FDC6330L
February 1999
FDC6330L
Integrated Load Switch
General Description
This device is particularly suited for compact power
management in portable electronic equipment where 3V
to 20V input and 2.3A output current capability are needed.
This load switch integrates a small N-Channel power
MOSFET (Q1) which drives a large P-Channel power
MOSFET (Q2) in one tiny SuperSOT
TM
-6 package.
Features
•
V
= 0.2V @ V = 12V, I =2.5 A. R
DROP
DROP
IN
IN
L
L
(ON)
(ON)
= 0.08
Ω
V
= 0.2V @ V = 5V,I = 1.6 A. R
= 0.125
Ω.
•
Control MOSFET (Q1) includes Zener protection for
ESD ruggedness (>6kV Human Body Model).
•
High performance PowerTrench
TM
technology for
extremely low on-resistance.
•
SuperSOT
TM
-6 package design using copper lead frame
for superior thermal and electrical capabilities.
Applications
•
Power management
•
Load actuation
Vin,R1
4
Q2
3
Vout,C1
EQUIVALENT CIRCUIT
ON/OFF
5
Q1
2
Vout,C1
IN
V
DR OP
+
-
OUT
R1,C1
6
See Application Circuit
1
R2
ON/OFF
SuperSOT -6
Absolute Maximum Ratings
Symbol
V
IN
V
ON/OFF
I
D
P
D
T
J
, T
stg
ESD
Input Voltage Range
On/Off Voltage Range
Load Current
- Continuous
- Pulsed
Maximum Power Dissipation
o
TM
T
A
=25 C unless otherwise noted
Parameter
(Note 1)
Ratings
3 - 20
1.5 - 8
(Note 2)
Units
V
V
A
W
°
C
kV
2.3
10
0.7
-55 to +150
6
(Note 1)
Operating and Storage Temperature Range
Electrostatic Discharge Rating MIL-STD-883D
Human-Body-Model (100pf/1500 Ohm)
Thermal Characteristics
R
θ
JA
R
θ
JC
Thermal Resistance, Junction-to-Ambient
Thermal Resistance, Junction-to-Case
(Note 2)
(Note 2)
180
60
°
C/W
°
C/W
Package Marking and Ordering Information
Device Marking
Device
FDC6330L
Reel Size
7’’
Tape width
8mm
Quantity
3000 units
.
330 (
.
Denotes pin 1)
©1999
Fairchild Semiconductor Corporation
FDC6330L Rev. C
FDC6330L
Electrical Characteristics
Symbol
Parameter
T
A
=25 C unless otherwise noted
o
Test Conditions
Min
Typ
Max
Units
OFF Characteristics
I
FL
Leakage Current
(Note 3)
V
IN
= 20 V, V
ON/OFF
= 250
µ
A
1
µ
A
ON Characteristics
V
DROP
R
(ON)
I
L
Conduction Voltage
Q
2
- Static On-Resistance
Load Current
V
IN
= 12 V, V
ON/OFF
= 3.3 V, I
L
= 2.5 A
V
IN
= 5 V, V
ON/OFF
= 3.3 V, I
L
= 1.6 A
V
GS
= -12 V, I
D
= -2.3 A
V
GS
= -5 V, I
D
= -1.9 A
V
DROP
= 0.2 V, V
IN
= 12 V, V
ON/OFF
= 3.3 V
V
DROP
= 0.2 V, V
IN
= 5 V, V
ON/OFF
= 3.3 V
0.054
0.081
2.5
1.6
0.2
0.2
0.08
0.125
V
V
Ω
A
Notes:
1. Range of Vin can be up to 30V, but R1 and R2 must be scaled such that VGS of Q2 does not exceed 20V.
2. R
θJA
is the sum of the junction-to-case and case-to-ambient thermal resistance where the case thermal reference is defined as the solder mounting
surface of the drain pins. R
is guaranteed by design while R
is determined by the user’s board design.
θJC
θJA
3. Pulse Test: Pulse Width < 300µs, Duty Cycle < 2.0%.
FDC6330L Load Switch Application
External Component Recommendation:
For applications where Co
≤
1µF.
For slew rate control, select R2 in the range of 1k - 4.7kΩ .
For additional in-rush current control,C1
≤
1000pF can be added.
Select R1 so that the R1/R2 ratio ranges from 10 - 100. R1 is required to turn Q2 off.
FDC6330L Rev. C
FDC6330L
Typical Characteristics
(continued)
0.4
0.5
TJ = 125°C
0.4
0.3
V
DROP
(V)
TJ = 125°C
V
DROP
(V)
0.3
T = 25 °C
J
0.2
T = 25 °C
J
0.2
0.1
V
IN
= 12 V
V
ON/OF F
= 1. 5 - 8 V
PW =300 us, D
≤
2%
0.1
V
IN
= 5V
V
ON/OF F
= 1. 5 - 8 V
PW =300 us, D
≤
2%
0
0
1
2
I
L
, (A)
3
4
5
0
0
1
2
I
L
, (A)
3
4
5
Figure 1. Conduction Voltage Drop
Variation with Load Current.
Figure 2. Conduction Voltage Drop
Variation with Load Current.
0.25
IL = 1A
V
ON/OFF
= 1.5 - 8 V
PW =3 00 us, D
≤
2%
0.2
R
(ON)
,(Ohm)
0.15
T = 1 25°C
J
0.1
0.05
T = 25 °C
J
0
2
4
6
V
I N
, (V)
8
10
12
Figure 3. On-Resistance Variation
with Input Voltage.
TRANSIENT THERMAL RESISTANCE
1
0.5
D = 0.5
r(t), NORMALIZED EFFECTIVE
0.2
0.1
0.05
0.2
0.1
0.05
0.02
0.01
R
θ
JA
(t) = r(t) * R
θ
JA
R
θ
JA
=180°C/W
P(pk)
t
1
t
2
0.02
0.01
0.0001
Single Pulse
T
J
- T
A
= P * R JA (t)
θ
Duty Cycle, D = t
1
/ t
2
0.001
0.01
0.1
t
1
, TIME (sec)
1
10
100
300
Figure 4.Transient Thermal Response Curve.
Thermal characterization performed using the conditions described in Note 2.
Transient themal response will change depending on the circuit board design.
FDC6330L Rev. C
