BA6161FE2 Overview

SWITCHING REGULATOR, PDSO8, SOP-8

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	LSOP,
Contacts	8
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
Maximum input voltage	16 V
Minimum input voltage	4.5 V
JESD-30 code	R-PDSO-G8
JESD-609 code	e3/e2
length	5 mm
Number of functions	1
Number of terminals	8
Package body material	PLASTIC/EPOXY
encapsulated code	LSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.7 mm
surface mount	YES
Terminal surface	TIN/TIN COPPER
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
width	4.4 mm
Base Number Matches	1

Regulator ICs

Switching regulator for electronic tuning

BA6161N / BA6161F

The BA6161N and BA6161F are switching regulators that contain a temperature compensation circuit. They can be used

for electronic tuning DC-DC converters.

FApplications

Electronic tuners in televisions and other electronic

equipment that requires high voltage (30X45V).

FFeatures

1) Output changes are small against input voltage vari-

ations.

2) Temperature compensation circuit provides stable

output.

FBlock

diagram

3) Reduced number of attached parts.

FPin

descriptions

261
