IMX 15, IMY 15 Series
15 Watt DC-DC Converters
Wide input voltage ranges up to 150 V DC
1 or 2 outputs up to 48 V DC
1500...4000 V DC I/O electric strength test
LGA
• Reinforced isolation for IMY-models
• Magnetic feedback
• Synchronous rectifier for 2.5, 3.3 and 5 V
outputs
• Short circuit protection
Selection chart
Output 1
U
o nom
I
o nom
[V DC]
[mA]
2.5
4500
2.5
4500
3.3
4500
3.3
4500
3.3
4500
5
3500
5
3500
5
3500
5.1
2300
5.1
2500
5.1
2500
+5.1
1350
+5.1
1500
+5.1
1500
5
1300
5
1400
5
1400
12
650
12
700
12
700
15
500
15
560
15
560
24
320
24
350
24
350
Output 2
U
o nom
I
o nom
[V DC]
[mA]
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
+3.3
1350
+3.3
1500
+3.3
1500
5
1300
5
1400
5
1400
12
650
12
700
12
700
15
500
15
560
15
560
24
320
24
350
24
350
Input voltage
U
i
[V DC]
8.4...36
16.8...75
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
8.4...36
16.8...75
50...150
Type
Options
(for availability
consult sales point)
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, K, i, L, C, Z
-8, R, i, L, C, Z
-8, R, i, L, C, Z
-8, R, i, L, C, Z
-8, R, i, L, C, Z
20 IMX 15-2.5-9RG
40 IMX 15-2.5-9RG
20 IMX 15-03-9RG
40 IMX 15-03-9RG
110 IMY 15-03-9RG
20 IMX 15-05-9RG
40 IMX 15-05-9RG
110 IMY 15-05-9RG
20 IMX 15-05-9R
40 IMX 15-05-9R
110 IMY 15-05-9R
20 IMX 15-0503-9R
40 IMX 15-0503-9R
110 IMY 15-0503-9R
20 IMX 15-05-05-9
40 IMX 15-05-05-9
110 IMY 15-05-05-9
20 IMX 15-12-12-9
40 IMX 15-12-12-9
110 IMY 15-12-12-9
20 IMX 15-15-15-9
40 IMX 15-15-15-9
110 IMY 15-15-15-9
20 IMX 15-24-24-9
40 IMX 15-24-24-9
110 IMY 15-24-24-9
www.power-one.com
1
Board Mountable
Input
Input voltage range
20 IMX 15
40 IMX 15
110 IMY 15
IMX 15, IMY 15 Series
8.4...36 V DC
16.8...75 V DC
50...150 V DC
Output
Output voltage setting accuracy
Minimum load
Line/load regulation
Line regulation
Load regulation
Output voltage switching noise
Efficiency
U
i nom
, 50%
l
o nom
±1%
U
o nom
recommended for double output models
10%
l
o nom
U
i min
...U
i max
, 50%
l
o nom
, models R (magn. feedback)
±0.5%
U
o nom
U
i min
...U
i max
, 50%
l
o nom
, models without R
±1%
U
o nom
U
i nom
,
10...100%
l
o nom
, models without R, main outp.
±3%
U
o nom
tracking output, models without R
±3%
U
o nom
U
i nom
, 0...100%
l
o nom
, peak-peak, total
max. 1...2%
U
o nom
U
i nom
,
l
o nom
up to typ 88%
Control and protection
Remote shut down
Trim input for
U
o
Input undervoltage lock-out
Overload protection
No-load protection
Temperature protection
TTL-compatible input
disabled with
≤0.7
V
80...105%
U
i min
...U
i max
, fully protected, hiccup mode
U
i min
...U
i max
Safety and EMC
Electric strength test voltage
Type of insulation
Electromagnetic interference
I/O (20 and 40 IMX/110 IMY)
1500/4000 V DC
I/O (20 and 40 IMX supplementary/110 IMY re-inforced)
conducted (with external filter)
class B
radiated
class A
Environmental
Operating ambient temperature
U
i nom
, l
o nom
Storage temperature
non operational
Relative humidity
non condensing
–40...71°C
–40...100°C
93%
Options
Extended temperature range
Magnetic feedback
Alternative pinout
Inhibit input (reverse logic)
SMD version
C-pinout
Open version
–40...85°C (derating above 71°C), ambient, operating
standard for all single output and -0503-models
connected outputs, for compatibility
TTL-compatible, disabled with
≥2.4
V or open-circuit
with PCB lid
connected outputs, no options possible
no housing, not lacquered
-8
R
K
i
L
C
Z
www.power-one.com
2
