IWS DC-DC Series Data Sheet
Single-Output, 10 Watts
Features
•
•
•
•
•
•
•
•
•
RoHS lead-solder-exemption compliant
Industry-standard package
Industry-standard pinout
85°C case operation
Short-circuit protection
5, 12, 24, and 48V input versions
Input Pi filter and 6-sided shielding
Regulated outputs
500V isolation
Efficiency vs. Load (5V Input)
Description
IWS DC-DC converters offer excellent regulation and
isolation in an industry-standard package. Available in
several input versions, the IWS is perfect for industrial,
datacom, or telecom applications. The IWS features
short-circuit protection and 500 VDC isolation. Please
see the IWD Series for dual-output applications.
Technical Specifications
Input
Voltage Range
5 VDC Nominal
12 VDC Nominal
24 VDC Nominal
48 VDC Nominal
Reflected Ripple
Reverse Input Current
4.5 - 9 VDC
9 - 18 VDC
18 - 36 VDC
36 - 72 VDC
20% Iin Max.
100% Iin Max.
EFFICIENCY %
90
85
80
IWS515
IWS548
75
70
10
20
30
40
50
60
70
80
90
100
LOAD %
Efficiency vs. Load (12V Input)
90
85
80
EFFICIENCY %
Output
Setpoint accuracy
Line regulation Vin Min. - Vin Max., Iout Rated
Load regulation Iout Min. - Iout Max., Vin Nom.
Minimum output current
Dynamic regulation, loadstep
Pk deviation
Settling time
Temperature coefficient
Ripple and noise, 20 MHz BW
Short-circuit protection 1
Current Limit
±1%
±0.5% Vout
±1.0% Vout
10 % Iout Rated
25% Iout
1% Vout
500 µs
0.02%/°C
1% Vout Nom.
Continuous
130%
75
70
65
60
55
50
10
20
30
40
50
60
70
80
90
100
LOAD %
-1205
-1212
-1215
General
Switching Frequency
Isolation
Input - Output
500 VDC
500 VDC
500 VDC
109 Ohms
-25 to +85°C
-40 to +85°C
-40 to +125°C
95%
5 g, 10 - 55 Hz
UL, cUL, TUV
1.4 oz
Input - Case
Output - Case
Isolation Resistance - Input to Output
Standard Case Operating Range
Industrial Range (add -I to p/n)
Storage Range
Humidity Max., Non-Condensing
Vibration, 3 Axes, 5 Min Each
Safety
Weight (approx.)
300 kHz
Notes
1 Continuous short-circuit protection is provided. Long-term continuous
operation in this mode is not recommended. Converter will auto-restart
once fault has been removed.
Specifications typically at 25°C, normal line, and full load, unless
otherwise stated.
Soldering Conditions: I/O pins, 260°C, ten seconds; fully compatible with
commercial wave-soldering equipment.
Safety: Agency approvals may vary from model to model. Please
consult factory for specific model information.
MCD10072 Rev. 1.0
Page 1 of 3
www.power-one.com
IWS DC-DC Series Data Sheet
Single-Output, 10 Watts
Model Selection
MODEL
INPUT VOLTAGE
(VOLTS)
INPUT VOLTAGE
RANGE (VOLTS)
MAXIMUM INPUT
CURRENT (AMPS)*
OUTPUT
VOLTAGE (VOLTS)
RATED OUTPUT
CURRENT (AMPS)
RIPPLE & NOISE
pk-pk (mV)
TYPICAL
EFFICIENCY**
IWS505
IWS512
IWS515
IWS524
IWS548
IWS1212
IWS1215
IWS1224
IWS1248
IWS2405
IWS2415I
IWS2424
IWS2448
IWS4802.1
IWS4803.3
IWS4805
IWS4812
IWS4815
IWS4824
IWS4848
NOTES:
5
5
5
5
5
12
12
12
12
24
24
24
24
48
48
48
48
48
48
48
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
4.5 - 9
9 - 18
9 - 18
9 - 18
9 - 18
18 - 36
18 - 36
18 - 36
18 - 36
36 - 72
36 - 72
36 - 72
36 - 72
36 - 72
36 - 72
36 - 72
3.20
3.70
3.45
3.60
3.55
1.80
1.65
1.75
1.75
0.88
1.00
0.95
0.90
0.85
0.94
0.85
0.96
1.00
0.45
0.45
5
12
15
24
48
12
15
24
48
5
15
24
48
2.1
3.3
5
12
15
24
48
2.00
1.00
0.75
0.50
0.25
1.00
0.75
0.50
0.25
2.00
0.80
0.50
0.25
3.80
3.00
2.00
1.00
0.80
0.50
0.25
100
120
150
240
480
120
150
240
480
100
150
240
480
75
100
100
120
150
240
480
78%
80%
82%
83%
84%
82%
84%
85%
86%
78%
82%
85%
86%
67%
73%
80%
84%
82%
85%
89%
* Maximum input current at minimum input voltage, maximum rated output power.
** At nominal Vin, rated output.
Model numbers highlighted in yellow or shaded are not recommended for new designs.
MAY 28, 2004 revised to MAY 31, 2006
Page 2 of 3
www.power-one.com
IWS DC-DC Series Data Sheet
Single-Output, 10 Watts
Mechanical Drawing
-0.60"(-15.2mm)
1.00"
(25.4mm)
0.18" MIN.
(4.6mm)
0
3
4
2.00"
(50.8mm)
1
2
DIA 0.040"
(1.0mm)
0.800"(20.3mm)
0
-0.10"
(-2.5mm)
0.500"
(12.7mm)
0.300"
(7.6mm)
0.800"
BOTTOM VIEW
0.40"
(10.2mm)
(20.3mm)
Thermal Impedance
Natural
Convection
100 LFM
200 LFM
300 LFM
400 LFM
15.4 °C/W
12.2 °C/W
9.3 °C/W
7.4 °C/W
6.4 °C/W
Pin
1
2
3
4
Function
+Vin
-Vin
+ Vout
- Vout
Inches:
.XX ± 0.040
.XXX ± 0.010
Pin:
± 0.002
Case:
+0.04, -0.00
Tolerances
(Millimeters)
.X ± 1.0
.XX ± 0.25
± 0.05
+1.0, -0.0
Note:
Thermal impedance data is dependent
on many environmental factors. The
exact thermal performance should be
validated for specific application.
(Dimensions as listed unless otherwise
specified.)
NUCLEAR AND MEDICAL APPLICATIONS - Power-One products are not designed, intended for use in, or authorized for use as critical components
in life support systems, equipment used in hazardous environments, or nuclear control systems without the express written consent of the respective
divisional president of Power-One, Inc.
TECHNICAL REVISIONS - The appearance of products, including safety agency certifications pictured on labels, may change depending on the date
manufactured. Specifications are subject to change without notice.
MCD10072 Rev. 1.0
Page 3 of 3
www.power-one.com
