Security & Chip Card ICs
SLE 66CLX641P
16-Bit High Security Contactless Controller
ISO/IEC 14443 Type A & B Compliant Interfaces
For Contactless Operation
with Memory Management and Protection Unit
in 0.22 µm CMOS Technology
136-Kbyte ROM, 5-Kbyte RAM, 64-Kbyte EEPROM
1100-Bit Advanced Crypto Engine
supporting RSA and Elliptic Curve GF(p)
112-Bit / 192-Bit DDES-EC2 Accelerator
supporting DES, 3DES and Elliptic Curve GF(2
n
)
Short Product Information
April 2004
SLE 66CLX641P Short Product Information
Ref.: SPI_SLE66CLX641P_0404.doc
This document contains preliminary information on a new product under development.
Details are subject to change without notice.
Revision History: Current Version 2004-04-27
Previous Releases: 2004-04-01
Page
Important:
Further information is confidential and on request. Please contact:
Infineon Technologies AG in Munich, Germany,
Security & Chip Card ICs,
Tel +49 - (0)89 234-80000
Fax +49 - (0)89 234-81000
E-Mail: security.chipcard.ics@infineon.com
Published by Infineon Technologies AG, SMS Security Applications Group
St.-Martin-Strasse 53, D-81541 München
© Infineon Technologies AG 2004
All Rights Reserved.
To our valued customers
We constantly strive to improve the quality of all our products and documentation. We have spent an exceptional
amount of time to ensure that this document is correct. However, we realise that we may have missed a few things. If
you find any information that is missing or appears in error, please use the contact section above to inform us. We
appreciate your assistance in making this a better document.
Attention please!
The information herein is given to describe certain components and shall not be considered as warranted
characteristics.
Terms of delivery and rights to technical change reserved.
We hereby disclaim any and all warranties, including but not limited to warranties of non-infringement, regarding
circuits, descriptions and charts stated herein.
Infineon Technologies is an approved CECC manufacturer.
Information
For further information on technology, delivery terms and conditions and prices please contact your nearest Infineon
Technologies Office in Germany or our Infineon Technologies Representatives world-wide (see address list).
Warnings
Due to technical requirements components may contain dangerous substances. For information on the types in
question please contact your nearest Infineon Technologies Office.
Infineon Technologies Components may only be used in life-support devices or systems with the express written
approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the failure of
that life-support device or system, or to affect the safety or effectiveness of that device or system. Life support devices
or systems are intended to be implanted in the human body, or to support and/or maintain and sustain and/or protect
human life. If they fail, it is reasonable to assume that the health of the user or other persons may be endangered.
µµ
SLE 66CLX641P
16-Bit High Security Contactless Controller
ISO/IEC 14443 Type A &B Compliant Interfaces
For Contactless Operation with MMU in 0.22 µm CMOS Technology
136-Kbyte ROM, 5-Kbyte RAM, 64-Kbyte EEPROM
1100-Bit Advanced Crypto Engine supporting RSA and Elliptic Curve GF(p) and
112-Bit / 192-Bit DDES-EC2 Accelerator
supporting DES, 3DES and Elliptic Curve GF(2n)
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
Enhanced
low power 8051 CPU with
extended addressing modes for
contactless smart card applications
Instruction set opcode compatible with
standard 8051 processor with additional
powerful instructions optimized for smart
card application
Enhanced architecture with
execution time
6 times faster (18 times using PLLmax)
than standard 8051 processor at same
external clock
134 Kbytes User ROM
for operating system
and application (programs & data)
2 Kbytes reserved ROM for
Resource
Management System
(RMS_E)
with
Contactless Optimized EEPROM
write/erase routines
64 Kbytes Secure EEPROM in SuperSlim
technology for application program and
data
4k bytes XRAM, 700 bytes Crypto-RAM
and 256 bytes internal RAM for fast data
processing
Memory Management Unit
Certified True Random Number Generator
Dual Key Triple DES (DDES) &
GF (2
n
) Elliptic Curve (EC2) Accelerator
Advanced Crypto Engine for Elliptic
Curve GF(p) and up to 2048 bits RSA
computation
CRC Module according to ISO/IEC 3309
supporting CCIT v.41 & HDLC X25
8 Interrupt Vectors Module with 3 priority
levels to ensure real time operation
•
•
•
•
PLL: to speed up the internal CPU clock
frequency up to 15MHz
(optional use)
Two 16-bit Timer with interrupt capability for
protocols, security checks & watch dog
implementations
Power saving sleep mode
Temperature range:
contact-less: -25°C to +70°C
Full operation of Contactless interface
controlled by Operating System
enhances Security Level
Contactless Interface
Interface according to ISO/IEC 14443 for
both Type A and Type B
Carrier frequency 13.56 MHz
Data rate
106 Kbit/s in type A operation
up to 848 Kbit/s in type B operation
Anticollision & Transmission Protocol
supported by open source application
notes for both Type A & B
Flexible Internal CPU clock frequency:
fully configurable from 1.7MHz up to
15 MHz
256 bytes buffer for contactless data
exchange (FiFo circular architecture)
Parallel operation of CPU, Peripherals like
DES, CRC and Contactless Interface
possible for High Demanding Contactless
Applications
•
•
•
•
•
•
•
Short Product Information
3 / 11
2004-04-27
µµ
SLE 66CLX641P
EEPROM (SuperSlim Technology)
•
•
•
•
•
•
•
•
•
Secure chip and firmware design
Byte wise EEPROM programming and read
accesses
Versatile & Flexible page mode for 1 to 256
bytes write/erase operation
32 bytes security area including:
- 16 bytes chip unique identification number
- 16 bytes PROM area (OTP like)
Fast personalisation mode 1.5 ms
Typical Page Erase time < 2.5ms
Typical Page Writing time < 1.8 ms
Minimum of 100.000 Write/erase cycles
1)
Data retention for a minimum of 10 years
1)
EEPROM programming voltage generated
on chip
•
•
•
•
•
•
•
•
•
•
•
•
Memory Management and Protection
Unit
•
•
•
•
•
Code execution from XRAM possible
Security Features
Operation state monitoring mechanism
The chip goes in a secure reset state on any
following sensors alarm:
•
Low and high voltage sensors
•
Internal voltage sensor
•
Frequency sensors and filters
•
Light sensor
•
Glitch sensor
•
Temperature sensor
•
Life Test Sensor
•
Internal power-on reset sensor
•
Active Shield with automatic and user
controlled attack detection
1)
Addressable memory up to 1 Mbytes
Separates OS (system mode) and
Application (application mode)
System routines called by traps
Access Restrictions to peripherals in
application mode controlled by OS
Security scrambled & optimized chip layout
against physical chip manipulation
Memory encryption/decryption module
(MED) for XRAM, ROM and EEPROM
against reverse engineering and power
attacks
ROM code not visible due to implantation
Mask dependant ROM code encrypted
during production
Chip Unique encryption of the XRAM and
EEPROM
Flexible encryption of part or whole
EEPROM by additional user-defined key
16 byte Unique chip identification number
for anti-clone countermeasure & tracking
16 bytes security PROM hardware
protected (OTP like)
Secure start of the operating system
ensured by certified Self Test Software
(STS)
Certified EEPROM programming routines
(RMS_E)
True Random Number Generator with
Firmware test function
High Speed SPA/DPA resistant Triple DES
(DDES) Accelerator and Advanced Crypto
Engine
Anti Snooping
•
HW-countermeasures against SPA/DPA-,
Timing- and DFA-attacks (differential fault
analysis)
Supported Standards
•
•
•
•
•
EMV 2000
ISO/IEC 14443
ISO/IEC 3309
CCIT v.41
HDLC X25
Values are temperature dependant
Short Product Information
4 / 11
2004-04-27
µµ
SLE 66CLX641P
Application Support
•
•
•
•
•
•
•
•
•
HW-& SW-Tools (Emulator, ROM Monitor,
Card Emulator, Simulator,
Evaluation Kit
Proximity (
Contactless Reader package),
SmartMask™ package, Simulated Reader
Software, etc.)
Open Source Application Notes Tutorial
(e.g.: DES and 3DES, Crypto Library,
Anticollision and Contactless Transmission
Protocols for both Type A and B, Card Coil
Design Guide, Card Coil Antenna Reference
Design List, etc.)
Certified CC EAL5+ Crypto Library
Worldwide Application Engineer Team and
customer dedicated Field Application
Engineers
Regular Customer trainings on
Cryptography, Contactless and Dual
interface controllers including ISO/IEC 14443
related topics
On-site trainings available on request
•
•
•
•
•
•
•
•
•
•
Chip Qualification report
Chip delivery specification for wafer with
chip-layout (die size, orientation, ...)
Module specification containing description
of package, etc.
Module Qualification report
Development Tools Overview
Software Development Kit SDK CC
Card Emulator CE66P Dual Interface
ROM Monitor RM66P-II with stand alone
functionality for ROM mask qualification in
the end user system
Emulator ET66P Hitex or ET66P KSC
Smart Mask™ Package for chip evaluation
Smart Mask™ Pure Contactless modules
(supplied by Infineon) supporting both
ISO/IEC 14443 Type A & B for implantation
process testing and production setup
Evaluation Kit Proximity (Contactless reader
package)
•
Document References
Confidential Data Book SLE 66CxxP
Confidential Instruction Set SLE 66CxxP
Confidential Quick Reference SLE 66CxxP
Short Product Information
5 / 11
2004-04-27
