Female Card Edge
.156” [3.96 mm] Contact Centers, .610” [15.49 mm] Insulator Height,
Dip Solder/Wire Wrap/Right Angle for .093”[2.36 mm] or .125”[3.18 mm] Mating PCB
SPECIFICATIONS
• Accommodates .093” ± .008” [2.36 mm ± 0.20 mm] or
.125” ± .008” [3.18 mm ± 0.20 mm] mating PCB
(Consult factory for .031” ± .006” [0.79 mm ± 0.15 mm] PC boards)
• PBT, PPS or PA9T insulator
• Molded-in key available
• 3 Amps current rating for one contact energized
• 30 milli Ohms maximum at rated current
• UL Flammability Rating: 94V-0
READOUT
Female Card Edge
DUAL (D)
TERMINATION TYPE
L
.030” [0.76]
.150” [3.81]
L
.250” [6.35]
LOOP
BELLOWS
(RS, RM)
TERMINATION
TYPE
RS
RM
TA
TB
Dip Solder
Wire Wrap
Right Angle
Right Angle
Right Angle
POST CROSS
SECTION (K)
.025ʺ [0.64] SQUARE
.025ʺ [0.64] SQUARE
.025ʺ [0.64] SQUARE
.025ʺ [0.64] SQUARE
.025ʺ [0.64] SQUARE
POST LENGTH
L ± .025ʺ [0.64]
.190ʺ [4.83]
.560ʺ [14.20]
.100ʺ [2.54]
.180ʺ [4.57]
.250ʺ [6.35]
FITS MIN.
HOLE SIZE
.040ʺ [1.02]
.040ʺ [1.02]
.043ʺ [1.09]
.043ʺ [1.09]
.043ʺ [1.09]
K
RIGHT ANGLE
DIP SOLDER
(TA, TB, TM)
TM
PCB LAYOUT
.250” [6.35]
.156” [3.96] TYP.
Ø .040” [1.02]
COMPONENT SIDE
.150” [3.81]
.156” [3.96] TYP.
Ø .043” [1.09]
A
D
STRAIGHT PIN TERMINATIONS
(RS, RM)
2X Ø .125” [3.18]
.095” [2.41]
A
D
RIGHT ANGLE TERMINATIONS
(TA, TB, TM)
2X Ø .125” [3.18]
MOUNTING STYLE
Ø.125” [3.18]
.250” [6.35]
FLUSH MOUNTING
(D)
NO MOUNTING
EARS (N)
#4-40
.250” [6.35]
FLUSH MOUNTING WITH
THREADED INSERT (T)
Ø.125” [3.18]
.250” [6.35]
FLUSH MOUNTING WITH
SIDE HOLES (Z)
80
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
Female Card Edge
.156” [3.96 mm] Contact Centers, .610” [15.49 mm] Insulator Height,
Dip Solder/Wire Wrap/Right Angle for .093” [2.36 mm] or .125” [3.18 mm] Mating PCB
PART NUMBER OPTIONS
MATERIALS (INSULATOR/CONTACT)
E =
PBT/Phosphor Bronze (Standard)
R
=
PPS/Phosphor Bronze
G
=
PA9T/Phosphor Bronze
H =
PBT/ Beryllium Copper
A =
PPS/Beryllium Copper
J =
PA9T/Beryllium Copper
(Consult factory for other materials.)
Refer to Page 7 for Operating/Processing Temperatures
CONTACT FINISH - RoHS Compliant
Contact Surface
.000010” Gold
.000030” Gold
.000010” Gold
.000030” Gold
Contact Surface
S
=
.000010” Gold
M =
.000030” Gold
E =
.000100” Pure Tin, Matte
CONTACT CENTERS
M =
.156” [3.96 mm]
B
C
G
Y
=
=
=
=
All platings are Lead Free and have .000050” Nickel underplate
E B M 43 D RM D - S273
MODIFICATION CODE
(Consult Factory)
-S273
=
FOR .093” ± .008” [2.36 mm ± 0.20 mm]
THICK MATING PCB
-S664
=
FOR .125” ± .008” [3.18 mm ± 0.20 mm]
THICK MATING PCB
MOUNTING STYLE (Opposite Page)
N =
No Mounting
D =
Flush Mounting
T
=
Flush Mounting With Threaded Inserts
Z =
Flush Mounting With Side Holes
TERMINATION TYPE (Opposite Page)
RS
=
.025” [0.64 mm] Square Dip Solder
RM
=
.025” [0.64 mm] Square Wire Wrap
TA, TB, TM
=
.025” [0.64 mm] Square Right Angle
READOUT (Opposite Page)
D =
Dual
NUMBER OF CONTACT POSITIONS
See Chart Below
Termination
.000100” Pure Tin, Matte
.000100” Pure Tin, Matte
.000005” Gold
.000005” Gold
Overall Plating
.000010” Gold
.000010” Gold
.000100” Pure Tin, Matte
Female Card Edge
DIMENSIONS
Dimensions in [ ] are in millimeters, all others are in inches.
REFER TO MOUNTING STYLE
.297 [7.54] INSERTION DEPTH
C
.360
[9.14]
.610
[15.49]
A
B
D
E
.470 [11.94]
.060
[1.52]
.156 [3.96] TYP.
F
REFER TO
TERMINATION TYPE,
SEE OPPOSITE PAGE
Tolerances on non-critical dimensions may very slightly due to shrinkage differential per insulator material; Consult factory.
POSITIONS/
CONTACTS A±.008
06/12
08/16*
10/20
12/24
15/30
18/36
20/40
22/44
24/48*
25/50*
28/56*
30/60*
31/62*
32/64
36/72
40/80*
43/86*
0.780
1.092
1.404
1.716
2.184
2.652
2.964
3.276
3.588
3.744
4.212
4.524
4.680
4.836
5.460
6.084
6.552
INCHES
B±.008
1.102
1.414
1.726
2.038
2.506
2.974
3.286
3.598
3.910
4.066
4.534
4.846
5.002
5.158
5.782
6.406
6.874
MILLIMETERS
E±.020
1.784
2.096
2.408
2.720
3.188
3.656
3.968
4.280
4.592
4.748
5.216
5.528
5.684
5.840
6.464
7.088
7.556
C±.015
1.221
1.533
1.845
2.157
2.625
3.093
3.405
3.717
4.029
4.185
4.653
4.965
5.121
5.277
5.901
6.525
6.993
D±.010
1.534
1.846
2.158
2.470
2.938
3.406
3.718
4.030
4.342
4.498
4.966
5.278
5.434
5.590
6.214
6.838
7.306
F±.015
1.104
1.416
1.728
2.040
2.508
2.976
3.288
3.600
3.912
4.068
4.536
4.848
5.004
5.160
5.784
6.408
6.876
A±0.20
19.81
27.74
35.66
43.59
55.47
67.36
75.29
83.21
91.14
95.10
106.98
114.91
118.87
122.83
138.68
154.53
166.42
B±0.20
27.99
35.92
43.84
51.77
63.65
75.54
83.46
91.39
99.31
103.28
115.16
123.09
127.05
131.01
146.86
162.71
174.60
C±0.38
31.01
38.94
46.86
54.79
66.68
78.56
86.49
94.41
102.34
106.30
118.19
126.11
130.07
134.04
149.89
165.74
177.62
D±0.25
38.96
46.89
54.81
62.74
74.63
86.51
94.44
102.36
110.29
114.25
126.14
134.06
138.02
141.99
157.84
173.69
185.57
E±0.51
45.31
53.24
61.16
69.09
80.98
92.86
100.79
108.71
116.64
120.60
132.49
140.41
144.37
148.34
164.19
180.04
191.92
F±0.38
28.04
35.97
43.89
51.82
63.70
75.59
83.52
91.44
99.37
103.33
115.21
123.14
127.10
131.06
146.91
162.76
174.65
* Consult factory for availability.
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
81
