Type 150
Axial Leaded Metallized Polyester
Flame Retardant Wrap and Fill Axial Leaded Capacitors
The Type 150 series axial lead metallized polyester
non inductive capacitors are available in bulk or on
tape and reel for automatic insertion. Type 150 is a
general purpose capacitor for use in blocking, bypass,
decoupling, smoothing and some timing applica-
tions.
Highlights
• Available on tape and reel or bulk
• Epoxy end fill meets UL94V-0
• Non inductively wound
• Flame retardant outer wrap meets UL510
• Non polar
RoHS Compliant
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Operating Tempeature Range:
Dielectric Withstand Voltage:
Dissipation Factor (DF):
0.001 µF to 10.0 µF
63 to 1000 Vdc
±5%, ±10%, ±20%
–55 ºC to +125 ºC (
derate linearly to 50% rated voltage
at 125 ºC)
Specifications
1.6 x rated voltage for 2 s @ +25 ºC ±5 ºC
tgd x 10
–4
at +25 ºC ±5 ºC
kHz
1
10
100
C
≤0.1
µF
80
150
250
0.1 µF <C ≤1 µF
80
150
—
C >1 µF
100
—
—
Insulation Resistance:
Self Inductance:
Life Test:
Damp Heat Test:
Soldering:
Long Term Storage Stability:
Maximum Pulse Rise Time dv/dt and Pulse:
Characteristic (Wo):
10,000 MΩ x µF, 30,000 MΩ Min.
1 nH max. per 1 mm lead and body length
1000 hrs @ 85 ºC 1.25 x Vn
95% RH @ +45 ºC for 21 days
260 ºC ±5 ºC for 10 s ±1 s
ΔC/C ≤ ±3% after 2 years
V/n
50 - 63
100
250
400
630
L Max
16.5
4
504
5
1,000
10
5,000
13.5
10,800
20
25,200
19 - 20.5
2
252
3
600
7
3,500
10
8,000
15
18,900
26.5 - 5.28
1.5
189
2
400
4
2,000
6.5
5,200
10
12,600
31.5 - 33
1
126
1
300
2.5
1,250
4
3,200
6
7,500
dV/dt (V/µsec)
W
O
(V
2
/µsec)
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type 150
Axial Leaded Metallized Polyester
Tape and Reel Specifications
L Max
(Body Lengty)
Inches
≤.433
.551 - .808
≥1.03
mm
≤11
14 - 20.5
≥26
Lead Spacing
Inches
2.06
2.5
2.87
mm
52.4
63.6
73
Distance Between
Reel Flanges
Inches
3
3.4
3.7
mm
75
86
95
1
2
3
Class
Outline Drawing
Ød ±.003
±0.076 mm
^Add class number (1, 2, or 3) to catalog number to indicate tape and reel
Diameter
Inches
0.197
.236 thru .256
0.276
.315 thru .346
.354 thru .413
.433 thru .512
.551 thru .571
>.571
mm
5
6.0 trhu 6.5
7
8 thru 8.5
9 thru 10.5
11 thru 13
14 thru 14.5
>14.5
Quantity per Reel
3,000
1,200
1,100
800
500
300
200
Not available
Tinned Copper Leads
1.58” ±0.2
(40 ±5 mm)
L Max.
1.58” ±0.2
(40 ±5 mm)
D
Max.
Ratings
Catalog
Part Number
150154*63AA^
150154*63BB^
150184*63AA^
150184*63BB^
150224*63BB^
150274*63BB^
150334*63BB^
150394*63CB^
150474*63DB^
150564*63DB^
150684*63DC^
150824*63EC^
150105*63EC^
150155*63HC^
150225*63HE^
150335*63KE^
150475*63ME^
150685*63QF^
150106*63TF^
150683*100AA^
150683*100BB^
150823*100AA^
150823*100BB^
150104*100AA^
150104*100BB^
150124*100BB^
150154*100BB^
150184*100CB^
150224*100CB^
Cap
(µF)
0.150
0.150
0.180
0.180
0.220
0.270
0.330
0.390
0.470
0.560
0.680
0.820
1.000
1.500
2.200
3.300
4.700
6.800
10.000
0.068
0.068
0.082
0.082
0.100
0.100
0.120
0.150
0.180
0.220
D
63 Vdc
0.197
0.236
0.197
0.236
0.236
0.236
0.236
0.256
0.276
0.276
0.276
0.315
0.315
0.374
0.374
0.433
0.492
0.571
0.610
0.197
0.236
0.197
0.236
0.197
0.236
0.236
0.236
0.256
0.256
0.433
0.650
0.433
0.650
0.650
0.650
0.650
0.650
0.650
0.650
0.807
0.807
0.807
0.807
1.102
1.102
1.102
1.299
1.299
0.433
0.650
0.433
0.650
0.433
0.650
0.650
0.650
0.650
0.650
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
5.0
6.0
5.0
6.0
6.0
6.0
6.0
6.5
7.0
7.0
7.0
8.0
8.0
9.5
9.5
11.0
12.5
14.5
15.5
5.0
6.0
5.0
6.0
5.0
6.0
6.0
6.0
6.5
6.5
11.0
16.5
11.0
16.5
16.5
16.5
16.5
16.5
16.5
16.5
20.5
20.5
20.5
20.5
28.0
28.0
28.0
33.0
33.0
11.0
16.5
11.0
16.5
11.0
16.5
16.5
16.5
16.5
16.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
150123*250AA^
150123*250BB^
150153*250AA^
150153*250BB^
150183*250AA^
150183*250BB^
150223*250AA^
150223*250BB^
150273*250AA^
150273*250BB^
0.012
0.012
0.015
0.015
0.018
0.018
0.022
0.022
0.027
0.027
150155*100IE^
150225*100LE^
150335*100PE^
150475*100RF^
150685*100WF^
150106*100YF^
1.500
2.200
3.300
4.700
6.800
10.000
Inches Max
L
Ød
Millimeters Max
D
L
Ød
Catalog
Part Number
150274*100CB^
150334*100EB^
150394*100EB^
150474*100DC^
150564*100EC^
150684*100FC^
150824*100HC^
150105*100IC^
Cap
(µF)
0.270
0.330
0.390
0.470
0.560
0.680
0.820
1.000
D
0.256
0.315
0.315
0.276
0.315
0.335
0.374
0.394
0.394
0.453
0.531
0.591
0.689
0.807
0.197
0.236
0.197
0.236
0.197
0.236
0.197
0.236
0.197
0.236
Inches Max
L
0.650
0.650
0.650
0.807
0.807
0.807
0.807
0.807
1.102
1.102
1.102
1.299
1.299
1.299
0.433
0.650
0.433
0.650
0.433
0.650
0.433
0.650
0.433
0.650
Ød
0.024
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.031
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
0.024
Millimeters Max
D
6.5
8.0
8.0
7.0
8.0
8.5
9.5
10.0
10.0
11.5
13.5
15.0
17.5
20.5
5.0
6.0
5.0
6.0
5.0
6.0
5.0
6.0
5.0
6.0
L
16.5
16.5
16.5
20.5
20.5
20.5
20.5
20.5
28.0
28.0
28.0
33.0
33.0
33.0
11.0
16.5
11.0
16.5
11.0
16.5
11.0
16.5
11.0
16.5
Ød
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
100 Vdc
250 Vdc
100 Vdc
* Indicates capacitance tolerance
J = ±5%, K = ±10%, M = ±20%
^If ordering tape and reel,
insert 1, 2, or 3.
See tape & reel specifications to determine which class applies.
Part Number highlighted in yellow, available until stock is depleted.
Replacement part number with “BB” case size.
Part Number highlighted in green - OBSOLETE
Part number highlighted in light yellow, available until stock is depleted, no replacement
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
