3-338240-2 Product Details
Live Product Chat
Product View
Standard Board Mount Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-338240-2
T E I nternal N umber: 3 - 3 3 8 2 4 0 - 2
Product Highlights:
l
Number of Positions = 25
l
Plug
l
PC B Mount Angle = Vertical
l
Product Series = HDP-20
l
With Mating C onnector Lock
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
HDP-20 SIZE 3 VERTIC AL+ PLUG HEADER; PRESS-FIT VERSION
(PDF, English)
Catalog Pages/Data Sheets:
l
AMPLIMITE SUBMINATURE D TYPE C ONNEC TORS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Number of Positions
= 25
l
Gender
= Plug
l
PC B Mount Angle
= Vertical
l
Product Series
= HDP-20
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type = Screwlocks, UNC 4-40
l
PC B Retention Feature
= Yes
l
Shell Type
= Front Metal Shell
l
Shell Size
= 3
l
Footprint (mm [in])
= 5.99 [.236]
l
PC B Thickness (in [mm])
= 0.063 [1.60]
l
Grounding Indents
= Without
l
Grounding Straps
= Without
l
PC B Mount Style
= Through Hole
l
C olor C ode
= None
l
Sealed = No
l
C olor = Black
l
Shell Material = Steel
l
C omment = C onnector has boardlocks which have to be clinched
onto the PC B for a perfect grounding performance.
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Grounding C lips
= Without
l
Termination Post Length (mm [in])
= 4.50 [0.177]
l
Solder Tail C ontact Plating
= Tin
Body Related Features:
l
PC B Retention Method
= AC TION PIN (C ompliant) Posts
l
Shell Plating = Tin
l
Bushing Material = Brass
l
Bushing Material Plating = Tin
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
l
Approved Standards = DIN 41652
l
Performance Level = Level 2
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Operation/Application:
l
Application = Standard
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
