MISCELLANEOUS SOCKETS
Shrink DIP Sockets and Strips
Solder Tail and Wrapost
0,38
0,25
0,64
0,46
Series 117, 127, 217
227, 317, 327
●
2,11
3,68
2,79
4,19
●
4,19
High density DIP
sockets and strips for
devices featuring 1,78
lead spacing.
Hi-Rel, 4-finger #30 clip
is rated at 3 amps.
See page 208 for details.
Solder tail is MM# 1802
receptacle (see page 138
for details). Wraposts are
MM# 1702-2 or 1703-3
pins. See page 162 for
details.
3,18
9,4
0,51
0,64
12,95
●
Total number
of pins
Or dering Inf ormation
Quantity
per tube
XX=Plating Code
See Below
Solder Tail
1,78
For RoHS compliance, select
plating code.
For the all gold option (XX=13) also change
part number from XX7-XX-XXX-41-00X000
to XX7-13-XXX-41-00X100
A
B
C
2 Level Wrapost
L = 9,4
OPEN FRAME DIP SOCKET
3 Level Wrapost
L = 12,95
16
28
30
48
20
28
40
42
48
52
56
64
68
64
14,53 7.62 4,41
25,2 10,16 12,45
26,97 10,16 12,45
42,98 10,16 12,45
18,08 15,24
25,2 15,24
35,86 15,24
37,64 15,24
42,98 15,24
46,53 15,24
50,1 15,24
57,2 15,24
60,76 15,24
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
17,53
35
20
18
12
28
20
14
13
11
11
10
8
8
8
117-XX-316-41-005000
117-XX-428-41-005000
117-XX-430-41-005000
117-XX-448-41-005000
117-XX-620-41-005000
117-XX-628-41-005000
117-XX-640-41-005000
117-XX-642-41-005000
117-XX-648-41-005000
117-XX-652-41-005000
117-XX-656-41-005000
117-XX-664-41-005000
117-XX-668-41-005000
117-XX-764-41-005000
127-XX-316-41-002000
127-XX-428-41-002000
127-XX-430-41-002000
127-XX-448-41-002000
127-XX-620-41-002000
127-XX-628-41-002000
127-XX-640-41-002000
127-XX-642-41-002000
127-XX-648-41-002000
127-XX-652-41-002000
127-XX-656-41-002000
127-XX-664-41-002000
127-XX-668-41-002000
127-XX-764-41-002000
127-XX-316-41-003000
127-XX-428-41-003000
127-XX-430-41-003000
127-XX-448-41-003000
127-XX-620-41-003000
127-XX-628-41-003000
127-XX-640-41-003000
127-XX-642-41-003000
127-XX-648-41-003000
127-XX-652-41-003000
127-XX-656-41-003000
127-XX-664-41-003000
127-XX-668-41-003000
127-XX-764-41-003000
57,2 19,05 21,34
CLOSED FRAME DIP SOCKET
64
57,2 19,05 21,34
37,64
2,64
1,78
8
217-XX-764-41-005000
227-XX-764-41-002000
227-XX-764-41-003000
SINGLE ROW STRIP SOCKET
If desired, we will supply any length up to 21 pins.
317-XX-121-41-005000
SPECIFY PLATING CODE XX=
21
37,64
327-XX-121-41-002000
13
0,76µm Au
327-XX-121-41-003000
99
41
43
44
200µ” Sn
5,08µm Sn
200µ” Sn
10µ” Au
0,76µm Au
200µ” Sn
91
10µ” Au
93
Sleeve (Pin)
Contact (Clip)
0,25µm Au
200µ” Sn/Pb
5,08µm Sn/Pb
200µ” Sn/Pb
0,76µm Au
200µ” Sn/Pb
w w w. m i l l - m a x . c o m
87
516-922-6000
