EH25 Series Oscillator
Quartz Crystal Clock Oscillators XO (SPXO) HCMOS/TTL (CMOS) 5.0Vdc 4 Pad 5.0mm x 7.0mm Ceramic Surface Mount (SMD)
2011/65 +
2015/863
168 SVHC
Revision G 06/08/2012
Electrical Specifications
Nominal Frequency
1.000MHz to 155.520MHz
Some frequencies within this range may not be available.
Frequency Tolerance/Stability
(Inclusive of all conditions: Calibration Tolerance at 25°C, Frequency
Stability over the Operating Temperature Range, Supply Voltage
Change, Output Load Change, First Year Aging at 25°C, Shock, and
Vibration)
±100ppm Maximum
±50ppm Maximum
±25ppm Maximum
±20ppm Maximum
±5ppm/year Maximum
0°C to +70°C
-40°C to +85°C
5.0V
DC
±10%
No Load
50mA Maximum
I
OH
= -16mA
2.4V
DC
Minimum with TTL Load, V
DD
-0.4V
DC
Minimum with HCMOS
Load
I
OL
= +16mA
0.4V
DC
Maximum with TTL Load, 0.5V
DC
Maximum with HCMOS Load
50 ±10(%) Measured at 1.4V
DC
with TTL Load or at 50% of waveform
with HCMOS Load from 1MHz to 70MHz Measured at 50% of waveform
above 70MHz
50 ±5(%) Measured at 50% of waveform
Measured at 0.8V
DC
to 2.0V
DC
with TTL Load; Masured at 20% to 80%
of waveform with HCMOS Load
6nSec Maximum from 1MHz to 70MHz
4nSec Maximum from 70.000001MHz to 155.520MHz
10 TTL Load or 50pF HCMOS Load Maximum from 1MHz to 70MHz
5 TTL Load or 15pF HCMOS Load Maximum from 70.000001MHz to
155.520MHz
CMOS
Tri-State (High Impedance)
+2.2V
DC
Minimum to Enable Output, +0.8V
DC
Maximum to Disable
Output (High Impedance), No Connect to Enable Output
±250pSec Maximum, ±100pSec Typical
±50pSec Maximum, ±30pSec Typical
Aging at 25°C
Operating Temperature Range
Supply Voltage
Input Current
Output Voltage Logic High (V
OH
)
Output Voltage Logic Low (V
OL
)
Duty Cycle
Rise Time/Fall Time
Load Drive Capability
Output Logic Type
Pin 1 Connection
Tri-State Input Voltage (Vih and Vil)
Absolute Clock Jitter
One Sigma Clock Period Jitter
1 of 10
28-Jan-2016 1:03 PM
Ecliptek | EH25 Series Oscillator
http://www.ecliptek.com/oscillators/EH25/
Mechanical Dimensions
All Dimensions in Millimeters
Pin 1: Tri-State
Pin 2: Case/Ground
Pin 3: Output
Pin 4: Supply Voltage
Marking Specifications
Line 1:
Line 2:
ECLIPTEK
XXXXXXM
XXXXXX = Nominal Frequency (5 Digits + Decimal)
M = Frequency unit of measure (MHz)
XXXXX
XXXXX = Ecliptek Manufacturing Identifier
Line 3:
3 of 10
28-Jan-2016 1:03 PM
Ecliptek | EH25 Series Oscillator
http://www.ecliptek.com/oscillators/EH25/
Environmental and Mechanical Specifications
ESD Susceptibility
Fine Leak Test
Flammability
Gross Leak Test
Mechanical Shock
Moisture Resistance
Moisture Sensitivity
Resistance to Soldering Heat
Resistance to Solvents
Solderability
Temperature Cycling
Vibration
Thermal Resistance (θ
JA
)
Thermal Resistance (θ
JC
)
MIL-STD-883, Method 3015, Class 1, HBM:1500V
MIL-STD-883, Method 1014, Condition A
UL94-V0
MIL-STD-883, Method 1014, Condition C
MIL-STD-883, Method 2002, Condition B
MIL-STD-883, Method 1004
J-STD-020, MSL 1
MIL-STD-202, Method 210, Condition K
MIL-STD-202, Method 215
MIL-STD-883, Method 2003
MIL-STD-883, Method 1010, Condition B
MIL-STD-883, Method 2007, Condition A
42°C/W (degrees Celsius per Watt)
15°C/W (degrees Celsius per Watt)
4 of 10
28-Jan-2016 1:03 PM
