SPECIFICATION CONTROL DRAWING
TITLE
82A3121
Date
Revision
TWO CONDUCTOR CABLE, SHIELDED, UNJACKETED
9-9-04
C
This specification sheet forms a part of the latest issue of Raychem Specification 80
COMPONENT WIRES- 82A0111
SHIELD - TIN-COATED COPPER
CONSTRUCTION DETAILS
PART NUMBER
1/
CONDUCTOR
SIZE
(AWG)
28
26
24
22
20
18
16
14
12
10
SHIELD
SIZE
(AWG)
OUTSIDE DIAMETER
(inches)
NOMINAL
.075
.083
.091
.103
.123
.145
.175
.215
.259
.335
MAXIMUM
.080
.088
.096
.108
.129
.152
.184
.226
.272
.352
MAXIMUM
WEIGHT
(lb/1000 ft)
4.9
6.0
7.8
9.9
13.4
19.4
27.8
42.3
61.1
103.2
82A3121-28-*
82A3121-26-*
82A3121-24-*
82A3121-22-*
82A3121-20-*
82A3121-18-*
82A3121-16-*
82A3121-14-*
82A3121-12-*
82A3121-10-*
38
38
38
38
38
38
38
38
38
36
CABLE RATINGS AND ADDITIONAL REQUIREMENTS
The "*" in the part number above shall be replaced
by color code designators with a slash separating
the component wire colors.
1/ Example: black and brown component wires:
82A3121-22-0/1
TEMPERATURE RATING: 150°C
Maximum continuous conductor temperature
VOLTAGE RATING: 600 volts (rms) at sea level
DIELECTRIC WITHSTAND: 1500 volts (rms), 60 Hz
SHIELD COVERAGE: 85% (minimum)
Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice.
Tyco Electronics also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer.
1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. HOWEVER, DUE TO LENGTH LIMITATIONS OF THE RAYCHEM PART NUMBER,
AN ALTERNATIVE COLOR CODE MAY REPLACE MIL-STD-681 COLOR CODE DESIGNATORS. (EXAMPLE: “901/902...” MAY BE REPLACED BY “Axxx”.) OTHER CODES AND
SUFFIXES MAY BE ADDED TO THE PART NUMBER, AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER.
DIMENSIONS ARE IN INCHES, AND UNLESS OTHERWISE DESIGNATED ARE NOMINAL.
R
Wire & Cable
501 Oakside Avenue
Redwood City, CA 94063-3800
Phone: 1-800-227-8816
Fax: 1-650-361-6297
Page 1 of 1
THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN.
REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID.
