2
AN17880A
B
No.
1
2
3
4
5
6
7
8
9
Item
Electrical Characteristics
(Ambient temperature is 25°C±2°C unless otherwise specified)
Symbol Test
Cct.
Istb
Icq 1
Icq 2
Gv 1
CB
Po
THD
Vno
CT
RR
MT
Condition
Vin = 0mV
STB: ON
Vin = 0mV
C-Amp: OFF
Vin = 0mV
C-Amp: ON
Vout = -22dBv
Vout = -22dBv
THD = 10%
Vcc = 2V
Vout = -12.2dBv
Rg = 600Ω
Vout = -12.2dBv
Vcc = 1.8V,
fr = 100Hz
Vr = -20dBv
Vout = -12.2dBv
Vbeep - in = 0dBv
Limit
Unit Note
Min Typ Max
-
-
-
5.5
-1.0
5.0
-
-
Stand-by current
Quiescent Current 1
Quiescent Current 2
V
oltage Gain 1
Channel Balance
Maximum Power Output
Total Harmonic Distortion
Output Noise Voltage
1
1
1
1
1
1
1
1
1
1
1
1
0.1
1.3
1.6
8.3
0
9.0
0.1
-94.5
50
72
78
-51
5.0
2.6
3.2
10.5
1.0
-
0.5
uA
mA
mA
dB
dB
mW
%
dBv
dB
dB
dB
dBv
1
2
1
2
-88
-
-
Channel Crosstalk
30
64
68
-56
10
Ripple Rejection Ratio
11
Muting Effect
12
Beep Output Voltage
-
-46
Vbeep
Vcc = 2.4V, RL = 16Ω, Frequency = 1KHz, Rg = 10KΩ, Vbeep = 0V (GND), STB: OFF, MUTE: OFF,
unless otherwise specified.
Note : 1) For this measurement, use the filter [ A-Curve ].
2) For this measurement, use the filter [ 30KHz LPF ].
Eff. Date
9 Nov 2000
FMSC-PSDA-002-01
Eff. Date
Eff. Date
Eff. Date
Matsushita Electronics Corporation
Prepared
Checked
Approved
Product Specifications
Ref No.
Total Page
Page No.
C-1
7
3
AN17880A
Description of Test Circuits 1
Test Circuit :
Standby
ON
OFF
14
Mute
ON
BEEP
0.22µF
+
IN2
1µF
OFF
13
16
15
12
11
10
BIAS
Standby
SW
Mute
SW
BEEP
C - Amp
SW
1
2
3
4
5
6
7
8
+
ON
OFF
+
10µF
1µ
16
Ω
OUT2
16
Ω
OUT1
1µF
C-Amp
VCC
Note: The above circuit is used for Latchup testing.
Eff. Date
9 Nov 2000
FMSC-PSDA-002-01
Eff. Date
Eff. Date
Eff. Date
Matsushita Electronics Corporation
+
9
+
10µF
+
22µF
+
10k
+
+
-
-
-
10k
+
IN1
Prepared
Checked
Approved
Product Specifications
Ref No.
Total Page
Page No.
D-1
7
4
AN17880A
Standby
ON
OFF
14
Circuit Function Block Diagram
Mute
ON
BEEP
0.22µF
+
IN2
1µF
10k
+
10µF
+
16
22µF
+
15
OFF
13
12
11
10
9
BIAS
Standby
SW
Mute
SW
BEEP
+
+
+
-
-
-
C - Amp
SW
1
2
3
4
5
6
7
8
+
ON
OFF
C-Amp
+
10k
10µF
1µ
16
Ω
OUT2
16
Ω
OUT1
+
1µF
VCC
IN1
Pin Descriptions
Pin No.
1
2
3
4
5
6
7
8
Pin Descriptions
Ripple Filter
Centre Amplifier Control
Supply Voltage
Ch.2 Output
Centre Amplifier Output
Ch.1 Output
Output Gnd
Ch.1 Input
Pin No.
9
10
11
12
13
14
15
16
Pin Descriptions
Ch.2 Input
Input Gnd
Beep Input
Mute time Control
Mute Control
Standby Control
Bias Output
Bias input
Eff. Date
9 Nov 2000
FMSC-PSDA-002-01
Eff. Date
Eff. Date
Eff. Date
Matsushita Electronics Corporation
Prepared
Checked
Approved
Product Specifications
Ref No.
Total Page
Page No.
E
7
5
AN17880A
Package Name
Unit : mm
SSONF-16D
5.00 ±0.20
16
9
(1.0)
0.15
4.40±0.20
6.40±0.30
+0.10
-0.05
0~10
0.50±0.20
1
8
(0.225)
0.65
0.22
-0.05
+0.10
0.10±0.10
1.20±0.20
SEATING PLANE
SEATING PLANE
Name
of item
( ) : Reference Value
Date
Code
Eff. Date
9 Nov 2000
FMSC-PSDA-002-01
Eff. Date
Eff. Date
Eff. Date
Matsushita Electronics Corporation
