CRYSTAL CLOCK OSCILLATORS
5Vdc • HCMOS/ TTL COMPATIBLE HALF-SIZE DIP
AC H
12.7 x 12.7 x 5.6 mm
FEATURES:
APPLICATIONS:
• Wide frequency range.
• Tight symmetry option.
• Fast rise and fall times.
• HCMOS and TTL compatible.
• Tristate Enable / Disable function.
• Anti-Static packaging tube.
• Provide clock signals for microprocessors and digital circuits.
• High output drive capability applications.
STANDARD SPECIFICATIONS
PARAMETERS
Frequency Range
Operating Temperature (T
OPR
)
Storage Temperature (T
STO
)
Frequency Stability
(DF/ F
o
)
Supply Voltage
(V
dd
)
Input Current
Duty Cycle
or Symmetry
(I
dd
)
(F
o
)
SPECIFICATIONS
32.768kHz - 200MHz
0°C to +70°C
(See Options)
-55°C to +125°C
±100ppm max.
(See Options)
5Vdc ±10%
30mA max. for F< 24MHz 70mA max. for F< 80MHz
_
45mA max. for F< 50MHz 85mA max. for F> 80MHz
45 / 55% max. for F < 50MHz
@ 1
/
2
V
dd
(See Options)
_
40 / 60% max. for F > 50MHz
@ 1
/
2
V
dd
(See Options)
_
10ns max. for F < 24MHz
Rise and Fall Times (T
R
/
T
F
)
5ns max. for F > 24MHz
Output Load
10TTL or 15pF (50pF max.) for F
o
< 80MHz
_
5TTL or 15pF for (F
o
) > 80MHz
Output Voltage
Start-up Time
Tristate Function
(Option “-A” ONLY)
0.9 *V
dd
min. (V
OH
) ; 0.4V
dc
max. (V
OL
)
(T
OSC
)
10ms max.
(V
IH
) “1” or Open: Oscillation
> 2.2V
_
“0”:Output disabled in high impedance (Hi Z) < 0.8V
(V
IL
)
100ns max. (for Option “- A” ONLY)
Dimensions: Inches (mm)
PIN
NUMBER
FUNCTION
Output Disable / Enable Time
* Pin 1 has internal pull-up resistor which allows Pin 1 to be left floating (enable high) Option A.
Test circuit, waveforms, see appendix B..
Environmental and mechanical specifications, see appendix C. Group 1.
Marking, see appendix G. Recommended handling, see appendix F.
Application notes, see appendix A. Reflow profile see appendix E.
1
4
5
8
NC or Tristate E/D
GND / Case
Output
V
dd
ORDERING OPTIONS
I
ACH - Frequency - Temperature - Overall Frequency Stability
XX.XXXX MHz or kHz
-D for -10°C to + 60°C
-E for -20°C to + 70°C
-F for -30°C to + 70°C
-N for -30°C to + 85°C
-L for -40°C to + 85°C
-Y for ±
-J for ±
-R for ±
-K for ±
-H for ±
-C for ±
10ppm max**
20ppm max
25ppm max
30ppm max
35ppm max
50ppm max
-
Duty Cycle - Tristate
1/2Vdd
@
1/2Vdd
@
1.4Vdc
@
1.4Vdc
@
- 50 - Value Added - Packaging
- T for tape and reel
-TY for Tray packing
-S for 45 / 55%
-T for 47.5 / 52.5%
-S1 for 45 / 55%
-T1 for 47.5 / 52.5%
50pF load
output drive
- A for Tristate E/D
ABRACON
54
** Standard Operating Temperature Only Frequency 50 MHz max.
-G
Gull Wing
-G2 Gull Wing
-GHT Gull Wing Reflow capable
-QXX (Trimmed Leads)
®
NOTE: Left blank if standard
•
All specifications and markings subject to change without notice
C O R P O R AT I O N
29 Journey • Aliso Viejo, CA 92656 • USA
(949) 448-7070 •
F
AX
: (949) 448-8484
E-
MAIL
:
abinfo
@
abracon.com •
I
NTERNET
A
DDRESS
:
www.abracon.com
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
