REVISIONS
REV.
A
ECO. NO
2178
DESCRIPTION
INITIAL RELEASE
DATE
02/14/2011
BY
LH
F
F
E
.079±.004 2.00±0.10
.020[0.50] X .006[0.15]
.079±.002 2.00±0.05
.079 2.00
.165 4.20
.079±.002 2.00±0.05
A .004[ 0.10]
.035±.002 0.89±0.05
E
.028±.004 0.70±0.10
D
.268±.004 6.80±0.10
D
+.004
+0.10
0.90
.035
- .006
- 0.15
A
.039±.002 1.00±0.05
(NOT REQ'D FOR USE
AS TOP ENTRY)
C .004[ 0.10]
2X
.047±.002 1.20±0.05
OPTIONAL
RECOMMENDED PCB LAYOUT
.065±.002 1.65±0.05
B
C
.053±.012 1.35±0.30
C
.102 2.60
.110±.008 2.80±0.20
.006[0.15]
.006 0.15
2X
.039 1.00
.047 1.20
OPTIONAL, SEE
PART NUMBER CODING
B
C
NOTES:
1. INSULATOR MATERIAL: NYLON 6T, UL 94V-0, BLACK.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: .000030" ~ .000050" NICKEL UNDERPLATE, GOLD FLASH OVERALL.
4. CURRENT RATING: 2 AMPS PER CONTACT.
5. VOLTAGE RATING: 150V AC/DC.
6. INSULATOR RESISTANCE: 1000 MEGOHMS MIN.
7. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
8. DIELECTRIC WITHSTANDING: 500 VAC.
9. OPERATING TEMPERATURE: -40° C TO +105° C.
10. *MAX PROCESSING TEMP.: 260° C FOR 10 SECS.
11. MODIFICATION: WITH PICK AND PLACE CAP IN TAPE & REEL.
*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT INSULATOR. HIGHER PROCESSING
TEMPERATURES MAY BE USED, PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB,
AND INSULATOR DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.
8
7
6
5
.228±.012 5.80±0.30
B
DRAWN
DATE
2/14/2011
NAME
LH
TITLE
A
Pb
R
oHS COMPLIANT
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES: ANGULAR:
X.X= .012 [0.30]
X.XX= .008 [0.20]
X.XXX= .006 [0.15]
30'
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
HEADER FEMALE .079" PITCH, TOP/BOTTOM ENTRY, T&R
A
PART NUMBER
SIZE
INTERPRET DIMENSIONS AND
TOLERANCING
PER: ASME Y14.5M-2009
3
SCALE: 6:1
2
C
CAGE CODE
NPPNxx2GFNx-M81RC
DWG. NO.
54453
11579
REV
SHEET 1 OF 2
1
A
FILE NAME: 11579, NPPNxx2GFNx-M81RC
8
7
6
5
4
3
2
1
F
F
*NPPNxx2GFNP-M81RC
*NPPNxx2GFNS-M81RC
E
(10-POSITION AS SHOWN)
(SEE T&R DIM TABLE AND NOTE 1)
OPTIONAL,
SEE P/N CODING
E
FIRST 20 CELLS EMPTY
.158[4.0]
.079[2.0]
**SEE ABOVE FOR PART
INSIDE EACH CELL
.472 .006[12.0±0.15]
LAST 20 CELLS EMPTY
.059[Ø1.5]
COVER TAPE
D
W±.012[ 0.30]
.069[1.75]
D
.059[1.5]
UNREELING DIRECTION
.132[3.35]
.173[4.4]
C
C
LABEL
A±.012[ 0.30]
13.00 .012[Ø330.0±0.30]
QA LABEL
RoHS LABEL
Part No.:
FEEDING DIRECTION
Cus_P/N:
Quantity:
Data Code:
COVER TAPE
CARRIER TAPE
RoHS6
B
B
1200 PCS/REEL
DRAWN
A
DATE
2/14/2011
NAME
LH
NOTE 1: WHEN THE CARRIER TAPE WIDTH IS EQUAL OR SAMLLER THAN 24mm[.945"],
1.50mm[.059"] CARRIER HOLES ARE LOCATED ON SINGLE SIDE OF CARRIER TAPE.
WHEN THE CARRIER TAPE WIDTH IS OVER THAN 24mm[.945"], 1.50mm[.059"]
CARRIER HOLES ARE LOCATED ON DOUBLE SIDE OF CARRIER TAPE.
8
7
6
5
Pb
R
oHS COMPLIANT
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES: ANGULAR:
X.X= .012 [0.30]
X.XX= .008 [0.20]
X.XXX= .006 [0.15]
30'
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
HEADER FEMALE .079" PITCH, TOP/BOTTOM ENTRY, T&R
PART NUMBER
SIZE
TITLE
A
INTERPRET DIMENSIONS AND
TOLERANCING
PER: ASME Y14.5M-2009
3
SCALE: 16:1
2
C
CAGE CODE
NPPNxx2GFNx-M81RC
DWG. NO.
54453
11579
REV
SHEET 2 OF 2
1
A
FILE NAME: 11579, NPPNxx2GFNx-M81RC
