FINAL ACCEPTED ORDER DATE [2013/09]
LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
HXC
HXC
SERIES
105℃ High Ripple, Snap-in Terminal Type
◆FEATURES
・
Load Life : 105℃ 2000 hours.
・
Higher ripple current endurance than MXC series.
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−25∼＋105℃
200, 400, 450V.DC
±20％
（20℃，
120Hz）
I＝3
CV (After 5 minutes application of rated voltage)
Leakage Current(MAX)
I＝
Leakage Current
(μA)
Rated Voltage
(V)
tanδ
Rated Voltage
(V)
Z
（−25℃） （20℃）
/Z
C＝
Rated Capacitance
(μF)
450
0.20
400∼450
（120Hz）
8
V＝
Rated Voltage
(V)
(tanδ)
Dissipation Factor(MAX)
200∼400
0.15
200
3
（20℃，
120Hz）
Impedance Ratio(MAX)
After applying rated voltage with rated ripple current for 2000hrs at 105℃, the capacitors shall meet
the following requirements.
Capacitance Change
Endurance
Dissipation Factor
Leakage Current
Not more than 200％ of the specified value.
Not more than the specified value.
Within ±20％ of the initial value.
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
Frequency
Coefficient
（Hz）
200WV
60 50） 120
（
0.80
1.00
1.00
500
1.20
1.20
1k
1.30
1.25
10k≦
1.50
1.40
400∼450WV 0.80
◆PART NUMBER
□□□
Rated Voltage
HXC
Series
□□□□□
Rated Capacitance
□
Capacitance Tolerance
□□□
Option
SN
Terminal Code
D×L
Case Size
◆Option
Code
PET Sleeve without plate
PVC Sleeve without plate
PVC Sleeve with plate
◆DIMENSIONS
●SN
［4(3.5)mm½
terminal type
（mm）
EFC
OOE
Blank
VENT
SLEEVE
2-φ2
NEGATIVE
10
10
±0.1
L±2
※
4±0.5
φD±1
φD±1
MOUNTING HOLES
※For φ35, 3.5±0.5
LARGE CAN TYPE ALUMINUM ELECTROLYTIC CAPACITORS
HXC
◆STANDARD SIZE
WV
Cap
(μF)
φD
200
φ22
22×25
22×30
22×35
22×40
22×45
22×50
1.64
1.89
2.14
2.41
2.71
3.06
φ25
φ30
φ35
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
25×25
25×30
25×35
25×35
25×45
25×50
1.99
2.32
2.63
2.81
3.32
3.72
30×25
30×25
30×30
30×30
30×35
30×40
30×50
2.27
2.43
2.82
2.94
3.36
3.78
4.48
35×25
35×30
35×35
35×40
35×45
35×50
2.56
3.07
3.57
4.01
4.44
4.90
WV
Cap
(μF)
φD
400
φ22
22×30
22×35
22×40
22×45
22×50
0.81
0.99
1.19
1.43
1.60
φ25
25×25
25×30
25×35
25×40
25×45
25×50
0.99
1.19
1.43
1.61
1.83
2.06
φ30
φ35
82
100
120
150
180
220
270
330
390
470
560
30×25
30×30
30×35
30×40
30×45
30×50
1.41
1.61
1.84
2.10
2.36
2.62
35×30
35×35
35×40
35×45
35×50
2.00
2.29
2.56
2.86
3.15
WV
Cap
(μF)
φD
450
φ22
22×30
22×35
22×40
22×45
0.67
0.81
0.99
1.19
φ25
25×25
25×30
25×35
25×40
25×45
25×50
0.81
0.99
1.19
1.49
1.68
1.89
φ30
φ35
68
82
100
120
150
180
220
270
330
390
470
30×25
30×30
30×35
30×40
30×45
30×50
1.19
1.49
1.70
1.92
2.18
2.45
35×25
35×25
35×30
35×35
35×40
35×45
35×50
1.49
1.61
1.85
2.12
2.41
2.67
2.97
Ripple Current (A r.m.s./120Hz, 105℃)
Case Size φD×L(mm)
