TS-Series Specifications
A
–
15.75D x 3.93H (mm)
B
–
15.75D x 6.73H (mm)
PDI
TS-Series
is a cold-welded hermetically sealed quartz crystal in a
TO8 through-hole package. This crystal, designed to meet your most demanding
specification, is available in standard or custom frequencies and/or with customized
parameters. PDI provides quick-turn sampling for your proto-typing needs,
mass production capability, and competitive pricing.
ex)
TS—25000X—F—B—C—B—18—A—X
*
FREQUENCY
08000X – 99999X
=
8.0000MHz -
99.999MHz -
C10000 – C20000
=
100.00MHz -
200.00MHz -
MODE
F
= Fundamental
3
= 3rd Overtone
5
= 5th Overtone
TOLERANCE
@ 25°C
A
= ±10
B
= ±25
C
= ±50
S
= Special
FREQUENCY
STABILITY **
B
= ±25
C
= ±50
E
= ±100
S
= Special
OPERATING
TEMPERATURE
A
= 0 to +70°C
B
= -20 to +70°C
D
= -40 to +85°C
E
= -55 to +125°C
S
= Special
LOAD
08-99
= pF
SE =
Series
HEIGHT
A
= 3.93 (mm)
B
= 6.73 (mm)
** - AT-Cut Only.
*(X) for standard or assigned for custimization.
Parameter (AT-Cut)
Frequency Range
Frequency Tolerance
Temperature Range
Frequency Stability
(AT-Cut Only)
Turning Point (Typical)
(Doubly Rotated Cuts Only)
Equivalent Series Resistance
(AT-Cut) (Max)
Equivalent Series Resistance
(Doubly Rotated Cuts) (Max)
Drive Level (Typical)
Shunt Capacitance (Maximum)
Load Capacitance (Typical)
Aging (Per Year Max)
Seal Method
Insulation Resistance
AT-Cut
Doubly Rotated Cuts
@ +25°C
Operating
Storage
Over Operating Temperature
Mode
Fundamental
3.0000 to 25.0000
3rd Overtone
5th Overtone
Units
MHz
ppm
°C
°C
ppm
°C
Ω
8.0000 to 50.0000 50.0000 to 100.0000
Per Option
Per Option
- 55 to +125
Per Option
+55 to +105 (Mode, Cut, Frequency Dependent)
3.000000 to 25.000000 MHz
8.000000 to 50.000000 MHz
50.000000 to 100.000000 MHz
3.000000 to 25.000000 MHz
8.000000 to 50.000000 MHz
50.000000 to 100.000000 MHz
50
50
90
60
60
110
100
7.0
Per Option
±1.0
±0.5
Cold Weld
500MΩ Minimum @100Vdc ±15V
Ω
uW
pF
pF
ppm
REV:
NA
SIZE:
A
CAGE:
A
1
of
2
TS-Series
15.75D x 6.73H or 3.93H(mm)
PA C K A G E D I M E N S I O N S
Decimal XXX = ± .008, XX = ± .02 Metric [XXX = ± .20], [XX = ± .50]
PIN
1
2
3
4
5
CONNECTION
Crystal
No Connect
Crystal
No Connect
Ground
FREQUENCY
PDI P/N
DATE CODE
Traceability Code
.620 Max.
[15.75 Max.]
.515 Max
[13.08 Max.]
"H" Dimension
A
B
.155 [3.93]
.265 [6.73]
"H"
.500 MIN
[12.70 Min.]
.018 ±.002
[.46 ±.05]
.032
[.81]
4
5
1
.200 ±.008
[5.08 ±.20]
3
2
.200 ±.008
[5.08 ±.20]
NOTES:
Other options are available, please consult factory.
All product is supplied
RoHS
and
REACH
compliant.
Product can be supplied on Tape and Reel, on reels of 1,000 units.
Specifications subject to change without notice, last updated 4/1/13.
REV:
NA
SIZE:
A
CAGE:
A
2
of
2
