DL4936-TP: DescriptionRectifier Diode, 1 Element, 1A, 400V V(RRM), Silicon, MELF-2; CategoryDiscrete semiconductor diode; File Size306KB，4 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

DL4936-TP Overview

Rectifier Diode, 1 Element, 1A, 400V V(RRM), Silicon, MELF-2

DL4936-TP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Parts packaging code	MELF
package instruction	MELF-2
Contacts	2
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	METALLURGICALLY BONDED, LOW LEAKAGE CURRENT
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	O-PELF-R2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	400 V
Maximum reverse recovery time	0.2 µs
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal form	WRAP AROUND
Terminal location	END
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

MC C

•

NOT RECOMMENDED FOR NEW DESIGNS

USE

S1A-L ~

S1J-L SERIES

S1AE ~

S1JE SERIES

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

DL4933

THRU

DL4937

1 Amp Glass

Passivated, Fast

Recovery Rectifier

50 to 600 Volts

MELF

Cathode Mark

Features

Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates

RoHS Compliant. See ordering information)

Case Material:Molded Plastic.

Epoxy meets UL 94 V-0 flammability rating

Moisture Sensitivity Level 1

Low Leakage Current

Metalurgically Bonded Construction

Surface Mount Applications

Glass Passivated Junction

•

Maximum Ratings

•

Operating Temperature: -55°C to +150°C

Storage Temperature: -55°C to +150°C

Maximum Thermal Resistance; 30

°C/W

Junction To Lead

MCC

Catalog

Number

Device

Marking

Maximum

Recurrent

Peak

Reverse

Voltage

50V

100V

200V

400V

600V

Maximum

RMS

Voltage

Maximum

Blocking

Voltage

DL4933

DL4934

DL4935

DL4936

DL4937

---

35V

70V

140V

280V

420V

50V

100V

200V

400V

600V

DIM

INCHES

MIN

.190

---

.095

DIMENSIONS

Electrical Characteristics @ 25°C Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum

Instantaneous

Forward Voltage

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Maximum Reverse

Recovery Time

Typical Junction

Capacitance

F(AV)

FSM

1.0A

30A

=55°C

8.3ms, half sine

MAX

.205

.022

.105

MIN

4.80

---

2.40

MAX

5.20

.55

2.67

NOTE

Nominal

∅

1.3V

= 1.0A;

= 25°C

SUGGESTED SOLDER

PAD LAYOUT

.220”

5.0µA

100µA

200ns

= 25°C

= 125°C

=0.5A,

=1.0A,

=0.25A

Measured at

1.0MHz,

=4.0V

.115”

.035”

15pF

*Pulse test: Pulse width 300

µsec,

Duty cycle 1%

Notes: 1.

High Temperature Solder Exemption Applied, see EU Directive Annex Notes 7.

Revision:

www.mccsemi.com

1 of 4

2011/11/14
