TMC
standard tantalum chip capacitor
features
•
•
•
•
•
•
Epoxy molded body, UL94V0 flammability
EIA-US and EIA-Japan compatible sizes
100% burn-in and end-of-line testing
Extended values per case size
Excellent humidity and solder resistance
Marking: Black body color with white marking
dimensions and construction
L
W1
t
Side
Case Size
(Inch Size Code)
L
W1
Dimensions
inches
(mm)
W2
t
d
g
P
(2012)
A
(3216)
B
(3528)
.079±.008 .049±.008 .035±.004 .047 Max. .020±.012 .031 Min.
(2.0±0.2) (1.25±0.2)
(0.9±0.1)
(1.2 Max.)
(0.5±0.3)
(0.8 Min.)
.126±.008 .063±.008 .047±.008 .063±.008 .028±.012 .055±.008
(3.2±0.2) (1.6±0.2)
(1.2±0.2)
(1.6±0.2) (0.7±0.3) (1.4±0.2)
.138±.008 .110±.008 .087±.008 .073±.008 .031±.012 .055±.008
(3.5±0.2) (2.8±0.2) (2.2±0.2) (1.9±0.2) (0.8±0.3) (1.4±0.2)
.236±.012 .126±.008 .087±.008 .098±.008 .051±.012 .094±.008
(6.0±0.3) (3.2±0.2) (2.2±0.2) (2.5±0.2) (1.3±0.3) (2.4±0.2)
.287±.012 .169±.012 .094±.004 .110±.008 .051±.012 .15±.008
(7.3±0.3) (4.3±0.3) (2.4±0.1) (2.8±0.2) (1.3±0.3) (3.8±0.2)
capacitors
End
W2
C
(6032)
E
(EIA-D)
d
g
Bottom
d
ordering information
New Part #
TMC
Type
1E
Voltage
Code
0E: 2.5V
0G: 4V
0J: 7V
1A: 10V
1C: 16V
1D: 20V
1E: 25V
1V: 35V
C
Case Size
P: 2012
A: 3216
B: 3528
C: 6032
E: EIA-D
T
Termination
Material
T: Sn
TE
Packaging
TE: 7" embossed
plastic
475
Nominal
Capacitance
Reference
capacitance
ranges and
case sizes
chart
M
Tolerance
K: ±10%
M:±20%
R
Polarity
Orientation
For further information on packaging,
please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
4/22/05
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
.O.
191
TMC
standard tantalum chip capacitor
capacitance ranges and case sizes
Standard Range
STANDARD VALUES VOLTAGE CODE 0G 0J
85ºC
Rated Voltage (VDC)
Surge Voltage (VDC)
125ºC
0.1
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
Derated Voltage (VDC)
Capcode
104
154
224
334
474
684
105
155
225
335
475
685
106
156
226
336
476
686
E
C
E
C
E
A,B
C
E
B
C
E
A
B
C
E
A
B
C
A
B
A
B
A
A
A
A
A
A
B
B
B
C
C
C
E
E
4
5
2.5
7
9
4
1A 1C 1D 1E 1V
10
13
16
20
20
26
13
25
32
16
35
46
23
125ºC
Extended Range
STANDARD VALUES VOLTAGE CODE
85ºC
Rated Voltage (VDC)
Surge Voltage (VDC)
Derated Voltage (VDC)
Capcode
473
683
104
154
224
334
474
684
105
155
225
335
475
685
106
156
226
336
476
686
107
157
227
337
477
Capacitance (µF)
.047
.068
.1
.15
.22
.33
.47
.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
0E
2.5
3.2
1.6
0G
4
5
2.5
0J
7
9
4
1A
10
13
6.3
1C
16
20
10
1D
20
26
13
1E
25
32
16
P
P
P
P
P
P
P
A,P
A
A
A,B
A,B
A,B,C
B,C
B,C
C,E
C,E
E
E
A
A
A
A
A,B
A,B
A,B
B,C
B,C
B,C
C,E
C,E
E
E
1V
35
46
23
6.3 10
Capacitance (µF)
P
P
P
A,P
A,P
A,P
A,B,P
A,B
B
B,C
B,C
C,E
C,E
E
E
P
P
A,P
A,P
A,P
A,B,P
A,B,P
A,B,P
A,B,C
A,B,C
B,C,E
B,C,E
C,E
C,E
E
E
P
P
A,P
A,P
A,P
A,B,P
A,B,P
A,B
A,B,C
A,B,C
B,C,E
B,C,E
B,C,E
C,E
E
E
P
P
A,P
A,P
A,P
A,B,P
A,B
A,B
B,C
B,C
B,C,E
B,C,E
C,E
C,E
C,E
E
P
P
A,P
A
A
A,B
A,B
A,B
A,B
A,B,C
B,C,E
C,E
C,E
E
E
A
A
A
A,B
B
B
B,C
C
C,E
C,E
E
Extended Range
Nominal capacitance (10µF)
Voltage code G = 4 VDC
Value code (same as TMC)
(S6 = 4.7 µf)
Anode (positive)
C & E Case
10
25
C & E Case
47
10
Belt marking (positive)
Production month/year code
Rated voltage (VDC)
Same marking as standard TMC
Year
capacitors
part marking
Standard Range
A & B Case
A6
Value (µf)
Marking
.1
A5
Capacitance symbol (A6:1µF)
Belt marking anode
Lot Number Symbol
Lot number symbol is expressed “a” as January
1999 as a starting month and year in an
alphabetical order and in a small letter to a capital
(Letters of I, i, O, and o are excluded)
Month
2002
2003
2004
2005
1
N
a
n
A
2
P
b
p
B
3
Q
c
q
C
4
R
d
r
D
5
S
e
s
E
6
T
f
t
F
7
U
g
u
G
8
V
h
v
H
9
W
j
w
J
10
X
k
x
K
11
Y
l
y
L
12
Z
m
z
M
Production month/year code
.15 .22 .33 .47 .68 1.0 1.5 2.2 3.3 4.7 6.8 10.0
E5
J5
N5 S5 W5 A6 E6
J6
N6 S6 W6 A7
GS6
Production month/year code
A, B & P Case
Voltage
Marking
2.5
e
4
G
7
J
10
A
16
C
20
D
25
E
35
V
10/03/05
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
192
KOA Speer Electronics, Inc.
• Bolivar Drive • P Box 547 • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
